Summary of Contents for Power Walker A72R-12
- Page 1 User Manual Battery Pack...
- Page 2 1. Important Safety Warnings Please comply with all warnings and operating instructions in this instruction strictly. Read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. Do not try to assemble or repair the unit yourself, contact your local ...
- Page 3 CAUTION – A battery can present a risk of electrical shock and high short circuit current. The following precaution should be observed when working on batteries: 1. Remove watches, rings, or other metal objects. 2. Use tools with insulated handles. 3.
- Page 4 SOP - How to assemble BP A72R-12x9Ah 1.Insert cables as shown below：Insert the black external battery cable into P3 and P5 of the PCB board on the left, and insert the switch safety red cable into P1. 300MM 220MM * 8 300MM Tool：...
- Page 5 The red cable use heating shrinkable sleeve protection 240MM 280MM 380MM 380MM Tool： Notice: Pliers 1．No short for battery is allowed. 2．Wires should be connected precisely.
- Page 6 1、Plug the (240MM) battery red cable into P5 on the right connect pcba board. 2、Plug the long red cable of (380MM) battery into P6 on the right connect pcba board. 3、Plug the (280MM) short black battery cable into P2 on the left connect pcba board. 4、Plug the long black cable of (380MM) battery into P1 on the left connect pcba board.
- Page 7 1. Put the battery in the direction as shown, and then lock the battery baffle. Screw 38-000008-XXG*8；Torsion：8kgf.cm Tool： Notice: Pliers 1．No short for battery is allowed. 2．Wires should be connected precisely.
- Page 8 1.Lock back panel screws and paste label：38-000008-XXG*4 Torsion：8KGF-CM。 2. Lock the both side screws of the outer cover as shown below：38-000029-XXG*11 Torsion： Notice: Tools: Electrical drill, cross screw bit No reversed, incorrect, and missed isolation stick is allowed. No missed screwing is allowed,...
