FLIGHT CONTROLLER F722-WING
QUICK START GUIDE
MCU: 216MHz STM32F722RET6
IMU: MPU6000 (SPI)
Baro: BMP280 (I2C)
OSD: AT7456E (SPI)
Blackbox: MicroSD card slot (SPI)
5x Uarts (1,2,3,4,6) with built-in inversion
1x Softserial_Tx option
2x Motors & 6x Servos outputs
1x I2C
4x ADC (VBAT, Current, RSSI, AirSpeed)
Switchable Dual Camera Inputs
Switchable 5V/9V for Camera/VTX
9~36V DC IN (3~8S LiPo)
High-precision Current Sense 132A Range
BEC 5V 2A for FC
BEC 9V 2A for camera/VTX, 12V option
BEC Vx 5A for servos, 5V, 6V or 7.2V option
LDO 3.3V 200mA
Dec.2018 Rev 1.0
www.mateksys.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mateksys F722-WING
Summary of Contents for Mateksys F722-WING
- Page 1 FLIGHT CONTROLLER F722-WING QUICK START GUIDE MCU: 216MHz STM32F722RET6 IMU: MPU6000 (SPI) Baro: BMP280 (I2C) OSD: AT7456E (SPI) Blackbox: MicroSD card slot (SPI) 5x Uarts (1,2,3,4,6) with built-in inversion 1x Softserial_Tx option 2x Motors & 6x Servos outputs 1x I2C...
- Page 2 *** 9V rise to 12V if “9V->12V” jumper is bridged. D+ & D-: USB data VBUS: USB voltage BlackBox MicroSD Slot 6000 Size: 54x36x13mm Weight: 25g w/ top and bottom plate Holes: Φ4mm, 30.5mm mounting M3 Silicon Grommets included Dec.2018 Rev 1.0 www.mateksys.com...
- Page 3 Vsw Power / Camera switcher Vsw OFF Vsw ON No USER1 definition Vsw ON by default C1 ON & C2 OFF C2 ON & C1 OFF No USER2 definition C1 (Camera-1) ON by default Dec.2018 Rev 1.0 www.mateksys.com...
