Page 1
PowerWalker How to assemble a BPH P48R-8...
Page 2
Important Safety Warnings Please comply with all warnings and operating instructions in this instruction strictly. Read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. • Do not try to assemble or repair the unit yourself, contact your local supplier, seek for a qualified technician for professional assistance.
Page 3
The following precaution should be observed when working on batteries: 1. Remove watches, rings, or other metal objects. 2. Use tools with insulated handles. 3. Wear rubber gloves and boots. 4. Do not lay tools or metal parts on top of batteries. 5.
Page 4
SOP – How to assemble BPH P48R-8 Please assemble 8 batteries into the BP housing. Remark: 3x Fuse 15A 250V 8x Battery 12V 7-9 Ah...
Page 5
Please connect the 8 batteries with the wires as shown below • Connect BAT7 (+) and BAT8 (-) with the black wiring. • Connect BAT8 (+) and BAT1 (-) with the black wiring. • Connect BAT1 (+) and BAT2 (-) with the black wiring. •...
Page 6
• Connect BAT2 (+) and FUSE with the red wiring. • Connect BAT4 (+) and FUSE with the red wiring.
Page 7
Please fix the batteries and lay them down as shown below Anderson connector: 600V/ 45A...
