ADVANCE System. Refer to the display's manual for setting.
1. Set the slide switch to 【LOWER】.
2. Press 【LEFT button】 long. The gauge shifts to the setting mode for number of cylinders,
and warning and peak LEDs on the gauge blink alternately.
If displays are installed, the system moves into the system setup mode of display not
the tachometer setting mode. LEDs on the gauge doesn't blink. If the tachometer is not
installed, the system does not shift to the setting mode for number of cylinders.
3. Press 【RIGHT button】 to change the number of cylinders in this order: 1 → 2 → 3 → 4
→ 5 → 6 → 8.
Press 【MIDDLE button】 to change the number of cylinders in this order: 8 → 6 → 5 → 4
→ 3 → 2 → 1.
When the number of cylinders 1 is selected, the needle pointer points to 1000rpm when
4 is selected, the needle pointer points to 4000rpm. Please set the number according to
your vehicle.
4. After completion of setting, return the slide switch to 【UPPER】.

9.6. Setting mode for tachometer response

Slide switch position : 【LOWER】
The response needs to be set if ADVANCE tachometer is installed. There are 3 levels.
Factory default setting: Level 1
If displays are installed as well, settings for tachometer need to be done in the system
setup mode. The settings of displays are applied to other tachometers connected to the
ADVANCE System. Refer to the display's manual for setting.
Adjust the response by moving the needle pointer.
Level Response
1
2 middle
3
1. Set the slide switch to 【LOWER】.
2. Press 【LEFT button】 long. The gauge shifts to the setting mode for number of cylinders,
and warning and peak LEDs on the gauge blink alternately.
If displays are installed, the system moves into the system setup mode of display not
the tachometer setting mode. LEDs on the gauge doesn't blink. If the tachometer is not
installed, the system does not shift to the setting mode for number of cylinders and
ADVANCE Control Unit SE Manual
Indicated position
high 1000rpm
2000rpm
low 3000rpm
