Argus Security TAURUS TW-BS-01/916 Quick Start Manual

Wireless (916) base sounder, vad red led; vad white led
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wireless (916) Base Sounder VAD White LED
WARNINGS AND LIMITATIONS
Our devices use high quality electronic components and plastic materials that are highly resistant to environmental deterioration. However,
after 10 years of continuous operation, it is advisable to replace the devices in order to minimize the risk of reduced performance caused by
external factors. Ensure that this device is only used with compatible control panels. Detection systems must be checked, serviced and main-
tained on a regular basis to confirm correct operation. Smoke sensors may respond differently to various kinds of smoke parti cles, thus appli-
cation advice should be sought for special risks. Sensors cannot respond correctly if barriers exist between them and the fire location and may
be affected by special environmental conditions. Refer to and follow national codes of practice and other internationally recognized fire engi-
neering standards. Appropriate risk assessment should be carried out initially to determine correct design criteria and updated periodically.
Use only in Taurus fire detection and alarm systems.
WARRANTY
All devices are supplied with the benefit of a limited 5 years warranty relating to faulty materials or manufacturing defects, effective from the
production date indicated on each product. This warranty is invalidated by mechanical or electrical damage caused in the field by incorrect
handling or usage. Product must be returned via your authorized supplier for repair or replacement together with full informa tion on any
problem identified. Full details on our warranty and product's returns policy can be obtained upon request.
The warranty does not cover the provided batteries.
TW-BS-01/916
SAI Global
Lic SMK41004
AS ISO 7240.25
TW-BS-01/916
Wireless (916) Base Sounder
TW-BSB-23R-01/916
Wireless (916) Base Sounder VAD Red LED
TW-BSB-23W-01/916
TW-BSB-23R-01/916
SAI Global
Lic SMK41004
AS ISO 7240.23
AS ISO 7240.25
TW-BSB-23W-01/916
SAI Global
Lic SMK41004
AS ISO 7240.23
AS ISO 7240.25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAURUS TW-BS-01/916 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argus Security TAURUS TW-BS-01/916

Summary of Contents for Argus Security TAURUS TW-BS-01/916

  • Page 1 TW-BS-01/916 Wireless (916) Base Sounder TW-BSB-23R-01/916 Wireless (916) Base Sounder VAD Red LED TW-BSB-23W-01/916 Wireless (916) Base Sounder VAD White LED WARNINGS AND LIMITATIONS Our devices use high quality electronic components and plastic materials that are highly resistant to environmental deterioration. However, after 10 years of continuous operation, it is advisable to replace the devices in order to minimize the risk of reduced performance caused by external factors.
  • Page 2 Tamper switch Output selection Link program DIP switch switch Battery A Battery B lodgement lodgement LED indicator Acoustic alarm outlet Sound diffuser Picture 1 ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...

  • Page 3: Deployment Procedure

    DEPLOYMENT PROCEDURE The general applicable procedure for the deployment of these products is the following: 1) Select a location for the base sounder. See LOCATION SELECTION. 2) Unbox the base sounder product from its packaging. 3) Detach the battery cover from the base sounder. See BATTERY COVER. 4) Detach the wall installation plate from the device.

  • Page 4: Location Selection

    Always install the battery cover, since it is a vital part of the anti-tampering feature. Make sure the battery cover is safely fixed, blocked and closed. ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
  • Page 5 WALL INSTALLATION PLATE To detach / reinstall the wall plate to the base sounder refer to the following picture: Picture 4 Make sure that the sound diffuser cone printed on the wall plate corresponds to the acoustic alarm signal outlet of the base sounder. Drill templates on the wall plate are highlighted in the following picture: Picture 5 info@argussecurity.it...
  • Page 6 3) Insert the two supplied batteries into their device’s lodgments. Ensure that the batteries are installed properly, with their polarities matching the indications on the device. ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
  • Page 7 LINKING - WAKE-UP “Wake-up” linking consists in associating one or more child devices to the Taurus system altogether in a single operation. Wake-up is performed either through the TauREX software or the TW-MTI-01/916 / TW-MEC-01/916 keyboard-screen interface; it CANNOT be done through TW-ME-01/916 devices. 1) Create the “virtual model”...
  • Page 8 4) Select the visual emission’s power; switch settings and the corresponding power levels are found on table 4 (applies only to TW-BSB-23R-01/916 and TW-BSB-23W-01/916). Acoustic volume level Switches configuration High Medium-High Medium-Low Table 3 Visual emission power level Switch configuration High Table 4 ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
  • Page 9 Tone number Main tone designation Main tone pattern description DIP switches Silent No sound 11111 Warble Tone 800Hz for 500ms, then 1000Hz for 500ms 11101 Continuous tone 970Hz continuous tone 01011 Slow Whoop (Dutch) 500-1200Hz for 3500ms, then off for 500ms 10101 German DIN tone 1200-500Hz swept every 1000ms (1Hz)
  • Page 10 660Hz for 150ms, then OFF for 150ms 00110 800Hz continuous 10111 800Hz continuous 10011 800Hz continuous 01000 2900Hz continuous 00011 800Hz continuous 10000 Table 6 ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
  • Page 11 FIXING THE BASE SOUNDER To fix the base sounder to the wall plate insert and fix the supplied screws in the holes highlighted in the following picture: Picture 7 HOST DETECTOR / PLASTIC COVER INSTALLATION If a detector is hosted, follow the setup instructions on its installation manual. Make sure the detector’s OWN battery cover is installed to avoid tamper detection events.
  • Page 12 5) Check that a normal condition persists (i.e. test smoke can stagnate in a detector’s smoke chamber causing the alarm to be triggered again). Local safety standards may require you to test these devices on a regular basis. ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...

  • Page 13: Technical Specifications

    TECHNICAL SPECIFICATIONS * Specification Value Communication range with TW-MTI-01/916, TW-MEC-01/916 or 200 m (in open space) TW-ME-01/916 network devices Wireless frequency band 916 MHz Number of wireless channels Radiated power 14 dBm (25 mW) Operating temperature range -10 °C to 55 °C Maximum humidity (non condensing) 95% RH Certified IP rating (AS ISO 7240)

  • Page 14: Acoustic Specifications

    1.7 m height, 6 m coverage diameter, 4.24 m x 4.24 m O1.7-6 (AS ISO 7240.23) (18 m ) square coverage Table 12 Ceiling Mounted Device Demonstration Item TW-BSB-23R-01/916 and TW-BSB-23W- 01/916 only ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...

This manual is also suitable for:

Taurus tw-bsb-23r-01/916Taurus tw-bsb-23w-01/916
