- Page 1 Instruction / Installation Manual 60cm Chimney Hood L60CHDB12 (Black) L60CHDS12 (Silver)
-
Page 3: Table Of Contents
Contents Safety Warnings ..........................4 Unpacking ............................. 8 Product Overview ......................... 9 Modes of Operation ........................10 Air Extraction ................................10 Air Recirculation ..............................10 Operation ............................ 10 To Select the Fan Motor Speed ......................... 10 Hob Lighting ................................10 Cleaning and Maintenance ...................... -
Page 4: Safety Warnings
Safety Warnings • This appliance complies with all relevant local and national safety requirements. Inappropriate use can, however, lead to personal injury and damage to property. • To avoid the risk of accidents and damage to the appliance, please read these instructions carefully before using it for the first time. They contain important information on the safety, installation, use and maintenance of the appliance. • Keep these instructions in a safe place and ensure that all users are familiar with the contents. Pass them on to any future owner of the appliance. Correct Application • This appliance is not designed for commercial use. It is intended for use in domestic households. • It must only be used as a domestic appliance to extract vapours and remove odours from cooking. • Any other usage is not supported by the manufacturer and could be dangerous. The manufacturer cannot be held liable for damage resulting from incorrect or improper use or operation of the appliance. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. • Accessible parts may become hot when used with cooking appliances. • If the supplied mains cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Safety with children • This appliance is only intended for use by adults who have read these instructions. • This appliance is not a toy! To avoid the risk of injury, keep children well away and do not allow them to play with it or to use the controls. They will not understand the potential dangers posed by it. They should be supervised whenever you are working in the kitchen. - Page 5 • Regulate the flame so that it does not burn up the sides of the pan. • Do not allow the pans to overheat excessively (e.g. when using a wok). • The cooker hood can become damaged when exposed to excessive heat. • A lways switch the cooker hood on when a cooking zone is in use, otherwise condensation may collect in the hood, which could cause corrosion. • W hen cooking with oil or fat, chip pans and deep fat fryers etc, do not leave the pans unattended. Never leave an open grill unattended when grilling. Overheated oil and fat can ignite and could set the cooker hood on fire. • D o not use the cooker hood without the filters in place. This way you will avoid the risk of grease and dirt getting into the appliance and hindering its smooth operation. • T he filters should be regularly cleaned or changed as appropriate. Saturated filters are a fire hazard. See "Cleaning and Maintenance". • T he cooker hood can get very hot during cooking due to heat rising from the hob. Do not touch the housing or the grease filters until the cooker hood has cooled down. • D o not use a steam-cleaner to clean this appliance. Steam could reach the electrical components and cause a short circuit. Technical safety • Before installation, check the cooker hood for visible signs of damage. Under no circumstances should you use a damaged appliance. It could be dangerous.
- Page 6 • During installation, maintenance and repair work, the appliance must be disconnected from the mains electricity supply. It is only completely isolated from the electricity supply when: a) i t is switched off at the isolator, or b) t he mains fuse is disconnected, or c) i t is switched off at the wall socket and the plug withdrawn, or d) t he fuse of the fused spur connection unit is withdrawn. • Do not connect the appliance to the mains electricity supply by a multi-socket unit or an extension lead. These do not guarantee the required safety of the appliance (e.g. danger of overheating). This appliance may only be used in mobile installations if a risk assessment of the installation has been carried out by a suitably qualified engineer. • In areas which may be subject to infestation by cockroaches or other vermin, pay particular attention to keeping the appliance and its surroundings in a clean condition at all times. Using at the same time as other heating appliances that depend on the air from the same room. WARNING: Danger of toxic fumes.
- Page 7 The overall ventilation condition of the dwelling must be taken into account. If in any doubt, the advice of a competent builder or, for gas, a qualified gas fitter (Gas Safe registered in the UK) must be sought. • If the only way of ensuring adequate ventilation is via an open window, a window contact switch should be fitted to ensure that the cooker hood can only operate when the window is opened sufficiently. A window contact switch kit is available from good builders' merchants. Take care when ventilating the room through an open window that ventilation is not impaired by a closed blind or curtain. If the hood is being operated in recirculation mode, the above restrictions do not apply. If in any doubt , the advice of a qualified builder, gas fitter (Gas Safe registered in the UK) or electrician must be sought. Correct Installation • Refer to the cooker or hob manufacturer's instructions as to whether a cooker hood may be operated above the cooker/hob. • T he minimum safe distances between the top of the cooker or hob and the bottom of the cooker hood given in the Installation section of this booklet must be maintained, unless the hob/cooker manufacturer states that a greater safe distance is required. • If more than one appliance is fitted beneath the cooker hood, and they have different minimum safe distances to the cooker hood, select the greater distance. • S afety regulations prohibit the fitting of a cooker hood over solid fuel stoves. • A ll ducting, pipework and fittings must be of non-flammable material. These can be obtained from builders' merchants. • T he appliance must not be connected to a chimney or vent flue which is in use. Neither should it be connected to ducting which ventilates rooms with fireplaces. • I f exhaust air is to be extracted into a chimney or ventilation duct no longer used for other purposes, seek professional advice.
-
Page 8: Unpacking
Thank you on the purchase of your new Logik Cooker Hood. We recommend that you spend some time to read this manual in order to fully understand how to install and operate it correctly. Read all the safety warnings carefully before use and keep this manual for future reference. -
Page 9: Product Overview
Product Overview Recirculation Vents Control Panel Internal Chimney Illumination External Chimney Aluminium Filter Control Panel OFF button Motor speed buttons Lamp button... -
Page 10: Modes Of Operation
Modes of Operation The cooker hood works with Air Extraction The air is drawn in and cleaned by the grease filters and directed outside. When the cooker hood is switched on, the non-return flap opens for the cooking vapours to be ducted away. Ensure there is adequate ventilation in the room when the cooker hood is used at the same time as other appliances burning gas or other fuels. -
Page 11: Cleaning And Maintenance
Cleaning and Maintenance • Before any cleaning or maintenance work is carried out, disconnect the cooker hood from the mains power supply. Ensure that: – it is switched off at the isolator, or – it is switched off at the wall socket and the plug is withdrawn, or –... -
Page 12: Cleaning The Grease Filters By Hand
Cleaning the Grease Filters by Hand • Clean the filters with a soft nylon brush in a mild solution of hot water and a little washing-up liquid. Do not use: • Cleaning agents containing descaling agents. • Powder cleaners, cream cleaners or abrasive all-purpose cleaners. • Oven cleaners. -
Page 13: Carbon Filter Usage
Carbon Filter Usage Your product is compatible with one type of carbon filter (carbon filters are not provided). • Before installing or replacing the carbon filters, you should switch off and disconnect the electricity supply. • The carbon filters should never be washed. • The grease filters should be installed on the product even when carbon filters are not being used. -
Page 14: Hints And Tips
Hints and Tips Problem Solution • Check Electric connection. (The supply voltage should be 220-240 V. The cooker hood must be connected to an earthed socket) Cooker hood does not operate • Check motor speed selector. (Motor speed selector should be in position I, II or III) • Check Electric connection. -
Page 15: Technical Specifications
Technical Specifications Model no. L60CHDS12 / L60CHDB12 Extraction Rate (m 450.0 Voltage (V) 220 – 240 ~ Frequency (Hz) Total Power (W) Lamp 2 × 40 W Features and specifications are subject to change without prior notice. Product Fiche Symbol... -
Page 16: Installation
Installation Product Overview Grill For Air Outlet Internal Chimney Connection Plate Internal Chimney External Chimney Connection Plate External Chimney Hanging Plate... - Page 17 440-820 All dimensions shown are in mm.
-
Page 18: Safety Distance Between Hob And Cooker Hood
Safety Distance Between Hob and Cooker Hood When planning the installation height of your cooker hood, the minimum safe distance between the top of a cooker or hob and the bottom of the cooker hood should be at least 650mm, unless a greater distance is specified by the manufacturer of your cooking appliance. -
Page 19: Connection For Air Extraction
Connection for Air Extraction To avoid the danger of toxic fumes, please observe the Safety Warnings. This is especially crucial when using the cooker hood at the same time as another heating appliance which relies on air from the same room. The cooker hood should be installed according to the local and national building regulations. -
Page 20: Mounting The Cooker Hood
Mounting the Cooker Hood • We recommend professional tradespersons are consulted prior to the fitting of this appliance. • Each installation is different and these instructions should be used as a guide only. If in doubt consult professional tradespersons. • Air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels. - Page 21 Assembling Hanging Plate Holes Drill (A, B, C, D, E) holes on marked points by using a Ф8mm drill bit. Push 5 pcs of plastic wall plugs into the drilled holes (A, B, C, D, E). Put the hanging plate on the holes A, B, E. Using the supplied 4 x 40mm screws;...
- Page 24 For general information about this appliance and handy hints and tips, please visit www.knowhow.com/knowledgebank or call 0344 5611234. Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories. With over 1 million spares and accessories available we can deliver direct to your door the very next day. Visit www.partmaster.co.uk or call 0344 800 3456 (UK customers only).
