PART LIST—Model No. PFTL78007.0
To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual.
Key No. Qty.
Description
1
25
#8 x 3/4" Screw
2
4
#8 x 1" Tek Screw
3
1
Hex Key
4
6
3/8" x 2" Bolt
5
2
1/4" x 1 1/4" Bolt
6
4
3/8" x 4 1/2" Bolt
7
6
5/16" x 1 1/4" Bolt
8
8
3/8" Nut
9
4
3/8" Star Washer
10
6
5/16" Star Washer
11
5
#8 x 3/4" Tek Screw
12
2
#8 x 1/2" Screw
13
2
Base Pad Spacer
14
1
Latch Bracket
15
5
3/4" Reed Switch Screw
16
2
Rear Foot Star Washer
17
2
5/16" x 1 1/2" Bolt
18
2
5/16" x 3 5/8" Bolt
19
2
3/8" x 1 1/4" Bolt
20
2
Rear Roller Bolt
21
1
3/8" x 1 3/4" Bolt
22
1
3/8" x 1 1/2" Bolt
23
2
3/8" x 1" Bolt
24
8
1/2" Ground Screw
25
8
#12 x 1 1/4" Screw
26
2
Motor Bolt
27
1
Right Rear Foot Insert
28
1
Reset/Off Circuit Breaker
29
4
Belt Guide Screw
30
2
1/4" x 3/4" Flat Washer
31
2
1/4" Lock Washer
32
2
#8 x 1 1/2" Screw
33
2
1/4" Star Washer
34
1
Frame/Roller Ground Wire
35
1
Audio Wire
36
4
5/16" Flange Nut
37
3
Hood Clip
38
1
Upright Wire
39
1
Lift Frame Ground Wire
40
1
Left Rear Foot Insert
41
1
Left Foot Rail
42
1
Warning Decal
43
2
Platform Cushion
44
1
Walking Platform
45
1
Walking Belt
46
2
Belt Guide
47
1
Console Tray
48
2
Frame Spacer
49
3
Front Roller Spacer
50
1
Magnet
Key No. Qty.
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
30
Get other manuals https://www.bkmanuals.com
Description
1
Front Roller/Pulley
2
15 1/2" Wire Tie
1
Storage Latch
1
Latch Knob
1
Right Foot Rail
1
Frame
2
Rear Roller Bracket
1
Rear Roller
1
Left Rear Foot
1
Right Rear Foot
1
Hood
1
Drive Belt
1
Motor Isolator
1
Motor
1
Lift Frame
3
Wire Tie
1
Controller Ground Wire
1
Power Cord
1
Power Cord Grommet
1
Controller
1
Reed Switch
1
Reed Switch Clip
1
Belly Pan
1
Left Upright
1
Incline Motor
1
Left Upright Spacer
2
3/8" Jamnut
1
Right Upright
1
Right Upright Spacer
2
5/16" Cage Nut
4
Base Pad
2
Caution Decal
1
Base
2
Wheel
2
Releasable Tie
10
8" Tie
1
Access Door
4
Bolt Spacer
1
Console
1
Latch Endcap
1
Console Base
1
Plastic Tie
1
Incline Wire
1
Handrail Crossbar
1
Right Handrail
1
Left Handrail
2
Foot Rail Decal
4
Handrail Endcap
1
Left Accessory Tray
1
Key/Clip
R1007A
