Owner's Manual & Assembly Instructions
G1
Model No.
704740101
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
10' x 8'
121" x 92 3/4"
3,0m x 2,3m 307cm x 236cm
PM108
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
74
467
123 1/4"
6,9m
2
13,2m
3
VM108
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
95 1/4"
86"
313cm
242cm
218cm
Interior Dimensions
(Wall to Wall)
Width
Depth
Height Width Height
118 1/4"
90"
84 3/4" 55 1/2" 64 1/2"
300cm
229cm
215cm
Door
Opening
141cm 164cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM108 and is the answer not in the manual?

Questions and answers

Related Manuals for Arrow Storage Products PM108

Summary of Contents for Arrow Storage Products PM108

  • Page 1 Owner's Manual & Assembly Instructions Model No. PM108 VM108 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 704740101 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 2 BEFORE YOU BEGIN..Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.

  • Page 3: Tools And Materials

    PLAN AHEAD..BX03 Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 CARE & MAINTENANCE..A5 Web Finish: For long lasting finish, periodically clean and wax the exterior surface. Touch- up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 6 ACCESSORIES..A6 WEB ROOF STRENGTHENING (heavy snow load) KITS Extra roof beams and gable braces designed for added protection against heavy snow accumulation. Increases the strength of your roof by 50%. ANCHOR KIT ANCHOR KIT Model No. AK100 Model No. AK4 New concrete anchor system permits Anchor Kit contains heavy-duty steel anchoring any size Arrow building...
  • Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 9 Foundation The Foundation For Your Building OPTION 1: ARROW FLOOR FRAME KIT: (Order No. FB109-A or 68385-A) Arrow has the best base for your building in this simple kit. It keeps stored items above the ground. This kit should be used with one of the following: A.
  • Page 10 Anchoring Anchoring Down The Building It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia. Recommended for use with any suggested base.
  • Page 11 Hardware Remove from bag of screws and save for the last step 65900A 65103 #10Bx1/2" Black Screw (4) 65923 65004 #8-32 Hex Nut (153) (Packed with Screws) #8-32x3/8" Bolt (153) #8Ax5/16" Screw (304) 67468 66646 67545 Peak Cap (1) 66045 Washer (198) Handle (2) Weather Stripping (1)

  • Page 12: Parts List

    Parts List Assembly Part Part Quantity Check Key No. Number Description in Carton List 3719 Door Handle Brace 5290 Front Siding (6 Board) 5291 Front Siding (3 Board) 5306 Rear Siding (6 Board) 5307 Rear Siding (3 Board) 5986 Rear Wall Angle 6264 Horizontal Door Brace 6403...
  • Page 13 Assembly by Key No.
  • Page 14 8934 Ramp (1) Parts Needed For 9367 Front Floor Frame (2) Step 1 8936 Rear Floor Frame (2) Floor Frame Assemblies 9203 Side Floor Frame (4) The front floor frame is made up of three pieces. The side floor frames 9367 and the rear floor frame are made up of two pieces.

  • Page 15: Frame Assemblies

    Parts Needed For 5986 Rear Wall Angle (2) Step 2 8841 Side Wall Angle (4) Frame Assemblies The main frame pieces reinforce the walls. These pieces will later be in- stalled at the top edge of the side walls and the rear wall. Proceed as follows: 5986 Overlap the rear wall angle pieces...
  • Page 16 Parts Needed For 8834 Right Roof Beam (4) Step 3 Roof Beam Assemblies 8835 Left Roof Beam (4) The roof beams join the two gables and support the roof panels. The main roof beam is made up of four pieces overlapped, back to back at the cen- Left ter.

  • Page 17: End View

    Parts Needed For 6403 Door Track Splice (1) Step 4 Door Track Assembly 9366 Door Track (2) NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall. It is made up of three pieces. 6403 Using the door track splice, (painted), join the door track...
  • Page 18 Front Floor Assembly (1) Parts Needed For Step 5 Side Floor Assembly (2) Floor Frame Rear Floor Assembly (1) RIGHT REAR 9203 STEP Assemble the four corners of the 8936 floor frame using two screws at each corner as shown. At the front corners fasten bolts through...

  • Page 19: Top View

    9196 Right Corner Post (2) 9197 Left Corner Post (2) Parts Needed For Step 6 Door Track Assembly (1) Posts/Top Frames Rear Wall Angle Assembly (1) Side Wall Angle Assembly (2) NOTE The remainder of the building assembly requires many hours and more than one person.
  • Page 20 9195 Splice Post (1) Parts Needed For Step 7 9198 Side Splice Post (2) Splice Post/Door Jamb 9194 Door Jamb (2) STEP The door jambs reinforce the door opening and provide an attractive ANGLED END OF SPLICE POST MUST trim. The splice post supports the BE ON TOP wall.
  • Page 21 Parts Needed For Step 8 9199 Siding Stud (6) Studs The studs provide a surface for at- taching the siding panels. Following dimensions, measuring from the ends of angles, place a stud between each corner and splice post. Position stud inside top angle and fasten with a screw.

  • Page 22: Side Siding

    Parts Needed For 8584 Side Siding (5 Board) (4) Step 9 8585 Side Siding (3 Board) (4) Side Siding 8583 Side Siding (6 Board) (4) Each screw in the wall requires a washer. Slide side siding (5 board) into channels of corner and splice posts, flat edge upward, bottom edge down (6 board) resting on floor frame.
  • Page 23 8736 Rear Siding (5 Board) (2) 5307 Rear Siding (3 Board) (2) Parts Needed For Step 10 5306 Rear Siding (6 Board) (2) 8737 Front Siding (5 Board) (2) Rear/Front Siding 5291 Front Siding (3 Board) (2) 5290 Front Siding (6 Board) (2) STEP STEP Slide rear siding (5 board) into...
  • Page 24 Parts Needed For 8576 Right Gable (2) Step 11 8577 Left Gable (2) Gable Assemblies 6635 Roof Beam Bracket (4) The gables go on top of the front and rear walls to support the roof beams. NOTE The gables are packed nested together and might be mistaken as one piece.
  • Page 25 Left Gable Assemblies (2) Parts Needed For Step 12 Right Gable Assemblies (2) Gables/Braces 9009 Gable Brace (2) Lift and fasten a right and left gable, under angle at corner, to the rear wall angel with screws. Hint: On the rear gable, use a bolt and nut at the overlapping rear wall angle.
  • Page 26 Main Roof Beam (1) Parts Needed For Step 13 Single Roof Beam (2) Roof Beam/Braces 9204 Roof Beam Brace (2) Apply the weather stripping along the mating edge of the left and right STEP gables as shown. Cut the weather stripping to length.
  • Page 27 Parts Needed For Step 14 8578 Right Roof Panel (1) Right Roof Panel STEP Installing the roof panels is best done with a step ladder. Begin installing 8579 8578 roof panels at the back right corner of the building. Each screw and bolt in the roof requires a washer.
  • Page 28 8578 Right Roof Panel (1) 8579 Left Roof Panel (2) Parts Needed For Step 15 7571 Roof Panel (2) Roof Assembly 7743 Roof Panel (2) 8840 Ridge Cap (1) STEP 8579 Left Roof Panel Weather Stripping Install a left roof panel at the left 7571 Roof Panel Tape Roll rear and right front corner of the roof.
  • Page 29 8486 Ridge Cap (1) 7571 Roof Panel (2) Parts Needed For Step 16 8840 Ridge Cap (1) Panels/Ridge Cap/Trim 8485 Left Side Roof Trim (2) 8836 Right Side Roof Trim (2) STEP Install the second ridge cap over- 8486 lapping the first ridge cap while in- Cut Weather Stripping stalling the remaining roof panels.

  • Page 30: Door Assembly

    3719 Door Handle Brace (2) Parts Needed For 9200 Right Door (1) Step 17 9201 Left Door (1) Door Assembly 6264 Horizontal Door Brace (4) 9202 Vertical Door Brace (2) The steps on this page tell how to assemble the right door. You will perform exactly the same procedures for the left door.
  • Page 31 Parts Needed For Right Door Assembly (1) Step 18 Door Installation & Adjustment Left Door Assembly (1) Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP STEP building) behind door jamb into the...
  • Page 32 PM108 VM108 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
