Summary of Contents for Power Walker A24R-6x9Ah
- Page 1 User Manual Battery Pack...
- Page 2 1. Important Safety Warnings Please comply with all warnings and operating instructions in this instruction strictly. Read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. Do not try to assemble or repair the unit yourself, contact your local ...
- Page 3 CAUTION – A battery can present a risk of electrical shock and high short circuit current. The following precaution should be observed when working on batteries: 1. Remove watches, rings, or other metal objects. 2. Use tools with insulated handles. 3.
- Page 4 SOP - How to assemble BP A24R-6x9Ah Battery assembly A 150MM 150MM 350MM 350MM 400MM Insert P5 Insert P10 Insert P6 350MM...
- Page 5 Battery assembly B 1. As below shown, note that the battery direction; level off , smooth the wire after inserted. The first long red line inserted The second long red line inserted in the battery red terminal in the battery red terminal The third long red line inserted in the battery red terminal As shown, the three red lines on the...
- Page 6 Battery assembly C Screw：38-000008-XXG*4； 1、As below shown, lock the baffle of battery on the base. Torque：8KGF-CM...
