729021220
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
OPTION-A
BUILDING DIMENSIONS
Approx.
Size
5' x 3'
1,5 m x ,9 m
1.4 m
* See Inside for Detailed Safety Information.
Exterior Dimensions
Storage
(Roof Edge to Roof Edge)
Area
Width
67 1/2"
2
2,6 m 3
171,5 cm
Model No. PS53
Depth
Height
Width
39 1/4"
74 1/4"
62 1/4"
99,7 cm
188,6 cm
158,1 cm
PS53BG
5' x 3'
OPTION-B
Base
65 1/16" x 38 3/8"
Size
165,3 cm x 97,4 cm
Interior Dimensions
(Wall to Wall)
Depth
Height
35 9/16"
73 11/16"
90,3 cm
187,2 cm
01GXb
Nominal Size
Door
Opening
Width
Height
48 11/16"
69 11/16"
123,7 cm
177,0 cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPACEMAKER PS53 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Arrow Storage Products SPACEMAKER PS53 Series

  • Page 1 01GXb 729021220 Owner’s Manual & Assembly Guide Model No. PS53 PS53BG 5’ x 3’ Gloves must be worn at all times to reduce Nominal Size risk of injury! OPTION-A OPTION-B Base 65 1/16” x 38 3/8” Size 165,3 cm x 97,4 cm BUILDING DIMENSIONS †...
