Trademarks
FOXWELL is trademark of Shenzhen Foxwell Technology Co., Ltd.
All other marks are trademarks or registered trademarks of their respective holders.
Copyright Information
© 2015 Shenzhen Foxwell Technology Co., Ltd.
All rights reserved.
Disclaimer
The information, specifications and illustrations in this manual are based on the latest information
available at the time of printing.
Foxwell reserves the right to make changes at any time without notice.
Visit our website at:
www.foxwelltech.com
For Technical Assistance, send us email at
support@foxwelltech.com
1
AutoMaster Pro NT414 Manual_English_V1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NT414 and is the answer not in the manual?

Questions and answers

Related Manuals for Foxwell NT414

Summary of Contents for Foxwell NT414

  • Page 1 Disclaimer The information, specifications and illustrations in this manual are based on the latest information available at the time of printing. Foxwell reserves the right to make changes at any time without notice. Visit our website at: www.foxwelltech.com For Technical Assistance, send us email at support@foxwelltech.com...

  • Page 2: One-Year Limited Warranty

    The customer will be billed for any parts or labor charges not covered by this limited warranty. d) FOXWELL will repair the Product under the limited warranty within 30 days after receipt of the product. If FOXWELL cannot perform repairs covered under this limited warranty within 30 days,...
  • Page 3 OF THE PRODUCT OR ARISING FROM BREACH OF THE WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, STRICT TORT, OR ANY OTHER LEGAL OR EQUITABLE THEORY, EVEN IF FOXWELL KNEW OF THE LIKELIHOOD OF SUCH DAMAGES. FOXWELL SHALL NOT BE LIABLE FOR DELAY IN RENDERING SERVICE UNDER THE LIMITED WARRANTY, OR LOSS OF USE DURING THE PERIOD THAT THE PRODUCT IS BEING REPAIRED.

  • Page 4: Safety Information

    Block drive wheels before testing with engine running. Put the transmission in park (for ● automatic transmission) or neutral (for manual transmission). And never leave a running engine unattended. Do not wear jewelry or loose fitting clothing when working on engine. ● AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 5: Table Of Contents

    4.2.1 Auto Scan............................17 4.2.2 Control Unit............................18 4.3 D ......................19 IAGNOSTIC UNCTION ELECTION 4.3.1 Read Codes............................19 4.3.2 Freeze Frame Data..........................21 4.3.3 Erase Codes............................. 21 4.3.4 ECU Information..........................22 4.3.5 Live Data............................23 4.3.5.1 Complete Data List........................23 AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 6 7.1 S .............................46 ELECT ANGUAGE 7.2 C ............................47 HANGE NITS 7.3 C ..........................48 ONFIGURE EEPER 7.4T ...............................48 EYPAD 7.5 LCD K .............................. 49 EYPAD 7.6 T ............................50 NFORMATION 7.7 C ........................50 ONFIGURE HORTCUT AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 7: Using This Manual

    Test results do not necessarily indicate a faulty component or system. Important IMPORTANT indicates a situation which, if not avoided, may result in damage to the test equipment or vehicle. Example: IMPORTANT Do not soak keypad as water might find its way into the scanner. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 8: Introduction

    2 Introduction AUTOMASTER PRO series scanners from Foxwell are innovative diagnostic tools for most vehicles on the road today. With the tool properly connected to the vehicle’s data link connector (DLC), you can use the scanner to read diagnostic trouble codes and view “live” data readings from all electronic vehicle control systems, such as engine, ABS, and instrument cluster.

  • Page 9: Accessory Descriptions

    2. Attached the diagnostic cable to the scanner and tighten the captive screws to ensure good connection. 3. Connect a correct adapter to the data cable according to the vehicle being serviced and plug it into the vehicle DLC. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 10: Connecting To Personal Computer With Usb Cable

    DTC number. Typically, you may be required to input letters or numbers when you are doing any of the following operations. VIN entry ● input channel number ● set adaptation value ● AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 11 Figure 3-3 Sample Numeric Keyboard Screen 3. To delete a letter or number, use the function key Previous to move the cursor to it and then press the Backspace button. 4. When finished the entry, press Finish key to continue. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 12: Diagnostic Operations

    Figure 4-1 Sample Application Menu 2. A screen with vehicle manufacturer areas displays. Select the area where the vehicle manufacturer is from. A menu of all vehicle manufacturers from this area displays. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 13 4. Select Vin acquisition from the menu, and press the ENTER key. Figure 4-4 Sample Vin Acquisition Screen 5. The scan tool starts to communicate with the vehicle and read the Vehicle Specification or VIN Code automatically. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 14: Manual Vin Entry

    Manual VIN Entry identifies a vehicle by manually inputting a 17-digit VIN code. To identify a vehicle by manual VIN entry: 1. Refer to Step 1-3 of 4.1.1 Automatic VIN Acquisition. 2. Select a appropriate option from the menu. A virtual keyboard opens for VIN entry. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 15: Manual Vehicle Selection

    The Vehicle Record option will not show if no record of previously identified vehicle is created. To create a vehicle record: 1. Identify the vehicle by any of the means above, and run an automatic system test by selecting Auto Scan. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 16 3. Enter a unique name for this vehicle and save it, and you will see this new vehicle in Vehicle Data Recorder menu. Figure 4-11 Sample Vehicle Record Screen To identify a previously tested vehicle: 1. Select Vehicle record and press the ENTER key to start. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 17: System Selection

    2. To pause the scan, press the function key corresponding with Pause on the screen. Figure 4-14 Sample Automatic system scan screen 3. At the end of successful automatic controller scan, a menu with a list of installed controllers together with their DTC overview displays. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 18: Control Unit

    Figure 4-17 Sample Function Menu screen 4.2.2 Control Unit Control Unit screen displays all controllers available of the vehicle manufacturer. The controllers listed on the menu do not mean that they are installed on the vehicle. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 19: Diagnostic Function Selection

    A “The selected mode is not supported!” message displays if the option is not applicable to the vehicle under test. 4.3.1 Read Codes Read Codes menu lets you read trouble codes found in the control unit. Typical menu options include: AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 20 2. Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. Figure 4.21 Sample Code Screen AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 21: Freeze Frame Data

    Erase Codes does not fix the problem that caused the fault! DTCs should only be erased after ● correcting the condition(s) that caused them. To clear codes: 1. Scroll with the arrow keys to highlight Erase Codes from Function Menu and press the ENTER key. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 22: Ecu Information

    ECU Information screen displays the identification data of the control module under test, such as the control module identification string and the control module coding. To read ECU information: 1. Select ECU Information from the menu and press the ENTER key. Figure 4-25 Sample Function Menu Screen AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 23: Live Data

    1. Scroll with the arrow keys to highlight Live Data from the menu and press the ENTER key to display the live data menu. Figure 4-27 Sample Live Data Selection Screen 2. Select the Complete List from the menu and press the ENTER key to display the datastream screen. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 24 4. Press the function key Two Graphics to display two PID graphs in one screen. Figure 4-30 Sample Two PID Graph Screen 5. Press the function key Merge Graph to display two PID plots in one coordinate for easy and intuitive diagnosis. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 25: Custom Data List

    Figure 4-32 Sample Live Data Screen 2. The custom datastream selection screen displays. Scroll with the up and down arrow keys to highlight a line, press the ENTER key and then repeat the action to make more selections. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 26: Obdii/Eobd Operations

    When OBDII/EOBD application is selected from Home screen, the scanner starts to detect the communicaiton protocol autometically. Once the connection has established, a menu that lists all of the tests available on the identified vehicle displays. Menu options typically include: System Status ● AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 27: System Status

    1. Scroll with the arrow keys to highlight System Status from Diagnostic Menu and press the ENTER key. Figure 5-1 Sample Diagnostic Menu Screen 2. A screen with detailed information displays. Figure 5-2 Sample System Status Screen AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 28: Read Codes

    Figure 5-4 Sample Read Codes Screen If no DTCs are present the message “No (Pending) Codes Found!” is displayed. If any manufacturer specific or enhanced codes detected, select vehicle a make before viewing DTC information. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 29: Erase Codes

    Erase Codes does not fix the problem that caused the fault! DTCs should only be erased after ● correcting the condition(s) that caused them. To clear codes: 1. Scroll with the arrow keys to highlight Erase Codes from Diagnostic Menu and press the ENTER key. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 30: Live Data

    Complete Data List menu lets you view all live PID data from a selected system. To view all live PID data: 1. Scroll with the arrow keys to highlight Live Data from Diagnostic Menu and press the ENTER key. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 31 4. Scroll with the up and down arrow keys to highlight a line, if the One Graphic on the bottom is highlighted, it indicates the graphing is available for the selected line. Press the function key One Graphic to display the PID graph. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 32 8. Select Text to return to text viewing of PID data. 9. Press Pause to suspend collecting data and use the Start key to resume collecting data. 10.Use the Back key to return to diagnostic menu. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 33: Custom Data List

    To deselect an item, select it again and then press the ENTER key. Alternatively, use the function keys SELECT ALL and CLEAR ALL to select or deselect all items at once. 3. When finished selection, use the function key VIEW DATA to display selected items. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 34: Freeze Frame

    2. Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. If no freeze frame detected, the message “No freeze frame data stored!” is displayed. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 35: Read I/M Readiness Status Data

    1. Scroll with the arrow keys to highlight I/M Readiness from Diagnostic Menu and press the ENTER key. If vehicle supports both types of monitors, a screen for monitor type selection displays. Select a monitor type and press the ENTER key. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 36 Figure 5-21 Sample IM Readiness Screen 1 Figure 5-22 Sample IM readiness screen 2 3. Press the BACK key to exit. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 37: O2 Monitor Test

    Figure 5-24 Sample O2 Monitor Test screen 3. Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 38: On-Board Monitor Test

    Test results do not necessarily indicate a faulty component or system. To request on-board monitor test results: 1. Scroll with the arrow keys to highlight On-Board Monitor Test from Diagnostic Menu and press the ENTER key. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 39 Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. For non-CAN vehicles, test screen is illustrated as below: AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 40: Component Test

    To perform a component test: 1. Scroll with the arrow keys to highlight Component Test from Diagnostic Menu and press the ENTER key. A screen with a list of available tests displays. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 41: Request Vehicle Information

    NOTE Available options will vary depending on the vehicle under test. To request vehicle information: 1. Scroll with the arrow keys to highlight Vehicle Info. from Diagnostic Menu and press the ENTER key. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 42 3. Scroll with the arrow keys to highlight an available option and press the ENTER key. A screen with details of the selected option displays. Figure 5-36 Sample Calibration ID Screen 4. Press function key Save to store the readiness data. Or use the BACK key to exit and return. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 43: Modules Present

    5.12 DTC Lookup DTC Lookup menus allows to request DTC definitions stored in the scan tool. To Look up DTCs: 1. Scroll with the arrow keys to highlight DTC Lookup. from Diagnostic Menu and press the ENTER key. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 44 Manufacturer Specific), the scanner displays “DTC definition not found! Please refer to vehicle service manual!” If a P1xxx, C1xxx, B1xxx or U1xxx code is entered, select a vehicle make to look for DTC definitions. Press the Back key to exit. Figure 5-41 Sample Trouble Codes Screen AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 45: Playback Data

    3. Scroll with the arrow keys to highlight a vehicle record and press the ENTER key. Details of the test record displays. Use the up and down arrow keys to scroll through data to select lines. Figure 6-3 Sample Test Data Details Screen AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 46: System Setup

    Selecting Language opens a screen that allows you to choose system language. The scan tool is set to display English menus by default. To configure system language: 1. Scroll with the arrow keys to highlight Language from Setup menu and press the ENTER key. Figure 7-1 Sample Setup Screen AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 47: Change Units

    1. Scroll with the arrow keys to highlight Units from Setup menu and press the ENTER key. Figure 7-3 Sample Setup Screen 2. Press the LEFT/RIGHT arrow key select an item and press the ENTER key to save and return. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 48: Configure Beeper

    Selecting Key Test option opens a screen that allows you to check the functionality of the keypad. To test the keypad: 1. Scroll with the arrow keys to highlight Key Test from Setup menu and press the ENTER key. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 49: Lcd Keypad

    To test the display: 1. Scroll with the arrow keys to highlight LCD Test from Setup menu and press the ENTER key to start test. Check if there are any missing spots in the LCD screen. AutoMaster Pro NT414 Manual_English_V1.00...

  • Page 50: Tool Information

    Selecting Shortcuts option lets you to change the functionality of the shortcut buttons. To assign a function to a shortcut button: 1. Scroll with the arrow keys to highlight Shortcuts from Setup menu and press the ENTER key. A screen with available shortcut keys displays. AutoMaster Pro NT414 Manual_English_V1.00...
  • Page 51 Figure 7-13 Sample ShortCuts Screen 3. Scroll with the UP/DOWN arrow keys to highlight an application and press the ENTER key to assign the application to the shortcut key. 4. Press any key to exit and return. AutoMaster Pro NT414 Manual_English_V1.00...
