ASRock Industrial IMB-X1314 Settings Manual

IMB-X1314
®
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
Revision History
Date Description
December 30, 2022 First Release
March 14, 2023 Second Release
August 21, 2023 Third Release
COM Port Pin9 PWR Setting Jumpers
1 : PWR_COM1 (For COM Port1)
PWR_COM2 (For COM Port2)
26 : PWR_COM3 (For COM Port3)
PWR_COM4 (For COM Port4)
PWR_COM5 (For COM Port5)
PWR_COM6 (For COM Port6)
1-2 : +5V
2-3 : +12V
2 : 4-Pin Chassis FAN Connector
(+12V) (CHA_FAN1)

3 : ATX 12V Power Connector

4 : 4-Pin Chassis FAN Connector
(+12V) (CHA_FAN3)
5 : 4-Pin CPU FAN Connector
(+12V) (CPU_FAN1)
7 : Power Loss Header (PWR_LOSS1)
Short : Power Loss
Open : No Power Loss

8 : 24-pin ATX Power Input Connector

9 : System Panel Header

10 : Thunderbolt AIC Connector (TB1)
IntA_PA_SSRX-
11 : USB 3.2 Gen1 Header
IntA_PA_SSRX+
(USB3_5_6)
IntA_PA_SSTX-
IntA_PA_SSTX+
IntA_PA_D-
IntA_PA_D+
13 : Brightness Control Mode (BLT_PWM1)
1-2 : From eDP PWM to CON_LBKLT_CTL
2-3 : From LVDS PWM to CON_LBKLT_CTL
* Please set to 1-2 when adjusting brightness by Brightness Control bar under OS.
* Please set to 2-3 when adjusting brightness by BLT_VOL1.

Jumpers and Headers Setting Guide

1 2
USB 3.2 Gen2
49
Top:
T: USB3_1
LAN3
B: USB3_2
CHA_FAN1 CHA_FAN1
1 1
I225_LED3
1 1
48
47
1 1
46 Top:
LAN2
USB 3.2 Gen2 USB 3.2 Gen2
Top:
45
T: USB3_3 T: USB3_3
LAN1
B: USB3_4 B: USB3_4
44
43
PS2_KB_MS1
42
1
41
1 1
I225_LED2
1 1
I225_LED1
40
PCIE2
39
CHA_FAN2 CHA_FAN2
38
1 1 CLRMOS2 CLRMOS2
37
1 1 SIO_AT1 SIO_AT1
1 1
SPDIF1 SPDIF1
HD_AUDIO1
36
35 DACC1
1
CMOS CMOS
SPEAKER1
34 Battery Battery
1
33
1
BUZZ2 PCIE4
32
1 1 1
31
CI2
JGPIO_SET1
PWR_COM3 PWR_COM4
30
1 1 1 1
1 1 1 1
1
CLRMOS1 JGPIO_PWR1 JGPIO_PWR1
SMBUS_TEST1
1
COM3
1 1 LPT_GPIO1
29 28 27 26
14 : Panel Power Select (PNL_PWR1)
1-2 : +3V
2-3 : +5V
4-5 : +12V
15 : CON_LBKLT_EN and CON_LBKLT_CTL
Voltage Level (BLT_EN_PWM1)
1-2 : 3V Level
2-3 : 5V Level
16 : Inverter Power Control Wafer (BLT_PWR1)
FAN_SPEED_CONTROL
1
CHA_FAN_SPEED
+12V
GND
8 5
4
1
FAN_SPEED_CONTROL
Chassis Intrusion Headers (CI1, CI2)
CHA_FAN_SPEED
+12V 17 : CI1 :
GND
Short : Active Case Open
GND
+12V Open : Normal
CPU_FAN_SPEED
FAN_SPEED_CONTROL
31 : Cl2 :
Short : Normal
12 24
Open : Active Case Open
18 : Backlight & Amp Volume Control
(BLT_VOL1)
1 13
1
19 : Backlight Power Select
(LCD_BLT_VCC) (BKT_PWR2)
Vbus Vbus
1-2 : LCD_BLT_VCC : +5V
Vbus IntA_PB_SSRX-
IntA_PB_SSRX+
2-3 : LCD_BLT_VCC : +12V
GND
GND IntA_PB_SSTX-
IntA_PB_SSTX+
GND
20 : LVDS Panel Connector
GND IntA_PB_D-
IntA_PB_D+
Dummy
1
3 4 5 6
CHA_FAN3 CHA_FAN3 CPU_FAN1 CPU_FAN1
ATX12V1 ATX12V1
PCIE1
IMB-X1314
PCIE3
USB2_10_11 USB2_10_11
PWR_COM5 PWR_COM6
1 1
1 1 1 1
ESPI1 ESPI1
1 1 1 1 1
1 1
USB2_12_13 USB2_12_13
COM4 COM5 COM6
25 24 23 22
3 2 1
PIN Signal Name
1 GND
2 GND
3 CON_LBKLT_CTL
4 CON_LBKLT_EN
5 LCD_BLT_VCC
6 LCD_BLT_VCC
1
PIN Signal Name
1 GPIO_VOL_UP
2 GPIO_VOL_DW
3 PWRDN
4 GPIO_BLT_UP
5 GPIO_BLT_DW
6 GND
7 GND
2 1
* PD (Panel Detection):
Connect this pin to LVDS
Panel's Ground pin to
detect Panel detection.
40 39
7
1
PWR_LOSS1
8
1
9
1
10
11
SIM1 SIM1
12
Industrial Industrial
1 1 1 1 1 1
13
1 1
14
BLT_PWM1 BLT_PWM1
PNL_PWR1 PNL_PWR1
15
BLT_EN_PWM1
1 1 16
1
1
17
CI1
18
19
1 1
20
BIOS
ROM
SATA3_6 SATA3_6 SATA3_4 SATA3_4 SATA3_2 SATA3_2 SATA3_0 SATA3_0
SATA3_7 SATA3_7 SATA3_5 SATA3_5 SATA3_3 SATA3_3 SATA3_1 SATA3_1
21
1
PIN Signal Name PIN Signal Name
2 R_LVDD 1 R_LVDD
4 LDDC_CLK 3
6 LVDS_A_DATA0# 5 LDDC_DATA
8 PD (Panel Detection) 7 LVDS_A_DATA0
10 LVDS_A_DATA1 9 LVDS_A_DATA1#
12 LVDS_A_DATA2# 11
14 GND 13 LVDS_A_DATA2
16 LVDS_A_DATA3 15 LVDS_A_DATA3#
18 LVDS_A_CLK# 17
20 GND 19 LVDS_A_CLK
22 LVDS_B_DATA0 21 LVDS_B_DATA0#
24 LVDS_B_DATA1# 23
26 GND 25 LVDS_B_DATA1
28 LVDS_B_DATA2 27 LVDS_B_DATA2#
30 LVDS_B_DATA3# 29 DPLVDD_EN
32 GND 31 LVDS_B_DATA3
34 LVDS_B_CLK 33 LVDS_B_CLK#
36 CON_LBKLT_EN_R 35
38 LCD_BLT_VCC 37 CON_LBKLT_CTL_R
40 LCD_BLT_VCC 39 LCD_BLT_VCC

21 : SATA3 Connectors (SATA3_0~7)

23 : USB 2.0 Headers
(USB2_10_11,
USB2_12_13)
24 : ESPI Header

25 : COM Port Headers (COM3,4,5,6) (RS232)

Signal Signal
PIN PIN PIN
Name Name
9 +5V 7 RRTS# 5
10 N/A 8 CCTS# 6
27 : Digital Input / Output Power Select
(JGPIOPWR) (JGPIO_PWR1)
1-2 : +12V
2-3 : +5V
3-4 : +5V
4-5: GND

Clear CMOS Headers

28 : CLRMOS1 :
1-2 : Normal
2-3 : Clear CMOS
39 : CLRMOS2 :
Short : Auto Clear CMOS (Power Off)
Open : Normal
+3V
GND
GND
GND
GND
1
Signal Signal Signal
PIN PIN
Name Name Name
GND 3 TTXD 1 DDCD#
DDSR# 4 DDTR# 2 RRXD
