- Page 1 Installation &Operation Manual MiniPool Heat Pump Model: YC-005TB1 Thank you very much for purchasing our product, please keep this installation manual carefully and read this manual carefully before you install heat pump.
- Page 2 ...
- Page 3 Please keep installation manual properlyand read itcarefully before using. ‐ The unit must be installed by professional personnel, and install it based on this manual as possible. ‐ If the unit would be installed where is vulnerable to lightningstroke, lightning protectionmeasurements must be carried out. ‐ Themanufacturerdeclinesanyresponsibilityforthedamagecausedwiththepeople,objectsandoftheerrorsduetoth einstallation that disobey the manual guideline.Anyuse that is without conformityattheoriginofitsmanufacturingwill be regardedasdangerous. ‐ Please always keep the heat pump in the ventilation place and away from anything which could cause fire. ‐ Don’t weld the pipe if there is refrigerant inside machine. Please keep the machine out of the confined space when make gas filling. ‐ Please always empty the water in heat pump during winter time or when the ambient temperature drops below 32°F, or else the Titanium exchanger will be damaged because of being frozen, in such case, it will be out of warranty for this machine. ‐ Please always cut the power supply if you want to open the cabinet to reach inside the heat pump, because there is high voltage electricity inside. ‐ Please well keep the display controller in a dry area to protect the display controller from being damaged by humidity. ‐ Action of filling gas must be conducted by professional with R410A operating license. * INDEX 1. Specifications 2. Dimension 3. Installation and connection 4. Electrical wiring 5. Display controller operation 6. Trouble shooting 7. Exploded diagram 8. Maintenance ...
-
Page 4: Specifications
1. Specifications 1.1 Technical data pool heat pumps YC-005TB1 *Above data is subject to modification without prior notice. - 2 -... -
Page 5: Dimension（Mm
2. Dimension（mm） 3.Installation and connection Attention: Please observe the following rules when installing the heat pump: 1. Any addition of chemicals must take place in the piping located downstream from the heat pump. 2. Always hold the heat pump upright. If the unit has been held at an angle, wait at least 24 hours before starting the heat pump. 3.1 Heat pump location The unit will work properly in any desired location as long as the following three items are present: 1. Fresh air – 2. Electricity – 3. Swimming pool filters ... - Page 6 to circulate through the heat pump. The heat pump will not start up if the water is not circulating. 3.3 Electrical connection Before connecting the unit, verify that the supply voltage matches the operating voltage of the heat pump. The RCD plug has been included with power cable, which can offer electrical protection. Attention: Ensure the power plug is secure Never pull out the power plug during Never use damaged electric wires operation or unspecified electric wires. If the plug is not secure, it may cause an electric shock, over‐heating or Otherwise, it may cause an electric Otherwise it may cause an electric fire shock or a fire due to over‐heating. shock or a fire. After all connections have been made and checked, carry out the following procedure: 1. Switch on the filter pump. Check for leaks and verify that water is flowing from and to the swimming pool. on the electronic control panel. The 2. Connect power to the heat pump and press the On/Off button unit will start up after the time delay expires (see below). ...
-
Page 7: Electrical Wiring
water, which may cause condensation on the fins of the evaporator. The amount of condensation may be as much as several litters per hour at high relative humidity. This is sometimes mistakenly regarded as a water leak. 4.Electrical wiring 4.1 Swimming pool heat pump wiring diagram NOTE: (1) Above electrical wiring diagram only for your reference, please subject machine posted the wiring diagram. (2) The swimming pool heat pump must be connected ground wire well, although the unit heat exchanger is electrically isolated from the rest of the unit. Grounding the unit is still required to protect you against short circuits inside the unit. Bonding is also required. Disconnect: A disconnect means (circuit breaker, fused or un‐fused switch) should be located within sight of and readily accessible from the unit. This is common practice on commercial and residential heat pumps. It prevents remotely‐energizing unattended equipment and permits turning off power at the unit while the unit is being serviced. - 5 -... -
Page 8: Display Controller Operation
5. Display controller operation 5.1 The interface of controller When the heat pump is running or standby, the display shows the water inlet temperature. When the heat pump is Power‐on, the display shows ‘OFF’ will light on when you turn on the machine. will be lighting on, will flash. When defrosting, Turn on/off the heat pump to turn on the heat pump, the LED display shows the water setting temperature for 3s, then Press show water inlet temperature. again to turn off the heat pump, it will show ‘OFF’ on the display. press NOTE: There is 3 mini of time delay protection for the compressor. 5.3 Set the desired water temperature or directly to adjust the desired water temperature, the data will be saved in 3 Press ... -
Page 9: Troubleshooting
for 3 seconds to switch Celsius (℃) and Fahrenheit (℉) Hold 6. Trouble shooting 6.1 Error code on the LED controller Malfunction Code Reason Solution 1. Check the sensor wiring. Water temperature Water temperature sensor open P1 2.Replace the new water temperature sensor failure circuit or short circuit. sensor. 1. Check the sensor wiring. Piping temperature sensor Piping temperature sensor open P3 2.Replace the new piping temperature failure circuit or short circuit. sensor. 1. Check the sensor wiring. Ambient temperature Ambient temperature sensor P5 2.Replace the new water temperature sensor failure open circuit or short circuit. sensor. 1. Wait the ambient temperature Too low or too high 1. Ambient temperature is out of recover the operation range. ambient temperature E0 operating range: 23°F~109.4°F. ... - Page 10 6.2 Other Malfunctions and Solutions (No display on LED wire controller) Malfunctions Observing Reason Solution No power supply. LED wire controller Check cable and circuit breaker if no display. it is connected. Heat pump is 1. Water temperature is not running 1. Verify water temperature LED wire controller reaching to setting value, HP setting. displays the actual under constant temperature 2. Start up heat pump after a few water temperature. status. minutes. 2. Heat pump just starts to run. 1. Check the cable connections between the motor and fan, if LED displays actual necessary, it should be replaced. 1. Fan NO running. Short running water temperature, no 2. Check the location of heat 2. Air ventilation is not enough. error code displays. ...
-
Page 11: Exploded Diagram
7. Exploded diagram No. Name Name 1 Base tray refrigerant valve 2 Front panel Titanium heat exchanger 3 Back pillar Evaporator 4 Controller compressor 5 Fan grill Top cover - 9 -... - Page 12 8. Maintenance (1) You should check the water supply system regularly to avoid the air entering the system and occurrence of low water flow, because it would reduce the performance and reliability of HP unit. (2) Clean your pools and filtration system regularly to avoid the damage of the unit as a result of the dirty of clogged filter. (3) You should discharge the water from heat pump if it will stop running for a long time (especially during the winter season). (4) In another way, you should check the unit is water fully before the unit start to run again. (5) When the unit is running, there is all the time a little water discharge under th - 10 -...
- Page 13 - 11 -...
- Page 14 ...
