  • Page 1 PowerWalker How to assemble a BPH A72T-6...
  • Page 2 Important Safety Warnings Please comply with all warnings and operating instructions in this instruction strictly. Read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. • Do not try to assemble or repair the unit yourself, contact your local supplier, seek for a qualified technician for professional assistance.
  • Page 3 The following precaution should be observed when working on batteries: 1. Remove watches, rings, or other metal objects. 2. Use tools with insulated handles. 3. Wear rubber gloves and boots. 4. Do not lay tools or metal parts on top of batteries. 5.
  • Page 4 SOP – How to assemble BPH A72T-6 Please follow the below wiring for the first three batteries. Please also use the in- package insulating tubes to protect both loose ends. 450 mm 450 mm 380 mm 150 mm Organize the batteries as shown below. Use the protective plastic to avoid sharp...
  • Page 5 Please follow the wiring for the other side as shown below. 450 mm 280 mm 150 mm Organize the batteries as shown below. Use the protective plastic to avoid sharp edges damaging the wires. Fasten the batteries with the fixing plate.
