INSTALLATION MANUAL
STANDARD PSC
MODULAR MULTI-POSITION
AIR HANDLERS
MODELS: MP - 115V
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
UNIT INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
DUCT WORK AND CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . .5
LINE POWER CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
LOW VOLTAGE CONTROL CONNECTIONS . . . . . . . . . . . . . . . . . .6
BLOWER SPEED CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . .6
Return Air Duct Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Typical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Coil and Air Handler Attachment Details . . . . . . . . . . . . . . . . . . . . . . .3
Gasket Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Typical Horizontal Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Duct Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Physical and Electrical Data - Cooling Only . . . . . . . . . . . . . . . . . . . . .7
SECTION I: GENERAL
The MP modular air handler series provides the flexibility for installation
in any position. This unit may be used for upflow, downflow, horizontal
right, or horizontal left applications. These versatile models may be
used for air conditioning or heat pump heating.
These units may be located in a closet, utility room, attic, crawl space,
or basement. These versatile models may be used with heat pump
operation or for cooling with an indoor coil with no electric heat.
Top or side power wiring, control wiring, and color coded leads for
control wiring all combine to make the installation easy and minimize
installation cost.
SECTION II: SAFETY
This is a safety alert symbol. When you see this symbol on
labels or in manuals, be alert to the potential for personal
injury.
Understand and pay particular attention to the signal words DANGER,
WARNING, or CAUTION.
DANGER indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if not
avoided may result in minor or moderate injury. It is also used to
alert against unsafe practices and hazards involving only property
damage.
LIST OF SECTIONS
UNIT DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
AIR SYSTEM ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
TYPICAL THERMOSTAT CONNECTIONS . . . . . . . . . . . . . . . . . . . . 9
WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
START UP SHEET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
LIST OF FIGURES
Line Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Blower Delay Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Blower Speed Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Duct Static Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Typical Wiring Diagram - PSC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Wiring Diagram - PSC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
LIST OF TABLES
Electrical Data - Cooling Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Air Flow Data (CFM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
FIRE OR ELECTRICAL HAZARD
Failure to follow the safety warnings exactly could result in serious
injury, death or property damage. A fire or electrical hazard may result
causing property damage, personal injury or loss of life.
The air handler area must not be used as a broom closet or for any other
storage purposes, as a fire hazard may be created. Never store items
such as the following on, near or in contact with the furnace.
1. Spray or aerosol cans, rags, brooms, dust mops, vacuum clean-
ers or other cleaning tools.
2. Soap powders, bleaches, waxes or other Cleaning compounds;
plastic items or containers; gasoline, kerosene, cigarette lighter
fluid, dry cleaning fluids or other volatile fluid.
3. Paint thinners and other painting compounds.
4. Paper bags, boxes or other paper products
Never operate the air handler with the blower door removed. To do so
could result in serious personal injury and/or equipment damage.
WARNING
!
WARNING
!
5138264-UIM-D-0816
ISO 9001
Certified Quality
Management System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP-115V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Johnson Controls MP-115V

  • Page 1: Table Of Contents

    INSTALLATION MANUAL STANDARD PSC MODULAR MULTI-POSITION AIR HANDLERS ISO 9001 Certified Quality MODELS: MP - 115V Management System LIST OF SECTIONS GENERAL ..........1 UNIT DATA .
