731500821
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
arrowshed.com
Visit our website for compatible accessories
BUILDING DIMENSIONS
†
Approx.
Storage
Size
6' x 5'
25 Sq. Ft. 140 Cu. Ft.
1,7 m x 1,4 m
2,3 m
* See Inside for Detailed Safety Information.
†
Size rounded off to the nearest foot
Exterior Dimensions
(Roof Edge to Roof Edge)
Area
Width
69 3/4"
2
4,0 m 3
177,2 cm
157,5 cm
Model No. LWSM65
Depth
Height
Width
62"
72"
66"
182,9 cm
167,6 cm
Steel Shed
Steel Shed
6' x 5'
Register • Enregistrer • Regístrate
ShelterLogic.com
Base
68 1/2" x 56 1/2"
Size
174 cm x 143,5 cm
For proper base construction see page 14
Interior Dimensions
(Wall to Wall)
Depth
Height
54"
71"
137,2 cm
180,3 cm
01JY
Nominal Size
/
product-registration
Door
Opening
Width
Height
31"
62 3/4"
78,7 cm
159,4 cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SpaceMaker LWSM65 Series and is the answer not in the manual?

Questions and answers

FRANK MORENO
May 25, 2025

MISSING PARTS, CORNER CLIP 10280

0

Related Manuals for Arrow Storage Products SpaceMaker LWSM65 Series

Summary of Contents for Arrow Storage Products SpaceMaker LWSM65 Series

  • Page 1 01JY 731500821 Owner’s Manual & Assembly Guide Gloves must be worn Steel Shed Steel Shed at all times to reduce risk of injury! Model No. LWSM65 6’ x 5’ Nominal Size Register • Enregistrer • Regístrate ShelterLogic.com product-registration arrowshed.com Base 68 1/2”...
  • Page 3 SAFETY PRECAUTIONS... 02BA Safety precautions MUST be followed at all times throughout the construction of your building! Practice caution with the tools being used in Care must be taken when handling various the assembly of this building. Be especially pieces of your building since many contain familiar with the operation of all power tools.

  • Page 4: What You Need

    ASSEMBLY TIPS & TOOLS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building.

  • Page 5: Frequently Asked Questions

    04BA FREQUENTLY ASKED QUESTIONS How long will it take to assemble the building? Assembly time depends on a variety of factors, including roof design, tools available, DIY skill and the pace at which you work. Guidelines for each shed assembly are approximate AFTER completion of the base, and assume two or more people working on the assembly.
  • Page 6 05BA-NEW What kind of base do I use? You can: •Pour a concrete slab •Build a wood deck/fl oor (use exterior-grade plywood) •Use patio blocks •Build on crushed gravel, dirt or grass A continuous unbroken plastic vapor barrier with a thickness of 6 mil. between the ground and the building’s base is also recommended.
  • Page 7 06JY PANEL & CHANNEL ASSEMBLY TIPS PANEL Recommend a large table or sawhorses with plywood for working surface. Corners will need to hang off of work surface, so an elevated fl at surface is important. Arrows always point up, and always get covered. Start from middle and work your way out to push together panels.
  • Page 8 CARE & MAINTENANCE... 07JY Exterior Care: For a long lasting fi nish, clean and wax the exterior surface. We recommend washing with a mild soap solution. DO NOT use power washing to clean your shed. Using a spray automotive type wax periodically on the exterior is highly recommended if you are in a high humidity or coastal climate region.
  • Page 9 HARDWARE LIST... 08BY Hardware Views by Key No. Key Part Part Qty. Description List 65923 Bolt (#8-32 x 3/8) (10 mm) 65103 Hex Nut (#8-32) 65004 Screw (#8AB x 5/16) (8 mm) 66646 Washer Sheet 66715 Door Handle 66718 Hinge 66720 Padlock Eyelet Corner Cap...
  • Page 10 PARTS LIST... 09BY Key Part Part Qty. Selected End Views by Key No. Description List 10256 Floor Channel (unpainted) 1,3,4,5,8 2 & 9 10264 Ramp (unpainted) 10275 Horizontal Door Brace (painted) 10369 Vertical Door Brace (painted) 10361 Vertical Door Brace (painted) 10,11,15 11052 Door Jamb...
  • Page 11 ASSEMBLY BY KEY NO. 10BY...
  • Page 12 ASSEMBLY BY KEY NO. 11BY...

  • Page 13: Assembly Overview

    ASSEMBLY OVERVIEW 12BA...
  • Page 14 ASSEMBLY OVERVIEW 13BA...
  • Page 15 CONSTRUCTING A BASE... 14BA OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.). OPTION 2: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base: •...
  • Page 16 Step 1: Side Walls (2X) 15BA You will need for this page: 10307 10316 10268 Corner Panel Panel Wall Panel Wall 10268 10316 10307 10307 10307 10307 10316...
  • Page 17 Step 1: Side Walls (2X) 16BA You will need for this page: (QTY: 6) 10268 10316...
  • Page 18 Step 1: Side Walls (2X) 17BA You will need for this page: IMPORTANT 10261 START ASSEMBLY AT CORNER PANEL CORNER MUST BE AGAINST Wall Channel 45 DEGREE CUT ON CHANNEL 10261 10261 10261...
  • Page 19 Step 1: Side Walls (2X) 18BA IMPORTANT You will need for this page: 10255 10280 START ASSEMBLY AT CORNER PANEL CORNER MUST BE AGAINST 45 DEGREE CUT ON CHANNEL Floor Channel Corner Clip 10255 10268 10280 10280 10255 10280 10255 BE SURE TO MAKE TWO (2) SIDE WALL SECTIONS.

  • Page 20: Step 2: Rear Wall

    Step 2: Rear Wall 19BA You will need for this page: 10307 10316 10268 (QTY: 3) Corner Panel Panel Wall Panel Wall 10268 10316 10307 10307 10307 10307...
  • Page 21 Step 2: Rear Wall 20BA You will need for this page: IMPORTANT 10262 START ASSEMBLY AT CORNER PANEL CORNER MUST BE AGAINST Wall Channel 45 DEGREE CUT ON CHANNEL 10262 10262 10262...
  • Page 22 Step 2: Rear Wall 21BA You will need for this page: IMPORTANT 10256 10280 START ASSEMBLY AT CORNER PANEL CORNER MUST BE AGAINST 45 DEGREE CUT ON CHANNEL Floor Channel Corner Clip 10256 10268 10280 10280 10256 10280 10256...

  • Page 23: Step 3: Front Wall

    Step 3: Front Wall 22BA You will need for this page: 10268 11052 10316 (QTY: 4) (QTY: 1) Corner Panel Door Jamb Panel Wall 11052 11052 10316 10316 RIGHT LEFT RIGHT 10268 RIGHT...
  • Page 24 Step 3: Front Wall 23BK You will need for this page: 10262 10256 10263 10264 (QTY: 4) (QTY: 2) Wall Channel Floor Channel Header Trim Ramp 10262 10263 10263 10262 10256 10264 10264 10256...
  • Page 25 Step 3: Front Wall 24BA IMPORTANT You will need for this page: START ASSEMBLY AT CORNER PANEL 10280 CORNER MUST BE AGAINST 45 DEGREE CUT ON CHANNEL Channel Floor Channel Wall Channel (QTY: 4) Corner Clip Assembly Assembly (QTY: 4) WALL CHANNEL ASSEMBLY (Painted) 10280...

  • Page 26: Step 4: Wall Assembly

    Step 4: Wall Assembly 25BA You will need for this page: Side Wall Rear Wall Assembly Assembly (QTY: 3) CORNER PANEL ON TOP OF WALL PANEL Corner Clip Corner Panel Wall Panel REAR WALL SIDE WALL ASSEMBLY ASSEMBLY...
  • Page 27 Step 4: Wall Assembly 26BA You will need for this page: Side Wall Front Wall Assembly Assembly CORNER PANEL ON TOP OF WALL PANEL Corner Clip Corner Panel Wall Panel FRONT WALL ASSEMBLY SIDE WALL ASSEMBLY...
  • Page 28 Step 4: Wall Assembly 27BA You will need for this page: (QTY: 9)

  • Page 29: Side View

    28BA Step 5: Gable & Beam Assy You will need for this page: 80111 11048 10990 10278 Gable Left Gable Right (QTY: 8) (QTY: 4) Header Angle Gable Brace BACK 10990 80111 10990 80111 FRONT SIDE VIEW 80111 10990 11048 BACK BACK 10278...
  • Page 30 29BA Step 5: Gable & Beam Assy You will need for this page: 10312 10269 Ridge Beam (QTY: 6) (QTY: 4) Ridge Beam Angle 10269 10312 Large holes 10312 face down BACK FRONT BACK FRONT...
  • Page 31 30BA Step 6: Roof pre-assy (2X) You will need for this page: 10251 10252 10250 10267 10320 Roof Panel Roof Panel (QTY: 8) Roof Panel Roof Channel Fascia Trim Right Left 10250 10252 10252 10252 10251 10267 10250 10251 LARGE HOLES IN CHANNELS FACE 10267 DOWN...

  • Page 32: Step 7: Roof Assembly

    Step 7: Roof Assembly 31BA You will need for this page: 10270 Roof Assembly (QTY: 4) (QTY: 1) Ridge Cap LEFT Large holes face down FRONT FRONT LEFT INSIDE OF BUILDING BACK 10270 Large holes RIGHT face down...
  • Page 33 Step 7: Roof Assembly 32BA You will need for this page: 66860 Roof Assembly (QTY: 4) (QTY: 22) Peak Cap RIGHT Large holes face down FRONT FRONT RIGHT INSIDE OF BUILDING BACK 21,22 66860 19,20 66860 FRONT...
  • Page 34 Step 7: Roof Assembly 33BA You will need for this page: 66847 (QTY: 12) Corner Cap Vent 66847 66847 66847 66847...

  • Page 35: Step 8: Door Assembly

    Step 8: Door Assembly 34BK You will need for this page: 10361 10369 66715 66720 66721 (QTY: 4) Padlock U-Nut Vertical Door Vertical Door Door Handle Eyelet (Door Clip) Brace Brace 66721 (2X) 66721 (2X) 10361 66715 10369 66720 66715 66720 10369 SIDE VIEW...
  • Page 36 Step 8: Door Assembly 35BK You will need for this page: 10276 10309 10308 10275 Vertical Door Horizontal (QTY: 4) Door Panel Door Panel Door Panel Brace Assy Door Brace 10308 10309 10276 10275 10275...
  • Page 37 Step 8: Door Assembly 36BK You will need for this page: 10288 Diagonal (QTY: 3) (QTY: 9) Door Brace 10288 BACK 10288 FRONT...
  • Page 38 Step 8: Door Assembly 37BK You will need for this page: 66718 66720 66866 Door Assembly Padlock Door Closure (QTY: 8) (QTY: 6) Hinge Eyelet Clip 66718 66866 66718 66720 66720 66718 66866 66866...
  • Page 39 ANCHORING OPTIONS... 38JY IMPORTANT: It is important that building be anchored after construction. These are recommended ways of anchoring. Anchor into Wood or Concrete For wood platform. Use Decking Screws. For concrete slab. Use Lag Screws.
