Get Started - Spectrum Technologies FieldScout 2127W Manual

Download the FieldScout pH app
Scan the QR code or search for the FieldScout pH app in your app store.
You may need to activate location access for the app to record the location of each reading.
Home Menu
•
Home - Start screen with a list of available probes
•
Sample - Used for single measurements
•
Interval - Used for continuous measurements in specified intervals
•
History - Review your data
•
Settings - Select to choose Advanced Mode, Adjust Language, Units, Drift Warning Notice
Advanced Mode displays pH and mV, allows temperature calibration and during pH calibration, the standard deviation is
indicated
Activate Your Probe
•
Open the FieldScout pH app.
•
The LED on the probe is off when the probe is not yet registered and in standby mode.
•
To activate your device, tap the ON/OFF button on the top of the probe. The LED will turn blue when searching for a
connection.
•
With the app open, click the + Add Device button
•
Click the Search for Probes button
•
Select your probe and the LED on the probe will turn green
•
Follow the prompts to initiate the calibration process then click the Save button. The app will return to the Home page.
Standby Mode
When the probe is not in use and no interval measurement is running, the probe will go into standby mode. The LED will
turn off.
Registered Probes
•
If the probe is active, the app will recognize it and connect automatically
•
If the probe is in standby mode, it will be listed under "Disconnected Devices". Select your probe and click "Reconnect".
•
Once connected, the LED on the probe will turn green.
Battery Status of Probes
In the app, the battery status is shown as a percentage per probe. When the battery is running low during measurement,
the LED will flash red 5 times at each data point to warn you.
Add/Delete Probes
•
Click the + Add Device button - up to 6 probes can be connected
•
Swipe left on the probe(s) you want to delete. The LED will turn blue on the deleted probe.
Reset Your Probe
•
Press and hold the ON/OFF button on the top of the probe until the LED turns purple and then turns off. The LED will
either be green or blue.
•
Greed LED indicates the probe is connected and ready to use
•
Blue LED indicates the probe is disconnected and must be connected by clicking the + Add Device button
Restart Your Probe
•
Press and hold the ON/OFF button on the top of the probe until the LED turns white and then turns off. All connection
is reset. Calibration information remains.
6

GET STARTED
