  6. Operating and service manual

AR ATH200M1G Operating And Service Manual

Hide thumbs
Table of Contents
  • Table of Contents
  • General Information
  • General Description
  • Specifications
  • Performance Data
  • Installation
  • RF Connections
  • RF Power Amplifier
  • General Caution Notes
  • Typical Curves
  • Vswr
  • Typical Gain
  • E Plane Pattern Frequency - 200 Mhz
  • H Plane Pattern, Frequency - 200 Mhz
  • E Plane Pattern Frequency - 300 Mhz
  • H Plane Pattern Frequency - 300 Mhz
  • E Plane Pattern Frequency - 400 Mhz
  • H Plane Pattern Frequency - 400 Mhz
  • E Plane Pattern Frequency - 600 Mhz
  • H Plane Pattern Frequency - 600 Mhz
  • E Plane Pattern Frequency - 800 Mhz
  • H Plane Pattern Frequency - 800 Mhz
  • E Plane Pattern Frequency - 1000 Mhz
  • H Plane Pattern Frequency - 1000 Mhz
  • Outline Drawing
  • Polarization of Horn Antennas

Advertisement

Available languages

Available languages

Quick Links

Download this manual
Operating and
Service Manual
ATH200M1G
Model
10009125
Part Number
Serial Number
160 School House Road, Souderton, PA 18964 • 215-723-8181 • Fax 866-856-0582 • www.arworld.us

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATH200M1G and is the answer not in the manual?

Questions and answers

Related Manuals for AR ATH200M1G

Summary of Contents for AR ATH200M1G

  • Page 1 Operating and Service Manual ATH200M1G Model 10009125 Part Number Serial Number 160 School House Road, Souderton, PA 18964 • 215-723-8181 • Fax 866-856-0582 • www.arworld.us...
  • Page 3 OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 18 December 2006 concerning the Registration, Evaluation, Authorization and Restriction of Substances of Very High Concern Chemicals (SVHC) Supporting documentation is held by AR RF/Microwave Instrumentation’s Quality department in Pennsylvania, United States. Place of issue:...
  • Page 5 The caution symbol denotes a potential hazard. Attention must be given to the statement to prevent Your AR equipment may have more than one power supply cable. Use damage, destruction, or harm. only approved power cable(s). If you have not been provided with a Dangerous voltages are present.
  • Page 6 EQUIPMENT CONTAINING LASERS risk of serious injury due to unsafe AR Field Probes (FL/PL Series) and Field Analyzers (FA product handling should be a fundamental Series) are Class 1 laser products containing embedded consideration every user.
  • Page 7 Zur Vermeidung von Personen- oder Sachschäden gilt BEVOR SIE DAS GERÄT ANSCHLIESSEN es, die Hinweise zu beachten. Ihre AR-Ausrüstung hat möglicherweise mehr als ein Stromversorgungskabel. Gefährliche elektrische Spannungen sind vorhanden. Verwenden Sie nur zugelassene Stromkabel. Falls Sie kein Stromkabel oder Höchste Vorsicht ist geboten.
  • Page 8 Die meisten Geräte müssen während des Versands, der Montage und des Gebrauchs LASER-INFORMATION transportiert werden. Jeder Nutzer sollte sich AR - Feldsonden (FL/PL-Serie) und Feldanalysatoren (FA-Serie) über das Risiko von schweren Verletzungen sind Laserprodukte der Klasse 1 mit eingebetteten Klasse-4- durch unsachgemäße...
  • Page 9 électrode de mise à la Votre équipement AR peut disposer de plus d’un câble d’alimentation terre de protection. électrique. Utilisez uniquement un ou des câbles d’alimentation approuves.
  • Page 10 éliminer le risque injustifié de blessures causées par le levage est fournie par les méthodes de travail de NIOSH (publication Les sondes de champ AR (série FL/PL) et les analyseurs de n° 94-110) disponibles sur : champ (série FA) sont des produits laser de classe 1 contenant des lasers intégrés de classe 4.
  • Page 11 Er zijn gevaarlijke elektrische spanningen aanwezig. Wees uiterst voorzichtig. VOOR HET OPZETTEN VAN DE STROOM Uw AR-apparatuur kan meer dan een netvoedingskabel bezitten. Gebruik alleen goedgekeurde netvoedingskabel(s). Koopt een Wijst op een terminal aan die bedoeld is voor aansluiting netvoedingskabel die is goedgekeurd voor gebruik in uw land als u...
  • Page 12 APPARAAT DAT LASERS BEVAT distributie, de assemblage en het gebruik moeten worden behandeld, moet het risico AR-terreinsondes (FL/PL-serie) en terreinanalysatoren (FA- op ernstig letsel als gevolg van een serie) zijn laserproducten van klasse 1 met ingesloten onveilige behandeling van het product een klasse 4-lasers.

  • Page 13: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ....................i GENERAL INFORMATION ................1 General Description ................... 1 Specifications ....................1 Performance Data ....................1 Installation ......................1 1.4.1 RF Connections ....................1 1.4.2 RF Power Amplifier ................... 1 1.4.3 General Caution Notes ..................1 TYPICAL CURVES ..................
  • Page 14 Model ATH200M1G...

  • Page 15: General Information

    The coaxial cable should be terminated with the appropriate male connector (UG A/u or equivalent) in order to mate with the female connector provided on the antenna. Refer to the AR Data Sheet for the connector used on your model.
  • Page 16 3.34 mW/cm (safe operating level) When operating the ATH200M1G Antenna at 1000MHz at 1000 watts input, the power density is 520 mW/cm. This is approximately 155 times more than the 3.34 mW/cm specified in ANSI 95.1-1982 as a safe level with respect to human exposure to RF fields.
  • Page 17 RF test system - losses which generally increase with frequency. The Model ATH200M1G is well suited for either shielded room or free space testing. Optimum performance is achieved when it is used with our Model 2000W1000 or for even higher fields, our Model 3000W1000 broadband amplifier for RF susceptibility testing.
  • Page 18 POWER VS. FREQUENCY ATH200M1G/M2 ATH200M1GM1/M3 ATH200M1GM4/M5 1000 FREQUENCY (MHz) Field strengths have been measured in free-space conditions. Individual shielded rooms, amplifiers, and test-system conditions will influence performance. Field strength also varies with frequency and position of antenna and EUT in non-anechoic testing environments.

  • Page 19: Typical Curves

    2. TYPICAL CURVES VSWR Model ATH200M1G Antenna, Typical VSWR Rev C...

  • Page 20: Typical Gain

    Model ATH200M1G TYPICAL GAIN Rev C...

  • Page 21: E Plane Pattern Frequency - 200 Mhz

    Model ATH200M1G 2.3. E PLANE PATTERN FREQUENCY – 200 MHZ Rev C...

  • Page 22: H Plane Pattern, Frequency - 200 Mhz

    Model ATH200M1G H PLANE PATTERN, FREQUENCY – 200 MHZ Rev C...

  • Page 23: E Plane Pattern Frequency - 300 Mhz

    Model ATH200M1G E PLANE PATTERN FREQUENCY – 300 MHZ Rev C...

  • Page 24: H Plane Pattern Frequency - 300 Mhz

    Model ATH200M1G H PLANE PATTERN FREQUENCY – 300 MHZ Rev C...

  • Page 25: E Plane Pattern Frequency - 400 Mhz

    Model ATH200M1G E PLANE PATTERN FREQUENCY – 400 MHZ Rev C...

  • Page 26: H Plane Pattern Frequency - 400 Mhz

    Model ATH200M1G H PLANE PATTERN FREQUENCY – 400 MHZ Rev C...

  • Page 27: E Plane Pattern Frequency - 600 Mhz

    Model ATH200M1G E PLANE PATTERN FREQUENCY – 600 MHZ Rev C...

  • Page 28: H Plane Pattern Frequency - 600 Mhz

    Model ATH200M1G 2.10 H PLANE PATTERN FREQUENCY – 600 MHZ Rev C...

  • Page 29: E Plane Pattern Frequency - 800 Mhz

    Model ATH200M1G 2.11 E PLANE PATTERN FREQUENCY – 800 MHZ Rev C...

  • Page 30: H Plane Pattern Frequency - 800 Mhz

    Model ATH200M1G 2.11 H PLANE PATTERN FREQUENCY – 800 MHZ Rev C...

  • Page 31: E Plane Pattern Frequency - 1000 Mhz

    Model ATH200M1G 2.12 E PLANE PATTERN FREQUENCY – 1000 MHZ Rev C...

  • Page 32: H Plane Pattern Frequency - 1000 Mhz

    Model ATH200M1G 2.13 H PLANE PATTERN FREQUENCY – 1000 MHZ Rev C...

  • Page 33: Outline Drawing

    3. OUTLINE DRAWING Rev C...
  • Page 34 Model ATH200M1G Rev C...

  • Page 35: Polarization Of Horn Antennas

    4. POLARIZATION OF HORN ANTENNAS Rev C...
  • Page 36 Model ATH200M1G Rev C...
  • Page 37 These modules are not field-repairable and should never be opened outside of AR’s Microelectronics Lab. The modules in these product lines have a security label on two sides of the modules between the housing and lid/cover. If the security label is removed and or cut, the warranty of the module will be voided.
