Page 1: Table Of Contents
STIH) Technical Information 04.2013 New STIHL MS 362 C-M Chain Saw Contents 1. Components 2. Starting / Stopping the Engine 2.1 Positions of Master Control Lever™ 2.2 Setting the Master Control Lever™ 3. Specifications 4. Repairs 4.1 Troubleshooting 4.2 Control Unit 4.3 Wiring Harness... - Page 2 Automatic carburetor adjustment conditions. – Memory function The MS 362 C-M is the first STIHL saw to feature a – Master Control Lever™ with stop switch function Master Control Lever™ with a stop switch function. When the Master Control Lever™ is released and...
-
Page 3: Components
Wiring harness (3) Connects control unit, solenoid valve, microswitch Diagnostic jack (7) and diagnostic jack. Connection for STIHL MDG 1 engine analyzer. Master Control Lever™ with stop switch function (4) Engine is shut down by operating the Master Control Lever™. When the engine stops, the Master Control Lever™... -
Page 4: Starting / Stopping The Engine
Page 4 Technical Information 04.2013 Starting / Stopping the Engine Setting the Master Control Lever™ To move the Master Control Lever™ from the run Because of the new Master Control Lever™ with position F to start }, press down the trigger lockout stop switch function, it is no longer necessary to and squeeze the throttle trigger at the same time check its position when restarting the engine. -
Page 6: Repairs
(4). Troubleshooting 4.2.2 Installing the Control Unit The STIHL MDG 1 engine analyzer can be used to Place the control unit in the crankcase. test ignition module and control unit STIHL (M-Tronic™) and connected electrical components quickly and reliably. To do this, follow the steps in the diagnostics software after connecting the analyzer. -
Page 7: Wiring Harness
– see b 4.2.1 4.3.2 Installing the Wiring Harness Push the grommet with wiring harness through the crankcase – use STIHL press fluid if necessary. Push the ignition lead (6) into the guides (arrows) on top of the wiring harness. - Page 8 Page 7 Technical Information 04.2013 Installation at fanwheel side Fit yellow ground wire connector (3) onto the contact spring terminal (4) and push them both onto the filter base. Install the carburetor and filter base. Position black short circuit wire connector in the switch shaft's guides and push it onto the boss –...
-
Page 9: Switch Unit
Page 8 Technical Information 04.2013 Switch Unit 4.4.2 Installing the Switch Unit 4.4.1 Removing the Switch Unit Remove the shroud, air filter and baffle. Swing the filter base forward in direction of handle. Loosen the screw (1) and pull away the switch unit (2). -
Page 10: Tightening Torques
M2.5x16 Switch unit / carburetor 9.0 lbf in (1.0 Nm) Remark 1) Coat micro-encapsulated screws with medium strength Loctite 243 before reinstalling. All other tightening torques remain as before and are listed in the STIHL MS 362 service manual. TI_04_2013_30_01_01.fm... -
Page 11: Repair Times
Replace solenoid valve or M- Tronic wiring. Includes diagnostic and function tests. Engine diagnosis only to determine failures requiring unit replacement. Miscellaneous repairs and other repairs not listed. Handling allowance only-no labor. No labor. © ANDREAS STIHL AG & Co. KG, 2013 TI_04_2013_30_01_01.fm...
