Component Specifications

See below for information on serviced equipment.
Equipment Compac
Item Code
Coalescing
filters
Compac
filter/check FCVCI-12-SS
valve
Solenoid
SCI-12-SS
valve
Regulator
RCI-12-SS
valve
Specifications
The coalescing filters are designed
to trap dirt, moisture, oil, and other
debris that may damage the valve
Grade 10
seals. A Grade 10 coalescing filter
Coalescing Filter
will remove 95% of liquid aerosols
in the 0.3 to 0.6 micron range.
The filter/check valve prevents
back-flow from the high storage to
3/4" SAE female
the medium and low storage, and
inlet.
from the medium storage to the
2 x 3/4" SAE
low storage.
female outlets.
The valve has a metal to metal seat
350 bar max.
and should not leak or require
servicing.
The high flow solenoid valve is
3/4" SAE female
designed to control the flow of gas
inlet.
in a CNG Dispenser.
3/4" SAE female
Between the inlet and outlet, the
outlet.
valve opens with a differential
275 bar max.
pressure of more than 275 bar.
The regulator is a high flow valve,
designed to limit the outlet
pressure of the dispenser.
In the fixed pressure dispenser,
3 x 3/4" SAE
the regulator limits the final fill
female inlets.
pressure to 200 bar.
3/4" SAE female
In the temperature compensating
outlet.
dispenser, the regulator acts as a
275 bar max.
safety device to limit the amount of
over-pressure if the main solenoid
fails to shut off at the correct
pressure.
82.
