aspenhome
ah
ITEM NO: I631-239
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
HARDWARE LIST:
No.
Description
Hex Bolt Ø1/4" x 2"
A
Lock Washer Ø1/4"
B
Flat Washer Ø1/4" x 3/4"
C
Allen Wrench 4mm
D
FUNCTIONALITY INSTRUCTION
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/2
R
Pier Base
Sketch
Quantity
8 PCS
8 PCS
8 PCS
1 PC
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST:
Description
No.
1
Case
Leg
2
Adjustable Wood Shelves
Tempered Glasses
Leveler on Legs
Adjust the leveler
when necessary
Quantity
Sketch
1 PC
4 PCS
05-29-2023
Advertisement
Related Manuals for aspenhome I631-239
Summary of Contents for aspenhome I631-239
- Page 1 ASSEMBLY INSTRUCTIONS ITEM NO: I631-239 Pier Base Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment. TOOLS REQUIRED (NOT PROVIDED) PHILLIPS SCREWDRIVER...
- Page 2 ASSEMBLY INSTRUCTIONS ITEM NO: I631-239 Pier Base STEP 1: Lay the case face down on a soft surface. Attach the legs to case by using 8 bolts(A), lock washers(B), flat washers(C). Completely tighten all bolts. Turn the assembled base to the upright position.
- Page 3 ASSEMBLY INSTRUCTIONS ITEM NO: I631-272 72'' Console Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment. TOOLS REQUIRED (NOT PROVIDED) PHILLIPS SCREWDRIVER...
- Page 4 ASSEMBLY INSTRUCTIONS ITEM NO: I631-272 72'' Console STEP 1: Lay the case face down on a soft surface. Attach the side legs and central leg to case by using 8 bolts(A), 2 bolts(B), 10 lock washers(C), 10 flat washers(D). Completely tighten all bolts.
- Page 5 1 PC Wood Screw #4 x 1-3/16" 8 PCS FUNCTIONALITY INSTRUCTION I631-285 I631-272H I631-285 I631-239 I631-272 I631-239 BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS. Save these instructions for future reference. FOR INDOOR USE ONLY Page 1/4...
- Page 6 ASSEMBLY INSTRUCTIONS ITEM NO: I631-272H 72" Bridge & Back Panel STEP 1: Assemble the back panel(left) to back panel(right) by using 2 bolts(B), lock washers(C), flat washers(D), and female bolts(G) with 2 allen wrench(E) as shown below. Do not completely tighten bolts.
- Page 7 ASSEMBLY INSTRUCTIONS ITEM NO: I631-272H 72" Bridge & Back Panel STEP 3: Place the back panel assembly on the console by using 4 bolts(A), lock washers(C), flat washers(D) with 2 metal plates(F) as shown below. Do not completely tighten bolts.
- Page 8 ASSEMBLY INSTRUCTIONS ITEM NO: I631-272H 72" Bridge & Back Panel STEP 5: Attach the bridge to hutches by using 8 bolts(A), lock washers(C), flat washers(D) and female bolts(G) with 2 allen wrenchs(E) as shown below. Completely tighten all bolts.
- Page 9 Note: Please follow the group assembly instruction when this base is combined with the bridge & back panel (I631-272H). FUNCTIONALITY INSTRUCTION I631-285 I631-285 I631-239 Metal Plate Adjust the leveler I631-239 when necessary Leveler on Legs BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
