Next Generation Diagnostic Platform NT726TS User's Manual V1.0

Table of Contents

Need help?

Do you have a question about the NT726TS and is the answer not in the manual?

Questions and answers

Summary of Contents for Foxwell NT726TS

Page 1 Disclaimer The information, specifications and illustrations in this manual are based on the latest information available at the time of printing. Foxwell reserves the right to make changes at any time without notice. Visit our website at www.foxwelltech.us For Technical Assistance, send us email at support@foxwelltech.com...
Page 2: One-Year Limited Warranty
FOXWELL. 3 The customer shall bear the cost of shipping the product to FOXWELL. And FOXWELL shall bear the cost of shipping the product back to the customer after the completion of service under this limited warranty.
Page 3 The customer will be billed for any parts or labor charges not covered by this limited warranty. d) FOXWELL will repair the Product under the limited warranty within 30 days after receipt of the product. If FOXWELL cannot perform repairs covered...
Page 4 (the Consumer). This limited warranty gives the Consumer specific legal rights and the Consumer may also have other rights which vary from state to state. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 5: Safety Information
● Fuel, oil vapors, hot steam, hot toxic exhaust gases, acid, refrigerant and other debris produced by a malfunction engine can cause serious injury or death. Do not use the tool in areas where explosive vapor may collect, Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 6 And never leave a running engine unattended. ● Do not wear jewelry or loose fitting clothing when working on engine. ● Don't connect or disconnect the equipments while the ignition is on or the engine is running. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 7: Table Of Contents
6 VCI MANAGER ..........................25 7 FIRMWARE UPDATE ........................27 8 VEHICLE IDENTIFICATION ......................28 8.1 V ........................29 EHICLE ONNECTION 8.2 VIN R ..........................29 EADING 8.2.1 Automatic Read ........................ 30 8.2.2 Manual Entry ........................31 Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 8 MAGE 12.2 PDF R .......................... 70 EPORT 12.3 D ........................72 LAYBACK 13 SETTINGS ............................ 74 13.1 U ............................74 NITS 13.2 L ..........................75 ANGUAGE 13.3 F ..........................75 13.4 M ........................75 ODULE ORTING Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 9 ETTINGS 13.9 G ..........................78 ENERAL 13.10 U ..................... 78 NINSTALL EHICLE OFTWARE 13.11 C ........................79 LEAR APP DATA 13.12 P ........................79 RINT ETTINGS 13.13 A ...........................81 BOUT 14 REMOTE SUPPORT ........................82 Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 10: Using This Manual
Bold text is used to highlight selectable items such as buttons and menu options. Example: Select Diagnostic from the Home screen of the NT726TS application. 1.2 Symbols and Icons 1.2.1 Solid Spot Operation tips and lists that apply to specific tool are introduced by a solid spot.
Page 11: Introduction
Do not soak scanner as water might find its way into the scanner. 2 Introduction The brand new Android scan tool NT726TS series inherits the same Foxwell advantages in car fault diagnostic tech, such as multi manufacturer coverage, service functions and accurate test data, making it the perfect tool for busy garages or workshops, who need the latest technology at unbeatable value.
Page 12 Rear-Facing Camera - takes pictures of VIN number, faulty parts and plates and shoots test videos. Speaker – outputs audio. IMPORTANT Do not use solvents such as alcohol to clean display. Use a mild nonabrasive detergent and a soft cotton cloth. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 13: Accessories
This section lists the accessories that go with the scanner. If you find any of the following items missing from your package, contact your local dealer for assistance. Figure 2-4 Accessories 2.3 Technical Specifications Item Description Screen 5.5’’ TFT Capacitive LCD screen; 1280*720 pixel Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 14: Getting Started
3.1 Powering up the Scanner Before using the NT726TS applications (including updating the scanner), please make sure to provide power to the scanner. The unit operates on any of the following sources: Internal Battery Pack ●...
Page 15: Shutting Down The Scanner
2. Click the Power off to shut down or Reboot to restart. 3.3 Screen Layout of Home Screen After the scanner turning on, the screen show main menu of the application. Figure 3-1 Sample Home Screen Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 16: Application Menu
Maintenance - leads to screens for common used special functions like ● Oil light reset, EPB, BRT, and DPF etc. Update - leads to screens for Foxwell ID registration and updating the ● scanner. Data Manager - leads to screens for saved screenshots, pictures and test ●...
Page 17: My Account
This section introduces user account registration, login, device activation and other information. When My Account application is selected, a menu with available options displays. My Account Menu options typically include: My Account ● My Products ● Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 18: Registration
You are allowed to create a Foxwell ID with the built-in client. To register with built-in client: 1. Press My Account or Update from home screen of NT726TS diagnostic application, the user login page will show, then press Free registration button to register an account.
Page 19 4. “The account has been created successfully” message will appear if you registered successfully. Figure 4-5 Sample Registration Done Screen 5. The serial number will show after registration. Click Submit to activate the product or press to back. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 20: Sign In
Figure 4-6 Sample Product Activation Screen 4.2 Sign in Press My Account or Update from home screen of NT726TS diagnostic application, the user login page will show, enter your FOXWELL ID and password, and press Sign in button to sign in.
Page 21 2.Click Submit to continue the activation and press to give up activation. Figure 4-9 Sample Product Activation Submit Screen 3. “Product is activated successfully” message will appear if activate successfully. Figure 4-10 Sample activate success Screen Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 22: M Yaccount
This option allows you to log on your e-mail and send feedback and suggestions about Foxwell products. To send feedback and suggestions about Foxwell products: 1. Press My Account from home screen of the NT726TS diagnostic application. 2. Press Feedback and Suggestions option to show Feedback page, there are two options--Diagnosis Feedback and General Feedback.
Page 23 Press Save button to save the feedback. Or press Email button to send if you have an email account. Figure 4-13 Sample Feedback Edit Screen Figure 4-14 Sample Email Select Screen Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 24: Update
The scanner can be updated to keep you stay current with the latest development of diagnosis. This section illustrates how to register and update your scan tool. You can register both on Foxwell website or by the built-in update client.
Page 25: Vci Manager
VCI. VCI unbind & rebind： 1. Click VCI Manager application on the NT726TS home screen. 2. After clicking Unbind a VCI dongle, it will display whether to unbind the current VCI. When clicking OK, it will execute unbind, rebind, and refresh the vehicle.
Page 26 Figure 6-1 Sample Unbind a VCI dongle Figure 6-2 Sample Unbinding Confirmation Prompt Figure 6-3 Sample Unbinding Current VCI Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 27: Firmware Update
Figure 6-4 Sample Bind New VCI Successfully Figure 6-5 Sample Rescan Vehicle Software 7 Firmware Update This application allows you to update the firmware of NT726TS. To update the firmware: 1. Click the Update application on the NT726TS home screen.
Page 28: Vehicle Identification
Each selection you make advances you to the next screen. Exact procedures may vary somewhat by vehicle. It typically identifies a vehicle by any of the following means: VIN Reading ● Manual Selection ● Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 29: Vehicle Connection
8.2 VIN Reading VIN button on the title bar is a shortcut for VIN reading menu, which includes Automatic Read, Manual Entry, eliminating the need for navigating through complicated car identification process. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 30: Automatic Read
(VIN). To identify a vehicle by Automatic Read: 1. Select Diagnostic from home screen of the NT726TS application. 2. Click VIN and choose Automatic Read from the option list. 3. When the scan tool builds connection with the vehicle, the VIN number displays.
Page 31: Manual Entry
Manual Entry allows to identify a vehicle by inputting VIN manually. To identify a vehicle by Manual Entry: 1. Select Diagnostic from home screen of the NT726TS application. 2. Click VIN and choose Manual Entry from the option list. 3. Press Keyboard button to input a valid VIN code and press OK to continue.
Page 32: Smart Vin
(VIN). To identify a vehicle by Smart VIN: 1. Select Diagnostic from home screen of the NT726TS application. 2. A screen with vehicle manufacturers displays. Select the area where the vehicle manufacturer from. A menu of all vehicle manufacturers displays.
Page 33: Manual Vehicle Selection
VIN characters, such as model year, and engine type. To identify a vehicle by manual vehicle selection: 1. Select Diagnostic from home screen of the NT726TS application. 2. A screen with vehicle manufacturers displays. Select the area where the vehicle manufacturer is from.
Page 34: Vehicle History
To identify a vehicle by Vehicle History: 1. Select Diagnostic from home screen of the NT726TS application. 2. Select History button at the top of the diagnostic page and the diagnostic records will display.
Page 35: Vehicle Identification
(DTCs) overview. Depending on the number of control modules, it may take a few minutes to complete the test. To perform an automatic system scan: 1. Press Quick Scan option to start. 2. To pause the scan, press the Pause button on the screen. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 36 4. Press Report to create an overview of installed control units and their system status, or press Save to save the report. Press Erase to clear the information. Figure 9-4 Sample DTC Save Screen Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 37: Control Modules
Control Modules displays all controllers available of the vehicle manufacturer. The controllers listed on the menu do not mean that they are installed on the vehicle. It is useful for technicians who are familiar with the vehicle specifications. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 38: Diagnostic Operations
Live Data ● ECU Information ● NOTE Not all function options listed above are applicable to all vehicles. Available options may vary by the year, model, and make of the test vehicle. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 39: Read Codes
DTC set. It is a good function to help determine what caused the fault. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 40: Clear Codes
To clear codes, make sure that the ignition key is switched to ON with the ● engine off. Clear Codes does not fix the problem that caused the fault! DTCs should ● only be erased after correcting the condition(s) that caused them. To clear codes: Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 41: Live Data
All Data menu lets you view all live PID data from a selected control module. To view all live PID data: 1. Press Select ALL for select all live PID data and press Deselect ALL to deselect all items. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 42 Figure 9-16 Sample Live Data Selection Screen Figure 9-17 Sample Live Data Screen Name Description Help To provide help information of a PID To Top To move a data line to the top of Data List screen Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 43 Figure 9-19 Sample Live Data Screen 3. Swipe the screen up and down to view additional information when necessary. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 44 Merge Graph: merges multiple PID plots into one coordinate, so you can ● easily see how they affect each other, providing you with the most comprehensive and functional look at live data possible. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 45 3. To deselect an item, tap the line again. Alternatively, tap SELECT ALL or Deselect ALL to select or deselect all items at once. 4. Press OK to complete the selection, and all selected items display. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 46 Figure 9-25 Sample Live Data Record Screen 2. Press Stop button to create a record, then press OK to save the record into Data Playback of Data Manager. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 47: Ecu Information
Figure 9-28 Sample ECU Information Screen Press to print the information if need be. Press to exit. 4. Press Save to store ECU information screen and Press OK to complete save or Press Cancel to give up. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 48: Complaints
9.3 Complaints This function lets the customers sending back the complaints or feedback to Foxwell server with one touch during the diagnostic process and allows for quicker and more accurate fixes for diagnostic troubles and bugs. To make a complaint: Click during the diagnostic process when face a failure.
Page 49: Maintenance
Figure 9-31 Sample Compliant Sheet Screen 3.Press Upload to send to Foxwell server directly when connecting with Wifi or Press Save to save the complaint and send to us later.(The saved complaint can be found at Data Manager--Data Record menu.) Press Email to share or PDF to print.
Page 50: Electronic Parking Brake (Epb) Service
Mercedes SBC vehicles - allows to change brake fluid/bleed brake system. Perform service reset and service position on BMW EPB vehicles - ● allows to do the CBS reset and CBS correction for front brake and rear brake. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 51: Battery Replacement (Brt)
2. Connect the scanner to the vehicle’s 16 pin Data Link Connector (DLC) with the diagnostic cable. 3. Boost the device and select BRT; it will display all the vehicle makes available. Choose your vehicle make and follow the scanner instruction to start. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 52: Diesel Particulate Filter (Dpf) Regeneration
SAS Calibration menu lets you perform calibration of the Steering Angle Sensor, which permanently stores the current steering wheel position as straight-ahead in the sensor EEPROM. On successful calibration of the sensor, its fault memory is automatically cleared. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 53: Continuous Variable Transmission (Cvt)
Air is compressible, so when the brakes are applied any air bubbles in the system must first be compressed before the hydraulic fluid will transmit pressure to apply the brakes. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 54: Key Programming/Immobilizer
11 TPMS Service Operations The TPMS application is used to check the TPMS sensor conditions, program the Foxwell sensor T10, perform the TPMS Relearn procedure and basic TPMS diagnostic functions. 11.1 Navigation Tap the TPMS button from the home menu, the Vehicle Menu will appear.
Page 55: Trigger Operations
To Trigger TPMS sensor Tap Trigger Tab. Tap the desired wheel position on the vehicle thumbnail. Hold the Display Tablet with the symbol (in the top right corner) close to the tire Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 56 Figure 11-5 Possible results for triggering 11.2 Programming Operations The programming function is used to program the sensor data to the Foxwell sensor T10 and replace the faulty senor (poor battery life or malfunction). The Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 57 NT726TS is easy to use with a proven efficiency and guaranteed accurate results. There are four options available when programming Foxwell sensor T10 using the Display Tablet: Manual Create, Clone by Activation, Automatic Create (1-16), Clone by OBD. Figure 11- 6 Sample Programming Function Screen Main Section Column 1 –...
Page 58 3. Tap Manual Create button. 4. Enter the characters in the prompted screen. Tap OK to finish and save the sensor ID, or Cancel to exit. Figure 11-7 Sample ID Input Screen Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 59 Place the proper Foxwell sensor T10 near the top right of the Display Tablet to start programming. Figure 11-8 Sample Manual Create Function Screen If multiple sensors were detected, will pop up message to remind remove the excess sensors. Figure 11-9 Sample Manual Create Function Screen...
Page 60 11.2.2 Clone by Activation This function allows user to bypass OBD II and automatically write in the retrieved original sensor data to the Foxwell sensor T10. It is used after the original sensor is triggered. To perform Clone by Activation, user needs active the installed sensor firstly, if succeed, the sensor ID will display.
Page 61 Select the specific wheel on the screen. Tap the Automatic Create functional button on the screen. Place the proper Foxwell sensor T10 near the top right of the Display Tablet to write the new created sensor ID into the Foxwell sensor T10.
Page 62 Column 2 of the table. 11.2.4 Copy by OBD This function allows users to write the saved sensor information into Foxwell sensor T10 after performing Copy by OBD function, the sensor ID will appear on the table in Programming screen. Select the specific wheel on the screen, and then tap Copy by OBD button.
Page 63: Learn Help
Figure 11-13 Sample Copy by OBD Function Screen Place the proper Foxwell sensor T10 near the top right of the Display Tablet, and tap OK to start programming the saved sensor information to the Foxwell T10. The programmed sensor ID will appear on Column 2 of the table.
Page 64 (the tire pressure light is off). NOTE: Different models have different OBD relearn methods. Please read the relearn procedure carefully before performing the relearn function. 11.3.2 Automatic Relearn Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 65 (the tire pressure light is off). NOTE: Different models have different Automatic relearn methods. Please read the relearn procedure carefully before performing the relearn function. 11.3.3 Static Relearn Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 66 Use one of the following method to copy according to the actual situation. 1. Copy by activation 2. Copy by manually input the sensor IDs. (notice the data format is decimal or hexadecimal) Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 67: Data Manager
12.1 Image Image option leads to screens for review of stored screenshots. In case a failure of NT726TS application or the Android system occurs, please just take a screenshot and send it to our team to help with the troubleshooting.
Page 68 Figure 12-3 Sample Screenshot Screen 2. Add a description of the image, and press the OK to save or press cancel button to give up. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 69 Figure 12-4 Sample Screenshot Screen 12.1.2 Review Image To review the screenshots: 1. Press Data Manager from home screen of NT726TS diagnostic application. 2. Press Image from Data Manager. 3. Press Diagnostic Screenshot for application menu screenshot or Press System Screenshot for system menu screenshot, then all available pictures will be displayed.
Page 70: Pdf Report
PDF icon on the test screen, add a description and press OK button to save. 12.2.1 How to Create a PDF Report To create a PDF report: 1. Press Data Manager from home screen of NT726TS diagnostic application. 2. Press Report from Data Manager. 3. Press any reports saved.
Page 71 Email to share the report. Figure 12-10 Sample of Report edit Screen 12.2.2 Review PDF Report To review the PDF reports: 1. Press Data Manager from home screen of NT726TS diagnostic application. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 72: Data Playback
Playback speed and direction (forward or reverse) can also be controlled. To review recorded live data: 1. Press Data Manager from home screen of NT726TS diagnostic application. 2. Press Data Playback and all available records display.
Page 73 5. To move forward or reverse back of the playing, just drag the progress bar forward or reverse. Press the button to stop. 6. Long press the record to Rename or Delete the records. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 74: Settings
Selecting Unit opens a dialog box that allows you to choose between Imperial customary or metric units of measure. To change the unit setup: 1. Press Settings from home screen of the NT726TS diagnostic application. 2. Press Unit and available unit system display. 3. Select a unit system.
Page 75: Language
Select Language opens a screen that allows you to choose system language. To configure system language: 1. Press Settings from home screen of the NT726TS diagnostic application and select Language. Then all available language options display. 2. Select your preferred language to change.
Page 76 Figure 13-4 Sample Release and Dwell Update Module 3. Click to display whether to apply the current settings interface, click OK to apply the current changes, click Cancel to discard the current changes. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 77: Sort Tiles
This option allows you to change the sort for Brand of vehicles. There are two sorting methods available by alphabet or by frequency of use. To change sort 1. Press Settings from home screen of the NT726TS diagnostic application, and select Sort Tiles. 2. Select your preferred sort order.
Page 78: Automatic Update
1. Press Settings from home screen of the NT726TS diagnostic application, then select Remote control. 2. Select your preferred tool. 13.7 Automatic Update This option allows you to enable/disable automatic update notice. If it is enabled, an orange update mark will show on the upper right of the diagnostic software icon whenever there is a new version available.
Page 79: Clear App Data
This option allows you to print any data or information anywhere and anytime either via PC network or Wi-Fi. To setup the printer connection: 1. Tap the Settings application on home screen of NT726TS. 2. Tap the Printing Settings option on the option list. Figure 13-9 Sample Print Settings Screen 3.
Page 80 Figure 13-11 Sample Setting of Print Service Manager Screen 5. Choose the right printer. Press for return. Figure 13-12 Sample of Printer Screen 6. Select a available printer, then press PRINT TEST PAGE button at the right-bottom. Press for return. Next Generation Diagnostic Platform NT726TS User's Manual V1.0...
Page 81: About
Figure 13-14 Sample of File Printing Screen NOTE 1. Please make sure the printer and the NT726TS in the same Wi-Fi or Network when printing. 2. If Mopria Print Service driver can’t workable for your printer, please download the driver to work for your printer on Print Service Manager.
Page 82: Remote Support
About how to set the tool of default, please refer to 12.5 Remote control. To use QuickSupport for to remote control: 1. Click the Remote Control icon on the main menu of the NT726TS to start TeamViewer QuickSupport. Press for return.
