Digital Watchdog Star-Light Plus DWC-VA853WTIR User Manual page 13

Installation - Instructions
Using the mounting template or your camera,
1
mark and drill the necessary holes in the
mounting surface.
Pull all necessary wires through and make the
2
proper connections. See pages 14.
Use the two (2) mounting screws to install the
3
camera onto the mounting surface. See page
15 for tilting and pan adjustment options.
When the installation is complete, remove the
4
protective sticker from the camera's lens.
Protective sticker
13
Mounting template
