Inverter-driven multi-split system air conditioning

Advertisement

Quick Links

Installation Manual
Inverter-Driven
Multi-Split System
Air Conditioning
Models:
RAM-200FSPH
RAM-200FSPHDC
RAM-250FSPH
RAM-250FSPHDC
․Before installation, please read this manual carefully and keep it properly.
․Make sure to hand over this manual to workers of the next stage and finally let the customer keep it.
(Transportation and Handling) → (Refrigerant Piping) → (Electrical Wiring) → (Test Run) → (Customer)
Important Notice
․This Air Conditioner has been designed for common air conditioning for people. Do not apply to other purposes
such as for food, animals, plants, high precision machines or work of art.
․Do not install the unit in the following places. It may cause fire, deformation, corrosion or failure.
o Places where is filled with mineral oil mist or oil spray (including machinery oil) or vapor is produced.
o Places where is filled with sulfurous gas such as hot spring area.
․Do not install the unit in the following places, it may cause corrosion.
o Places where strong salty wind blows such as coast regions.
o An acid or alkaline environment.
․Pay attention to the following situations when the unit is installed in a hospital or other facilities where
o
electromagnetic wave is radiated from medical equipment.
o Do not install the unit where the electromagnetic wave is directly radiated to the electrical box, remote
control cable or remote-control switch
o o To avoid the influence of electromagnetic waves via air, wave generating machines such as radio, medical
equipment must be kept at least 3 meters form air conditioner.
o
․Do not install the unit in the place where wind directly blows on animals or plants. It could adversely affect them.
․Using wireless remote controller, the receiver may fail to receive signals due to effect of the lighting equipment.
Therefore, keep the receiver away from the lighting equipment more than 1 meter as possible
INDEX Table of Contents
2
Safety Precautions
3
Transportation and Handling
5
Installation Procedure
7
Refrigerant Piping Works
14
Electrical Wiring
16
DSW Dip Switch Setting
17
Test Run
18
Alarm Code
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAM-200FSPH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hitachi RAM-200FSPH

  • Page 1 Installation Manual Inverter-Driven Multi-Split System Air Conditioning INDEX Table of Contents Models: Safety Precautions RAM-200FSPH Transportation and Handling RAM-200FSPHDC Installation Procedure Refrigerant Piping Works RAM-250FSPH Electrical Wiring RAM-250FSPHDC DSW Dip Switch Setting Test Run Alarm Code ․Before installation, please read this manual carefully and keep it properly.
  • Page 2: Safety Precautions

    1.Safety Precautions ․Before installation, carefully read this section in order to install it correctly. ․This manual contains “⚠Danger” . This symbol indicates a hazardous situation which if installed incorrectly It may result in death or serious injury. Therefore, make sure to observe important message of safety. ․While checking any abnormality during test run after installation, explain to costumer the correct methods of Usage and maintenance according to the User’s Manual.
  • Page 3: Transportation And Handling

    2. Transportation and Handling (1) When transporting the outdoor unit, observe the following item. Please transport the unit to the installation location under packed condition. ●Hanging Method without Packing: ●Hanging Method with Packing: Hang the unit with two ropes. Thickness of Hang the unit with two ropes plywood or cardboard must...
  • Page 4 No interchangeability is available due to higher pressure when Vacuum compared with R22. Manifold Valve Pumping; ● ■ R410A connection diameter:1/2 UNF Vacuum holding; R407C connection diameter:7/16 UNF refrigerant ◎<Do not use current ones (R22) to the different charging and Charging Hose refrigerant>;...
  • Page 5 Please refer to the table below to select the quantity and capacity of Outdoor Units and Indoor Units. Indoor Unit Outdoor Unit Model Combined Capacity Ratio Maximum quantity of combined units RAM-200FSPH(D) 50~130% (Outdoor unit capacity) 4~12 RAM-250FSPH(D) (6) Cooling Operating Instructions The same refrigerant system of indoor unit, the cooling shall be operated.
  • Page 6 central draining pipes.) 4.Provide a foundation so that the entire footing of the outdoor unit can be mounted on the foundation. The height of the foundation should be 100mm to 300mm higher than the ground level. Strong wind blowing directly against the product installation method Follow the instructions below when installing the unit on the roof with strong winds in the absence of obstruction: •...
  • Page 7: Refrigerant Piping Works

    4. Refrigerant Piping Works (1) Piping Work 1)Refrigerant Pipe Selection ①Please prepare the refrigerant pipe by field supplied. ②Select clean copper pipes. Make sure there is no dust and moisture inside of the pipes. ●Cut off the refrigerant piping, use the pipe cutter. Blow the inside of the pipes with nitrogen or dry air, to remove any dust or foreign materials before connecting pipes.
  • Page 8 Connecting Pipe Set (Flare Nut) Gas Side Piping Liquid Piping Connection (ΦA Flare Nut) Gas Piping Connection (Combine with the connecting Pipe Set) Rear Piping (Knock Out Hole) Connecting Pipe Set Front Piping Rear Piping (Welding) Gas Pipe Size (Knock Out Hole) (Knock Out Hole)
  • Page 9 Others Multi-kit Pipe And Connection Pipe 15~22.99 22.2 / 9.53 E-NP282S E-N55HT ※2 15 19.05 / 9.53 ※1: RAM-200FSPH(D) piping length (L +l Φ Φ ) exceed above 70m, the liquid pipe size from 9.53 change to 12.7。 ※2: E-N55HT (Header Branch), It can be used that each indoor unit distribution and connection.
  • Page 10  Indoor Unit Pipe Diameter(mm) Pipe Diameter(mm) Model Horsepower Gas side Liquid Side Gas Side Liquid Side RAM-200FSPH(D) Φ25.4 Φ9.53 0.8~6.0HP Please select according to the RAM-250FSPH(D) Φ25.4 Φ12.7 indoor model type and grade 22~160 Level The multi-kit pipe, which is connected to the indoor unit, be sure to use an optional part of the multi-kit pipe set, in order to prevent the uneven distribution of the refrigerant and causing the unit’s capacity reduction.
  • Page 11 (4) Piping Connection, Installation 1)Check if the stop valve of outdoor unit is closed. 2)Please connect the piping between indoor and outdoor unit. When tightening the joints of piping, in the inside and outside of flare piping, please coated with a layer of refrigerant oil [Field Supplied (Idemitsu Kosan Co., Ltd. Synthetic Oil “FVC68D”)], and in accordance with the provisions of tightening torque with double spanner to tighten.
  • Page 12 Please implement vacuum drying determination, to confirm whether water exist within the system. If moisture is present, please extend the vacuum time or installation the drying filter until no moisture is present within the system. Be sure to do this work, otherwise in the future the unit could easily lead to failure, and difficult to handle. ※Note: 1.When remove the spindle calve cap of stop valve, there may be slight refrigerant leakage sound is normal.
  • Page 13 4)Fully open the liquid line stop valve after completing refrigerant charge. 5)Be sure to implement leak detection. (7) Precaution for Refrigerant Leakage In the room where the air conditioner is installed, in case of refrigerant leakage, the concentration of refrigerant should not exceed the limit ●This product uses non-flammable, non-toxic safe refrigerant R410A, in case the refrigerant of the indoor unit leaks and fills the whole room, there will be a danger of suffocation.
  • Page 14: Electrical Wiring

    Supply MODEL y Current Φ, 60Hz (mA) ○ ○ ○ ○ ○ ○ Twisted Wire RAM-200FSPH 0.75(mm 230V Total Length RAM-250FSPH 1000m below Twisted Wire RAM-200FSPHD 0.75(mm 380V Total Length RAM-250FSPHD 1000m below Note: When earth leakage breaker specification selection, please according to above table (Note: The earth leakage breaker of power supply 380V must use 3Φ4 wire.
  • Page 15 ●Caution of indoor and outdoor unit connection wiring construction: The transmission cable of indoor and outdoor unit and the 220V power source cord, be sure to keep the distance of more than 5 ~ 6cm. Therefore, do not use the coaxial cable. If the transmission cable and power source cord connecting wrong, will cause the PCB of the outdoor unit burning, please pay special attention.
  • Page 16 6.DSW Dip Switch Setting TURN OFF all power sources before setting. Without turning OFF, the set value will be considered invalid. (■ indicates the position of Dip Switch) (1) Transmission Method Setting When multiple outdoor units share the same transmission line, need to set refrigerant cycle number and end terminal resistance. Setting of refrigerant cycle number: Setting of end terminal resistance (PCB of outdoor unit): The unit before leaving the factory, No.
  • Page 17 7. Test Run 【Before Test Run】 ● Before test run, please re-confirm the installation whether there are problems, also confirm the following points. ●In addition, please confirm it with the outdoor unit attached the installation manual. 1) Refrigerant piping and the transmission cable if connected with a different refrigeration cycle, there will be abnormal operation occurred.
  • Page 18: Alarm Code

    Alarm Code Code Distinction Content of Abnormality Leading Cause Indoor Unit Activation of Protection Device (Float Activation of Float Switch (High water Level Drain Pan, Abnormality of Indoor Unit Switch) Drainpipe, Float Switch or Drain Pan) Activation of High Pressure Switch (4.15MPa); Air Conditioner Outdoor Outdoor Unit Activation of Protection Device Outdoor Unit Unit Fan Motor Lock.
  • Page 19 Test Run and Maintenance Record MODEL: SERIAL. No. COMPRESSOR MFG. No. DATE: CUSTOMER'S NAME AND ADDRESS: 1. Is the rotation direction of the indoor coil fan correct? 2. Is the rotation direction of the outdoor coil fan correct? 3. Are there any abnormal compressor sounds? 4.
  • Page 20 66MP1572-A1 Printed in Philippines...
