SECTION 11: REPLACING PARTS
At all times when parts are being replaced, ensure that both gas and electrical supplies are disconnected.
Various parts are available from the factory for replacement by a licensed service person. Refer to exploded parts
guide in Section 12 for all replacement parts.
Date of Installation _______________________
Heater Model Number RFPA _____ ______N = Natural Gas
Heater Serial Number _____________________L = Propane Gas
SECTION 12: REPLACING PARTS LIST – RFPA10C
Table 6: Replacement parts
ITEM PART
NO. NO.
1 02127150
2 02129160
3 04114000
4 04593020
5 04362020
6 04380000
7 41859000
8 41858000
9 40584000
10 04094010
11 04783010
12 41806020
13 41847000
14 02247010
15 41795020
16 41795010
17 03399020
18 03399030
19 03345010
20 03345020
21 03437000
22 03401030
23 41799000
24 04659000
25 43137010
26 03527000
27 03339020
28 41834000
29 03258120
30 03258910
Form 41357040
May 2021
DESCRIPTION
Hex Nut 1/2-13
Flat Washer 1/2
Upper Head
Expanded Metal Guard
Heat Exchanger Assembly
Main Burner Assembly (complete)
Burner Cap
Burner Base
Burner Alignment Bracket Assembly
Shutter Plate - Fixed
Base Assembly
Label Mounting Plate
Washer - Burner Fitting
Machine Screw 1/2-13 x 1
Pilot Shield - Outer
Pilot Shield - Inner
Pilot Burner & Orifice Fitting - Nat. #J129DDA3223
Pilot Burner & Orifice Fitting - PROPANE
#J129DDA4212
Pilot Orifice - Nat (.023") #Y90AA - 3223
Pilot Orifice - PROPANE (.012") #Y90AA - 4212
Pilot Burner less Orifice #J129DDA
Thermocouple
Pilot Tubing - White-Rodgers valve
Pilot Tubing - Baso valve
Pilot Tubing - Robertshaw valve
Break Away Fitting - included w/Valve & Pilot Orifice
Plug - 1/8" (pressure tap)
Burner Fitting Assembly
Main Burner Orifice (Nat.) #12
Main Burner Orifice (PROPANE) 7/64"
MODEL USED ON
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C-N6,N6C,N9A
RFPA10C-L6,L6C,L9A
RFPA10C-N6,N6C,N9A
RFPA10C-L6,L6C,L9A
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C (ALL MODELS)
RFPA10C-N6,N6C,N9A
RFPA10C-L6,L6C,L9A
13
RFPA10C-6C
RFPA10C-6
RFPA10C-9A
