aspenhome
ah
ITEM NO: I597-415
I597-406
I597-410
I597-407
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
I597-415
I597-406
I597-410
I597-415
I597-406
I597-410
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/7
King Panel HB
King Rails w/ Decking
Cal King Rails w/ Decking
King Low Profile FB
UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
I597-407
Option 1
I597-407
Option 2
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
R
All Beds need to be set up in the exact final
location so that after full assembly it will not
need to be moved. Moving the bed will cause
the support legs to move out of perpendicular
(90 degree), weaken the support system, and
may allow the bed to collapse.
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
04-13-2022
Advertisement
Table of Contents
Related Manuals for aspenhome I597-415
Summary of Contents for aspenhome I597-415
- Page 1 ASSEMBLY INSTRUCTIONS ITEM NO: I597-415 King Panel HB I597-406 King Rails w/ Decking I597-410 Cal King Rails w/ Decking I597-407 King Low Profile FB Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment.
- Page 2 ASSEMBLY INSTRUCTIONS ITEM NO: I597-415 King Panel HB I597-406 King Rails w/ Decking I597-410 Cal King Rails w/ Decking I597-407 King Low Profile FB HARDWARE LIST: I597-415 COMPONENTS LIST: I597-415 Description Quantity Description Quantity Sketch Sketch Bolt Ø1/4" x 1-3/8"...
- Page 3 ASSEMBLY INSTRUCTIONS ITEM NO: I597-415 King Panel HB I597-406 King Rails w/ Decking I597-410 Cal King Rails w/ Decking I597-407 King Low Profile FB For option 1: STEP 2: Screw the bolts(E) into HB & FB. Make sure the slat bearer is in the UPPER position.
- Page 4 ASSEMBLY INSTRUCTIONS ITEM NO: I597-415 King Panel HB I597-406 King Rails w/ Decking I597-410 Cal King Rails w/ Decking I597-407 King Low Profile FB STEP 5: Put the decking over the slats, secure decking to the slats with wood screws (K &...
- Page 5 ASSEMBLY INSTRUCTIONS ITEM NO: I597-415 King Panel HB I597-406 King Rails w/ Decking I597-410 Cal King Rails w/ Decking I597-407 King Low Profile FB For option 2: STEP 2: The slat bearers have been attached in position (b) side approximately 2"...
- Page 6 ASSEMBLY INSTRUCTIONS ITEM NO: I597-415 King Panel HB I597-406 King Rails w/ Decking I597-410 Cal King Rails w/ Decking I597-407 King Low Profile FB STEP 5: Arrange slats on the slat bearers and then lay the decking on top of the slats.
- Page 7 ASSEMBLY INSTRUCTIONS ITEM NO: I597-415 King Panel HB I597-406 King Rails w/ Decking I597-410 Cal King Rails w/ Decking I597-407 King Low Profile FB STEP 7: For Cal King bed, insert wood caps into the holes on headboard and footboard. For regular King bed, skip this step.
