- Page 1 PUCK-5 User Guide...
- Page 2 Index Packing Check List Tools Required Optional Accessories Introduction Installation Instructions Antenna Installation Precautions Cable Routing Safety PUCK-5 PS...
-
Page 3: Item Description
Packing Check List Item Description Quantity **PUCK-V1 Antenna only M4 x 10mm Flat head Stainless steel Screws 10mm Threaded Spigot 50mm Threaded Spigot Magnetic Base Pole/ wall mount bracket Plastic Nut Adhesive Foam seal 1 Grip Extenders SMA(f) to RP- SMA(m) Adapter * Quantity will differ with different versions ** Antenna will differ with different versions... -
Page 4: Packing Checklist
The appearance of each component Antenna Unit M4x10mm Flat head Stainless steel Screws 10mm Threaded Spigot 50mm Threaded Spigot Magnetic base Pole/wall mount bracket Plastic Nut Adhesive foam seal *SMA(f) to RP-SMA(m) Adapters Grip Extenders *Antenna with Wi-Fi only PUCK-5 PS... -
Page 5: Tools Required
Drills (Pilot drill (3mm) Safety goggles and Hole saw (22mm) or step drill (4 - 22mm)) Masking tape Hand drilling machine Centre punch Hammer Drilling template 27mm wrench (www.poynting.tech/downloads) Optional Accessories Optional Accessories Various Cable extensions are available Version: 1.0... - Page 6 PUCK-V1 antenna. Installation Instructions Threaded Spigot Mounting Use the Drill template below or download the 1:1 drill template from http://www.poynting.tech/downloads. • Choose the mounting location carefully and a position at least 50cm from heat sources, with a clear line of sight to the sky.
-
Page 7: Installation Instructions
Installation Instructions Version: 1.0... - Page 8 Installation Instructions PUCK-5 PS...
- Page 9 Installation Instructions Surface mounting • Clean the entire surface on which you plan to place the antenna. • Remove nut, foam seal and Short spigot from antenna. • Secure the magnetic base to the antenna with flat head screws. • Place antenna onto magnetic surface.
- Page 10 • Place the bracket over the two holes and line up the holes in the bracket with the holes in the wall. • Insert the two knock-in screws to mount the bracket to the wall. PUCK-5 PS...
-
Page 11: Cable Routing
Installation Instructions Antenna Installation Precautions • Place the antenna at the highest point possible and ensure that there aren’t any surrounding obstructions to the antenna. • In order to avoid communication interference, ensure that the antenna is placed at least 0.5m away from other antennas and metal objects. - Page 12 SAR (Specific Absorption Rate) RF Exposure requirements. European Waste Electronic Equipment Directive 2002/96/EC Please ensure that old waste electricals and electronics are recycled. Directive 2011/65/EU (RoHS 2) This product is fully compliant with the RoHS 2 directive. PUCK-5 PS...
