Wireless Sounder Base Black + Visual Alarm Device (White LED)
WARNINGS AND LIMITATIONS
Our devices use high quality electronic components and plastic materials that are highly
resistant to environmental deterioration. However, after 10 years of continuous operation, it is
advisable to replace the devices in order to minimize the risk of reduced performance caused
by external factors. Ensure that this device is only used with compatible control panels. Detec-
tion systems must be checked, serviced and maintained on a regular basis to confirm correct
operation. Smoke sensors may respond differently to various kinds of smoke particles, thus
application advice should be sought for special risks. Sensors cannot respond correctly if
barriers exist between them and the fire location and may be affected by special environmental
conditions. Refer to and follow national codes of practice and other internationally recognized
fire engineering standards. Appropriate risk assessment should be carried out initially to deter-
mine correct design criteria and updated periodically.
Use only in Taurus fire detection and alarm systems.
WARRANTY
All devices are supplied with the benefit of a limited 5 years warranty relating to faulty materials
or manufacturing defects, effective from the production date indicated on each product. This
warranty is invalidated by mechanical or electrical damage caused in the field by incorrect
handling or usage. Product must be returned via your authorized supplier for repair or replace-
ment together with full information on any problem identified. Full details on our warranty and
product's returns policy can be obtained upon request.
TW-BS-01/BL
Wireless Sounder Base Black
TW-BSB-23W-01/BL
0051
22
* TU0810UK
* TU0810CPR
** TU0910CPR
** TU0910UK
ARGUS SECURITY S.R.L.
Via del Canneto, 14
34015 Muggia (TS)
Italy
* TW-BS-01/BL
** TW-BSB-23W-01/BL
EN 54-3:2001+ A1:2002 + A2:2006
EN 54-25:2008
** TW-BSB-23W-01/BL
EN 54-23:2010
Type A - for indoor use only
TW-BSB-23W-01/BL
C3-15 & O4.6-15 (white / high power)
C3-10 (white / low power)
8504
22
Advertisement
Table of Contents
Related Manuals for Argus Security Taurus TW-BS-01/BL
Summary of Contents for Argus Security Taurus TW-BS-01/BL
- Page 1 Ensure that this device is only used with compatible control panels. Detec- tion systems must be checked, serviced and maintained on a regular basis to confirm correct ARGUS SECURITY S.R.L. operation. Smoke sensors may respond differently to various kinds of smoke particles, thus Via del Canneto, 14 application advice should be sought for special risks.
- Page 2 LED indicator Acoustic alarm outlet Sound diffuser Picture 1 All pictures are for product in black variant. Shown white for illustrative purpose only ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
-
Page 3: Deployment Procedure
DEPLOYMENT PROCEDURE The general applicable procedure for the deployment of these products is the following: 1) Select a location for the base sounder. See LOCATION SELECTION. 2) Unbox the base sounder product from its packaging. 3) Detach the battery cover from the base sounder. See BATTERY COVER. 4) Detach the wall installation plate from the device. -
Page 4: Location Selection
Always install the battery cover, since it is a vital part of the anti-tampering feature. Make sure the battery cover is safely fixed, blocked and closed. ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it... - Page 5 WALL INSTALLATION PLATE To detach / reinstall the wall plate to the base sounder refer to the following picture: Picture 4 Make sure that the sound diffuser cone printed on the wall plate corresponds to the acoustic alarm signal outlet of the base sounder. Drill templates on the wall plate are highlighted in the following picture: Picture 5 info@argussecurity.it...
- Page 6 3) Insert the two supplied batteries into their device’s lodgments. Ensure that the batteries are installed properly, with their polarities matching the indications on the device. ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
- Page 7 LINKING - WAKE-UP “Wake-up” linking consists in associating one or more child devices to the Taurus system altogether in a single operation. Wake-up is performed either through the TauREX software or the TW-MTI-01 / TW-MEC-01 keyboard-screen interface; it CANNOT be done through TW-ME-01 devices.
- Page 8 Acoustic volume level Switches configuration High * Medium-High Medium-Low Table 3 EN 54-3 approved volume Visual emission power level Switch configuration High Table 4 ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
- Page 9 Tone number Main tone designation Main tone pattern description DIP switches Silent No sound 11111 Warble Tone 800Hz for 500ms, then 1000Hz for 500ms 11101 Continuous tone 970Hz continuous tone 01011 Slow Whoop (Dutch) 500-1200Hz for 3500ms, then off for 500ms 10101 German DIN tone 1200-500Hz swept every 1000ms (1Hz)
- Page 10 660Hz for 150ms, then OFF for 150ms 00110 800Hz continuous 10111 800Hz continuous 10011 800Hz continuous 01000 2900Hz continuous 00011 800Hz continuous 10000 Table 6 ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
- Page 11 FIXING THE BASE SOUNDER To fix the base sounder to the wall plate insert and fix the supplied screws in the holes highlighted in the following picture: Picture 7 HOST DETECTOR / PLASTIC COVER INSTALLATION If a detector is hosted, follow the setup instructions on its installation manual. Make sure the detector’s OWN battery cover is installed to avoid tamper detection events.
- Page 12 5) Check that a normal condition persists (i.e. test smoke can stagnate in a detector’s smoke chamber causing the alarm to be triggered again). Local safety standards may require you to test these devices on a regular basis. ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
-
Page 13: Technical Specifications
TECHNICAL SPECIFICATIONS * Specification Value Communication range with TW-MTI-01, TW-MEC-01 or TW-ME-01 200 m (in open space) network devices Wireless frequency band 868 MHz Number of wireless channels Radiated power 14 dBm (25 mW) Operating temperature range -10 °C to 55 °C Maximum humidity (non condensing) 95% RH Certified IP rating (EN 54) -
Page 14: Acoustic Specifications
RED flash / LOW power coverage height, 6 m coverage diameter, 4.24 m x 4.24 m (18 O1.7-6 (EN 54-23) ) square coverage Table 12 Wall Mounted Device Demonstration ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
