42
en | Connection
Figure 6.6 Loop-through connection of radiators
NOTICE!
For the automatic cable termination to work, never leave an open-ended cable connected to
the last radiator in a loop-through chain.
When connecting infra-red radiators, do not split the cable, else the system will not function
correctly.
IOM-INT | V1.1 | 2010.12
Installation and Operation manual
Integrus
Bosch Security Systems B.V.
