Independent domestic hot water tanks
BP 150...500
300011515-001-E
Installation, User
and Service
Manual
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BP 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DeDietrich BP 150

Summary of Contents for DeDietrich BP 150

  • Page 1 Independent domestic hot water tanks BP 150...500 Installation, User and Service Manual 300011515-001-E...

  • Page 2: Table Of Contents

    Contents Introduction ....................4 Used symbols ............4 Abbreviations ............4 General ..............4 1.3.1 Manufacturer's liability ..........4 1.3.2 Installer's liability .............5 1.3.3 User's liability ............5 Homologations ............6 1.4.1 Certifications ............6 1.4.2 Directive 97/23/EC ..........6 1.4.3 Factory test .............6 Safety instructions and recommendations ..........7 Safety instructions ..........7 Recommendations ..........7 Technical description ................8...
  • Page 3 Contents Hydraulic connections ........15 4.6.1 Hydraulic connection of the primary circuit (exchanger circuit) ..............15 4.6.2 Connecting the tank to the domestic water circuit (secondary circuit) ..........15 Electrical connections ........17 4.7.1 Recommendations ..........17 4.7.2 Fitting the DHW sensor .........18 Commissioning ..................19 Putting the appliance into operation ....19 Checking and maintenance ..............20 General instructions ...........20...
  • Page 4 01/03/2011 - 300011515-001-E...

  • Page 5: Introduction

    BP 150...500 1. Introduction Introduction Used symbols In these instructions, various danger levels are employed to draw the user's attention to particular information. In so doing, we wish to safeguard the user's safety, obviate hazards and guarantee correct operation of the appliance.

  • Page 6: Installer's Liability

    1. Introduction BP 150...500 In the interest of customers, we are continuously endeavouring to make improvements in product quality. All the specifications stated in this document are therefore subject to change without notice. Our liability as the manufacturer may not be invoked in the following cases: 4 Failure to abide by the instructions on using the appliance.

  • Page 7: Homologations

    BP 150...500 1. Introduction Homologations 1.4.1. Certifications This product complies to the requirements to the european directives and following standards: 4 2006/95/EC Low Voltage Directive. Reference Standard: EN 60.335.1. 4 2004/108/EC Electromagnetic Compatibility Directive. Reference Standards: EN 50.081.1, EN 50.082.1, EN 55.014 1.4.2.

  • Page 8: Safety Instructions And Recommendations

    2. Safety instructions and recommendations BP 150...500 Safety instructions and recommendations Safety instructions CAUTION Before any work, switch off the mains supply to the appliance. CAUTION In order to limit the risk of being scalded, the installation of a thermostatic mixing valve on the domestic hot water flow piping is compulsory.

  • Page 9: Technical Description

    BP 150...500 3. Technical description Technical description General description DHW calorifiers BP 150...500 can be connected to central heating boilers used for heating domestic hot water. Main parts: 4 The tanks are made of high quality steel lined with food quality standard enamel vitrified at 850°C, which protects the tank from...

  • Page 10: Specifications Of The Dhw Sensor

    3. Technical description BP 150...500 BP 150 BP 200 BP 300 BP 400 BP 500 1080 1350 1720 2290 Flow per hour (∆T = 35 °C Specific flow (∆T = 30°C) (10 minutes) Maintenance consumption (ΔT=45K) kWh/24h (1) Primary temperature: 80 °C - Domestic cold water inlet: 10 °C - Domestic hot water outlet: 45 °C - Primary flow rate: 3 m 3 /h (2) Primary temperature: 80 °C - Domestic cold water inlet: 10 °C - Domestic hot water outlet: 40 °C - Domestic hot water storage: 40 °C...

  • Page 11: Installation

    Standard delivery The delivery includes: 4 One DHW tank. 4 One installation, use and service manual. BP 150 BP 200 BP 300 BP 400 BP 500 DHW tank package EC 400 EC 401 EC 402 EC 403 EC 404 4.2.2. Accessories...

  • Page 12: Choice Of The Location

    4. Installation BP 150...500 BP 150 BP 200 BP 300 BP 400 BP 500 Multi-voltage shielded resistor EC 413 EC 413 4.5 kW Multi-voltage steatite heating EC 411 resistance 2.4 kW Multi-voltage steatite heating EG 88 resistance 3 kW SLA2 control system for load...

  • Page 13: Main Dimensions

    T Exchanger outlet Y Drain opening U Magnesium anode a Domestic hot water sensor (1) Adjustable feet G : Exterior cylindrical threading, sealed by sheet gasket BP 150 BP 200 BP 300 BP 400 BP 500 1012 1192 1516 1535 1494 G (Ø)

  • Page 14: Levelling

    Levelling is done using the adjustable feet located on the base of the domestic hot water tank: 4 BP 150 - BP 200 - BP 300: 3 adjustable feet 4 BP 400 - BP 500: 4 adjustable feet (1) Adjustment range: 30 mm...

  • Page 15: Safety Unit (For France )

    BP 150...500 4. Installation Drain cock Filling the heating circuit DHW tank heat exchanger primary inlet DHW tank heat exchanger primary outlet DHW pump Non-return valve Domestic cold water inlet Pressure reducer Safety unit 7-bar safety valve D.H.W. loop back pump...

  • Page 16: Hydraulic Connections

    4. Installation BP 150...500 Hydraulic connections 4.6.1. Hydraulic connection of the primary circuit (exchanger circuit) ¼ See diagram : "Hydraulic installation diagram", page 13. For the hydraulic connection of 150 l to 300 l tanks and the boiler (right or left), we offer optional hydraulic connection kits.
  • Page 17 BP 150...500 4. Installation n Size The safety device and its connection to the DHW tank must be of at least the same diameter as the domestic cold water supply pipe of the tank domestic circuit. No isolating devices should be located between the valve or safety device and tank.

  • Page 18: Electrical Connections

    4. Installation BP 150...500 n Pressure reducer If the mains pressure exceeds 80% of the valve or safety unit setpoint (e.g.: 5.5 bar for a safety unit set at 7 bar), a pressure reducer must be fitted upstream of the appliance. Install the pressure reducer downstream the water meter in such a way as to ensure the same pressure in all of the installation pipes.

  • Page 19: Fitting The Dhw Sensor

    BP 150...500 4. Installation 4.7.2. Fitting the DHW sensor D000882 01/03/2011 - 300011515-001-E...

  • Page 20: Commissioning

    5. Commissioning BP 150...500 Commissioning Putting the appliance into operation CAUTION Initial commissioning must be done by a qualified professional. 1. Flush the domestic circuit and fill the tank through the cold water inlet tube. 2. Open a hot water tap.

  • Page 21: Checking And Maintenance

    BP 150...500 6. Checking and maintenance Checking and maintenance General instructions CAUTION Maintenance operations must be done by a qualified engineer. Only original spare parts must be used. Checking the magnesium anode Carry out a visual check of the anode.
  • Page 22 1. Cut off the cold water supply and drain the DHW tank. 2. Remove the inspection traps. Model BP 150 BP 200 BP 300 BP 400 BP 500 Diagram C + D A + C B + C B + C 3.

  • Page 23: Maintenance Form

    BP 150...500 6. Checking and maintenance Maintenance form Date Checks made Remarks Signature _____ _________ ______________________________ _____________________ _______________ ____________ 01/03/2011 - 300011515-001-E...

  • Page 24: Spare Parts

    7. Spare parts BP 150...500 Spare parts General When it is observed subsequent to inspection or maintenance work that a component in the appliance needs to be replaced, use only original spare parts or recommended spare parts and equipment. To order a spare part, give the reference number shown on the list.

  • Page 25: Domestic Hot Water Tanks

    BP 150...500 7. Spare parts 7.2.1. Domestic hot water tanks n BP 150 L000117-C Markers Reference Description 97525077 Top cover 200007092 Complete top mounting 89705511 Seal kit 7 mm + retainer ring 300011041 *1 thermometer 97860646 Adjustable foot M10 x 35 89658518 Side cover Ø...
  • Page 26 7. Spare parts BP 150...500 n BP 200 L000118-C Markers Reference Description 300011075 Top cover 89555506 Complete top mounting Ø 112 89705511 Seal kit 7 mm + retainer ring 300011041 *1 thermometer 97860646 Adjustable foot M10 x 35 89658526 Complete lateral trap ø 82 95013133 Lip seal outside Ø...
  • Page 27 BP 150...500 7. Spare parts n BP 300 L000119-C Markers Reference Description 300011075 Top cover 89705511 Seal kit 7 mm + retainer ring 300011041 *1 thermometer 97860646 Adjustable foot M10 x 35 89658518 Complete lateral trap ø 82 95013133 Lip seal outside Ø 82 89708901 Complete anode Ø...
  • Page 28 7. Spare parts BP 150...500 n BP 400 L000120-C Markers Reference Description 300011075 Top cover 89705511 Seal kit 7 mm + retainer ring 300011041 *1 thermometer 97860646 Adjustable foot M10 x 35 94974527 Nylon brace 95014035 Seal ø 35 x 8.5 x 2...
  • Page 29 BP 150...500 7. Spare parts n BP 500 L000120-C Markers Reference Description 300011075 Top cover 89705511 Seal kit 7 mm + retainer ring 300011041 AFRISO thermometer 97860646 Adjustable foot M10 x 35 94974527 Nylon brace 95014035 Seal ø 35 x 8.5 x 2...

  • Page 30: Options

    7. Spare parts BP 150...500 7.2.2. Options n Titanium anode - Package EC 414 Markers Reference Description 200000093 Titanium anode 88014964 Wiring 200007959 Screw bag n 2.2 kW heating element - Package EC 410 - Ø 82 Markers Reference Description 95013133 Lip gasket Ø...
  • Page 31 BP 150...500 7. Spare parts Markers Reference Description 200008224 Clamping flange Holes, diameter 82 89624900 Earth wire 89624901 Resistance cables 89625507 Earthing 89604901 Earth wire 95363327 Thermostat n 2.4 kW heating element - Package EC 411 - Ø 82 Markers Reference Description 95013133 Lip gasket Ø...
  • Page 32 7. Spare parts BP 150...500 n 3.3 kW heating element - Package EC 412 - Ø 82 Markers Reference Description 95013133 Lip gasket Ø 82 200008225 Heating element 3300 W 89625506 Magnesium anode Ø 40 - Length 410 95014035 Seal ø 25 x 8.5 x 2...
  • Page 33 BP 150...500 7. Spare parts n 4.5 kW heating element - Package EC 413 - Ø 82 Markers Reference Description 95013141 Sheet gasket Ø 170 200008220 Heating element 4500 W 200007580 Complete Anode 95014035 Seal ø 25 x 8.5 x 2...
  • Page 34 7. Spare parts BP 150...500 n 3 kW heating element - Package EG 88 Markers Reference Description 95013133 Lip gasket Ø 82 97863562 Heating element 3000 W - Three-phase 97862759 Heating body 97866635 Fastening plate 200006681 Power supply wires (x3)

  • Page 35: Warranty

    BP 150...500 8. Warranty Warranty General You have just purchased one of our appliances and we thank you for the trust you have placed in our products. Please note that your appliance will provide good service for a longer period of time if it is regularly checked and maintained.
  • Page 36 8. Warranty BP 150...500 4 the rules of the profession. The warranty is limited to the exchange or repair of such parts as have been recognised to be faulty by our technical department and does not cover labour, travel and carriage costs.
  • Page 37 BP 150...500 8. Warranty 01/03/2011 - 300011515-001-E...
  • Page 40 © Copyright All technical and technological information contained in these technical instructions, as well as any drawings and technical descriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. 01/03/2011 DE DIETRICH THERMIQUE 57, rue de la Gare F- 67580 MERTZWILLER - BP 30...

This manual is also suitable for:

Bp 200Bp 300Bp 400Bp 500
