Summary of Contents for Power Walker BP A24R-4x9Ah
- Page 1 User Manual Battery Pack...
- Page 2 1. Important Safety Warnings Please comply with all warnings and operating instructions in this instruction strictly. Read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. Do not try to assemble or repair the unit yourself, contact your local ...
- Page 3 CAUTION – A battery can present a risk of electrical shock and high short circuit current. The following precaution should be observed when working on batteries: 1. Remove watches, rings, or other metal objects. 2. Use tools with insulated handles. 3.
- Page 4 SOP - How to assemble BP A24R-4x9Ah Battery assembly A 450MM 350MM 350MM 450MM...
- Page 5 Battery assembly B 1、As below shown ,insert two battery packs black line on P5 & P10 terminal of the PCB board ； Insert the switch insurance short red line on the left side of the battery red terminal, and the long red line on the right side of the battery red terminal.
