AR ATH Series Operating And Service Manual
High-gain horn antenna
Hide thumbs
Also See for ATH Series:
- Operating and service manual (38 pages) ,
- Operating and service manual (26 pages) ,
- Operating and service manual (24 pages)
Related Manuals for AR ATH Series
Summary of Contents for AR ATH Series
- Page 1 Operating and Service Manual ATH7G18 Model 10006310 Part Number Serial Number 160 School House Road, Souderton, PA 18964 • 215-723-8181 • Fax 866-859-0582 • www.arworld.us...
- Page 3 REGULATION (EC) 1907/2006 OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 18 December 2006 concerning the Registration, Evaluation, Authorization and Restriction of Substances of Very High Concern Chemicals (SVHC) Supporting documentation is held by AR RF/Microwave Instrumentation’s Quality department in Pennsylvania, United States. Place of issue:...
- Page 5 The caution symbol denotes a potential hazard. Attention must be given to the statement to prevent Your AR equipment may have more than one power supply cable. Use damage, destruction, or harm. only approved power cable(s). If you have not been provided with a Dangerous voltages are present.
- Page 6 EQUIPMENT CONTAINING LASERS risk of serious injury due to unsafe AR Field Probes (FL/PL Series) and Field Analyzers (FA product handling should be a fundamental Series) are Class 1 laser products containing embedded consideration every user.
- Page 7 Zur Vermeidung von Personen- oder Sachschäden gilt BEVOR SIE DAS GERÄT ANSCHLIESSEN es, die Hinweise zu beachten. Ihre AR-Ausrüstung hat möglicherweise mehr als ein Stromversorgungskabel. Gefährliche elektrische Spannungen sind vorhanden. Verwenden Sie nur zugelassene Stromkabel. Falls Sie kein Stromkabel oder Höchste Vorsicht ist geboten.
- Page 8 Die meisten Geräte müssen während des Versands, der Montage und des Gebrauchs LASER-INFORMATION transportiert werden. Jeder Nutzer sollte sich AR - Feldsonden (FL/PL-Serie) und Feldanalysatoren (FA-Serie) über das Risiko von schweren Verletzungen sind Laserprodukte der Klasse 1 mit eingebetteten Klasse-4- durch unsachgemäße...
- Page 9 électrode de mise à la Votre équipement AR peut disposer de plus d’un câble d’alimentation terre de protection. électrique. Utilisez uniquement un ou des câbles d’alimentation approuves.
- Page 10 éliminer le risque injustifié de blessures causées par le levage est fournie par les méthodes de travail de NIOSH (publication Les sondes de champ AR (série FL/PL) et les analyseurs de n° 94-110) disponibles sur : champ (série FA) sont des produits laser de classe 1 contenant des lasers intégrés de classe 4.
- Page 11 Er zijn gevaarlijke elektrische spanningen aanwezig. Wees uiterst voorzichtig. VOOR HET OPZETTEN VAN DE STROOM Uw AR-apparatuur kan meer dan een netvoedingskabel bezitten. Gebruik alleen goedgekeurde netvoedingskabel(s). Koopt een Wijst op een terminal aan die bedoeld is voor aansluiting netvoedingskabel die is goedgekeurd voor gebruik in uw land als u...
- Page 12 APPARAAT DAT LASERS BEVAT distributie, de assemblage en het gebruik moeten worden behandeld, moet het risico AR-terreinsondes (FL/PL-serie) en terreinanalysatoren (FA- op ernstig letsel als gevolg van een serie) zijn laserproducten van klasse 1 met ingesloten onveilige behandeling van het product een klasse 4-lasers.
-
Page 13: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ....................i GENERAL INFORMATION ................1 General Description ................... 1 Specifications ....................1 Performance Data ....................1 Installation ......................1 1.4.1 RF Connection ....................1 1.4.2 RF Power Amplifier ................... 1 1.4.3 General Caution Notes ..................2 Typical Curves .................... -
Page 15: General Information
This versatile antenna works equally well as a radiator for RF susceptibility testing or as a receiving antenna for emissions testing. SPECIFICATIONS Refer to AR RF/Microwave Instrumentation Data Sheet on the next page for detailed specifications. PERFORMANCE DATA Typical Model ATH7G18 Antenna Gain Curve is included. -
Page 16: General Caution Notes
Model ATH7G18 1.4.3 General Caution Notes The Model ATH7G18 Antenna is capable of producing output voltages which are dangerous to human life as well as causing serious RF burns. Never walk in front of the horn when it is radiating. Operation of this antenna and associated equipment should only be performed by the personnel thoroughly familiar with the hazards inherent to this type of equipment. - Page 17 2800 watts maximum ATH7G18M3 Side launch adapter to Type N (f), gain enhancer 500 watts maximum permanently attached Approved for public release by AR RF/Microwave Instrumentation 040914 160 School House Road Souderton, PA 18964-9990 • 215-723-8181 • www.arworld.us Page 1 of 4...
- Page 18 Field Strengths have been measured in free-space conditions. Individual shielded rooms, amplifiers, and test-system conditions will Influence performance. Field Strength also varies with frequency and position of antenna and EUT in non-anechoic testing environments. ATH7G18 Gain (dBi) 25.0 20.0 15.0 10.0 without Gain Enhancer With Gain Enhancer...
- Page 19 ATH7G18 With Gain Enhancer @ 1 meter 1000.00 10000 50 WATT 2000 WATT 20 WATT 1000 WATT 10 WATT 500 WATT 1000 100.00 5 WATT 200 WATT 2 WATT 100 WATT 1 WATT 10.00 Frequency [GHz] ATH7G18 Without Gain Enhancer @ 3 meters 100.00 1000 50 WATT...
- Page 20 ATH7G18 With Gain Enhancer @ 3 meters 1000.00 10000 50 WATT 2000 WATT 1000 100.00 20 WATT 1000 WATT 10 WATT 500 WATT 5 WATT 200 WATT 2 WATT 100 WATT 1 WATT 10.00 Frequency [GHz] Model ATH7G18 FREQUENCY (GHz) with Enhancer Basic Antenna Page 4 of 4...
-
Page 21: Typical Curves
2. Typical Curves GAIN, VSWR AND 3DB BEAMWIDTH Rev C... -
Page 22: Gain Vs. Frequency
Model ATH7G18 GAIN VS. FREQUENCY Rev C... -
Page 23: E Plane Radiation Pattern @ 8.0Ghz
Model ATH7G18 E PLANE RADIATION PATTERN @ 8.0GHZ Rev B... -
Page 24: H Plane Radiation Pattern @ 8.0Ghz
Model ATH7G18 H PLANE RADIATION PATTERN @ 8.0GHZ Rev C... -
Page 25: E Plane Radiation Pattern @ 9.0Ghz
Model ATH7G18 E PLANE RADIATION PATTERN @ 9.0GHZ Rev B... -
Page 26: H Plane Radiation Pattern @ 9.0Ghz
Model ATH7G18 H PLANE RADIATION PATTERN @ 9.0GHZ Rev C... -
Page 27: E Plane Radiation Pattern @ 10.0Ghz
Model ATH7G18 E PLANE RADIATION PATTERN @ 10.0GHZ Rev B... -
Page 28: H Plane Radiation Pattern @ 10.0Ghz
Model ATH7G18 H PLANE RADIATION PATTERN @ 10.0GHZ Rev C... -
Page 29: E Plane Radiation Pattern @ 12.0Ghz
Model ATH7G18 E PLANE RADIATION PATTERN @ 12.0GHZ Rev B... -
Page 30: H Plane Radiation Pattern @ 12.0Ghz
Model ATH7G18 2.10 H PLANE RADIATION PATTERN @ 12.0GHZ Rev C... -
Page 31: E Plane Radiation Pattern @ 14.0Ghz
Model ATH7G18 2.11 E PLANE RADIATION PATTERN @ 14.0GHZ Rev B... -
Page 32: H Plane Radiation Pattern @ 14.0Ghz
Model ATH7G18 2.12 H PLANE RADIATION PATTERN @ 14.0GHZ Rev C... -
Page 33: E Plane Radiation Pattern @ 16.0Ghz
Model ATH7G18 2.13 E PLANE RADIATION PATTERN @ 16.0GHZ Rev B... -
Page 34: H Plane Radiation Pattern @ 16.0Ghz
Model ATH7G18 2.14 H PLANE RADIATION PATTERN @ 16.0GHZ Rev C... -
Page 35: E Plane Radiation Pattern @ 18.0Ghz
Model ATH7G18 2.15 E PLANE RADIATION PATTERN @ 18.0GHZ Rev B... -
Page 36: H Plane Radiation Pattern @ 18.0Ghz
Model ATH7G18 2.16 H PLANE RADIATION PATTERN @ 18.0GHZ Rev C... -
Page 37: Outline Drawing
3. OUTLINE DRAWING Drawing 10006309, Rev D Rev C... - Page 38 Model ATH7G18 Rev C...
-
Page 39: Polarization Of Horn Antennas
4. POLARIZATION OF HORN ANTENNAS Rev C... - Page 40 Model ATH7G18 Rev C...
- Page 41 These modules are not field-repairable and should never be opened outside of AR’s Microelectronics Lab. The modules in these product lines have a security label on two sides of the modules between the housing and lid/cover. If the security label is removed and or cut, the warranty of the module will be voided.
