VENTED GAS LOG APPLIANCE
OWNER'S OPERATION AND
INSTALLATION MANUAL
DANGER
f i r e - p a r t s . c o m
WARNING: No not store gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance. An LP-cylinder not connected for use shall not be stored in
the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Read the installation, operating and maintenance instruc-
tions thoroughly before installing or servicing this equipment.
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WHEN USED AS AN OUTDOOR APPLIANCE
CARBON MONOXIDE
WARNING
•
This appliance can pro-
duce carbon monoxide
which has no odor.
•
Using it in an enclosed
space can kill you.
•
Never use this appliance
in an enclosed space
such as a camper, tent,
car or home.
WHEN USED AS INDOOR VENTED APPLIANCE
For more information, visit www.fmiproducts.com
REMOTE-READY LOG SET AND BURNER SYSTEM
MF42ONE, MF42OPE, MF48ONE, MF48OPE,
VTDGT24NE, VTDGT24PE, VTDGT30NE, VTDGT30PE,
VTDGT36NE, VTDGT36PE
MF42 MODELS MAY BE USED WITH LMF36-SC AND LMF42-SC
MF48 MODELS MAY BE USED WITH LMF48-SC LOGS ONLY
PFS
WARNING: For Outdoor Use Only.
DANGER
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
MODELS
LOGS ONLY
®
US
Advertisement
Table of Contents
Related Manuals for FMI VTDGT24NE
Summary of Contents for FMI VTDGT24NE
- Page 1 REMOTE-READY LOG SET AND BURNER SYSTEM MODELS MF42ONE, MF42OPE, MF48ONE, MF48OPE, VTDGT24NE, VTDGT24PE, VTDGT30NE, VTDGT30PE, VENTED GAS LOG APPLIANCE VTDGT36NE, VTDGT36PE OWNER’S OPERATION AND MF42 MODELS MAY BE USED WITH LMF36-SC AND LMF42-SC LOGS ONLY INSTALLATION MANUAL MF48 MODELS MAY BE USED WITH LMF48-SC LOGS ONLY ®...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..................2 Specifications ..............16 Product Identification ............3 Wiring Diagram ..............17 Local Codes.................4 Troubleshooting ..............18 Unpacking................4 Accessories ...............21 Product Features ..............4 Parts ..................22 Installation ................4 Service Hints ..............25 Operation ................14 Technical Service...............25 Inspecting Burners.............15 Replacement Parts ............25 Cleaning and Maintenance ..........16 Warranty ............. -
Page 3: Product Identification
SAFETY Continued You must operate this appliance with the fire- other objects. 12.Do not use this appliance if any part has been exposed to place screen and hood in place. Make sure or under water. Immediately call a qualified service tech- fireplace screen and hood are in place before nician to inspect the room appliance and to replace any running appliance. -
Page 4: Local Codes
3. Check appliance for any shipping damage. If appliance is allel, as in a breezeway or at right angles to each side; or damaged call FMI PRODUCTS, LLC at 1-866-328-4537 for 3. Within a partial enclosure which includes an overhead cover replacement parts before returning to dealer. - Page 5 INSTALLATION Continued MINIMUM FIREPLACE CLEARANCE TO COMBUSTIBLE Minimum Noncombustible Material Clearances MATERIALS If Not Using Mantel Side Wall 16", Ceiling 42" Note: If using a mantel proceed to If Using Mantel. If not using Floor 5", Front: 36" a mantel, follow these instructions. You must have noncombustible material(s) above the fireplace LOG SIZING REQUIREMENTS opening.
- Page 6 INSTALLATION Continued MANTEL CLEARANCES NOTICE: Surface temperatures of adjacent In addition to meeting noncombustible material clearances, walls and mantels become hot during opera- you must also meet required clearances between fireplace tion. Walls and mantels above the firebox may opening and mantel shelf. If you do not meet the clearances become hot to the touch.
- Page 7 INSTALLATION Continued For Massachusetts Residents Only: Installation of this gas Chimney Height Minimum Permanent Flue Opening log set as a vented indoor appliance in the Commonwealth of Massachusetts requires the damper be permanently removed 6' to 15' 39 sq. inches or welded in the fully open position.
- Page 8 INSTALLATION Continued Masonry Screw optional equipment shutoff valve from your dealer. For propane/LP units, the installer must supply an external regulator. The external regulator will reduce incoming gas pressure. You must reduce incoming gas pressure to be- tween 11" and 14" of water. If you do not reduce incoming gas pressure, appliance regulator damage could occur.
- Page 9 INSTALLATION Continued Equipment Shutoff Valve PROPANE/LP 2. Cap off open end of gas pipe where equipment shutoff With 1/8" NPT Tap* From External valve was connected. Regulator 3. Pressurize supply piping system by either opening pro- Approved Flexible (11" W.C.** pane/LP supply tank valve for propane/LP gas or opening Gas Hose (if allowed to 14"...
- Page 10 INSTALLATION Continued Equipment Shutoff Valve MF SERIES BURNER SYSTEM-LOG COMPATIBILITY CHART Burner System Model Refractory Concrete Logs For Use With This Burner Gas Meter System MF42ONE,MF42OPE, LMF36-SC LMF42-SC Control Valve Location MF48ONE, MF48OPE, LMF48-SC Figure 15 - Checking Gas Joints (Natural Gas Only) PRESSURE TESTING APPLIANCE GAS CONNECTIONS Figure 16 - MF Series Burner System- Log Compatibility...
- Page 11 INSTALLATION Continued Right Front Log (D-061, D-019 or D027) Burner Tube Grate Finger Figure 17 - Installing Right Front Log Round Tube Burner Figure 17C - Installing Right Front Log, Side View 2. Find the back left log (LMF36-SC and VFGT24 inch mod- f i r e - p a r t s .
- Page 12 INSTALLATION Continued Log Notch Burner Tube Figure 18A - Installing Back Left Log Figure 19A - Installing Front Left Log Side View f i r e - p a r t s . c o m Vertical Portion of Burner Tube Grate Finger Log Slot Figure 18B - Installing Back Left Log (D-018) Rear View...
- Page 13 INSTALLATION Continued Burner Tube Log Notch Figure 20A - Installing Charred Log Top View Square Grate Log Notch Figure 21A - Installing Middle Split Log Rear Top Side View 6. Find the right split crossover log (D-022) The bottom of the log has a rectangular stand off that fits in the slots on f i r e - p a r t s .
-
Page 14: Operation
INSTALLATION OPERATION Continued FOR YOUR SAFETY 8. Find the back top log (LMF36-SC and VFGT24 inch READ BEFORE LIGHTING models: D-062 or LMF42-SC and VFGT30 inch models: D-023 or LMF48-SC and VTGF36 inch models: D-029). WARNING: If you do not follow these instruc- See Figures 24, and 24A. -
Page 15: Inspecting Burners
OPERATION INSPECTING BURNERS Continued Check burner flame patterns often. IGNITOR ASSEMBLY The ignitor assembly is factory preset for proper ignition of Incoming the burner. Alterations may have occurred during shipping Gas Line Equipment and handling. Call a qualified service person to readjust the Shutoff Valve ignitor assembly if necessary. -
Page 16: Cleaning And Maintenance
We recommend that you clean the unit every three MF42ONE, MF48ONE, VTDGT30NE, VTDGT36NE AND months during operation and have appliance inspected yearly VTDGT24NE by a qualified service person. • Rating (Variable): 29,000/40,000 Btu/Hr We also recommend that you keep the burner tube clean and •... -
Page 17: Wiring Diagram
WIRING DIAGRAM f i r e - p a r t s . c o m www.fmiproducts.com 125636-01C... -
Page 18: Troubleshooting
TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair appliance. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ''ON'' button on remote con- 1. - Page 19 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Delayed ignition of burner 1. Manifold pressure is too low 1. Contact local natural or propane/ LP gas company 2. Burner orifice clogged 2. Clean burner (see Cleaning and Maintenance, page 16) or replace burner orifice(s) Burner backfiring during combus- 1.
- Page 20 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instruc- tions.
-
Page 21: Accessories
ACCESSORIES DAMPER CLAMP - GA6080 Purchase these appliance accessories from your local dealer. If they can not supply these accessories, call FMI PROD- For all models. Permanently opens chimney flue damper for UCTS, LLC at 1-866-328-4537 for referral information. You vented operation. -
Page 22: Parts
PARTS MODELS MF42ONE, MF42OPE, MF48ONE, MF48OPE, VTDGT30NE, VTDGT30PE, VTDGT36NE, VTDGT36PE, VTDGT24NE AND VTDGT24PE f i r e - p a r t s . c o m www.fmiproducts.com 125636-01C... - Page 23 PARTS MODELS MF42ONE, MF42OPE, MF48ONE, MF48OPE, VTDGT30NE, VTDGT30PE, VTDGT36NE, VTDGT36PE, VTDGT24NE AND VTDGT24PE This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replace- ment Parts on page 25 of this manual. PART NO.
- Page 24 PARTS LOG SETS FOR MODELS MF42ONE, MF42OPE, MF48ONE, MF48OPE, VTDGT30NE, VTDGT30PE, VTDGT36NE, VTDGT36PE, VTDGT24NE AND VTDGT24PE This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on page 25 of this manual.
-
Page 25: Service Hints
REPLACEMENT PARTS Note: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. Contact authorized dealers of this product. If they can’t supply original replacement part(s), call FMI PRODUCTS, LLC at 1-866-328-4537. When calling, have ready: •... - Page 26 _____________________________________________________ NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ f i r e - p a r t s . c o m ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________...
- Page 27 _____________________________________________________ NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ f i r e - p a r t s . c o m ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________...
-
Page 28: Warranty
FMI PRODUCTS, LLC makes no other warranties regarding this product. FMI PRODUCTS, LLC’s liability is limited to the purchase price of the product, and FMI PRODUCTS, LLC shall not be liable for any other damages whatsoever under any circumstances including indirect, incidental, or consequential damages.
