Bosch RADION RFUN Installation Manual

RADION universal transmitter
RFUN/RFUN-A
Installation Guide
1
1
3
© 2013 Bosch Security Systems, Inc.
33.02 mm
19.5 mm
(1.30 in)
(0.76 in)
82.55 mm
(3.25 in)
12.5 mm 18.5 mm
(0.49 in) (0.72 in)
24.5 mm
(0.97 in)
UL - only model RFUN-A is evaluated by UL
UL365: Standard for Police Connected Burglar Alarm Units and System
UL609: Standard for Local Burglar Alarm Units and Systems
UL634: Connectors and Switches for use with Burglar Alarm Systems
UL1023: Household Burglar Alarm System Units
UL1076: Standard for Propriety Burglar Alarm Units and Systems
UL1610: Standard for Central-Station Burglar-Alarm Units
FCC, Part 15
Classifi ed to ANSI/SIA CP01-2010
2
2
P/N: F.01U.261.834-02 - B810
P/N: F.01U.261.835-02 - RFRC-OPT
Duracell DL123A Lithium 3 VDC
Panasonic CR123A Lithium 3 VDC
Sanyo CR123A Lithium 3 VDC
P/N: F.01U.261.834-02 - B810
P/N: F.01U.261.835-02 - RFRC-OPT
3
<20.32 mm
(0.80 in)
433.42 MHz
0°C to +49°C
(+32°F to +120°F)
0 - 93% Non-condensing
humidity
4
