- Page 1 ASSEMBLY INSTRUCTIONS YSS-V 2 FTPLCG-0114 FTPLCG-0115 FTPLCG-0116 10X10 FT HARDTOP GAZEBO...
- Page 2 WARNING 1. Must use ground nails, ropes, and expansions screws for whichever ground you install on for stability to avoid devastat- ing injuries for people inside or nearby and property damage caused by a collapsing gazebo. 2. Do not use this gazebo in high winds, heavy snow, or inclem- ent weather.
- Page 3 ASSEMBLY INSTRUCTIONS 1. Two or more people are required for assembly. 2. A ladder and electric drill may be necessary. 3. Do not erect the structure in heavy winds or inclement weather. 4. Do not leave up this unit for extended periods of time, as it is not a permanent structure or designed to withstand sustained wind or rain.
- Page 4 ASSEMBLY INSTRUCTIONS Item no. Reference Image Qty.
- Page 5 ASSEMBLY INSTRUCTIONS Item no. Reference Image Qty. X4+X1...
- Page 6 ASSEMBLY INSTRUCTIONS Item no. Reference Image Qty. M6X15mm 9X+56X M6X23mm M5X12mm ST4.8X12mm M6X42mm M6X10mm...
- Page 7 ASSEMBLY INSTRUCTIONS 4pcs 4pcs 12pcs...
- Page 8 ASSEMBLY INSTRUCTIONS 4pcs 4pcs 4pcs 40pcs When connecting B and B1 via P, make sure that 3 holes on part P (as shown in the picture) should be facing upwards. Do not install it upside down.
- Page 9 ASSEMBLY INSTRUCTIONS 32pcs...
- Page 10 ASSEMBLY INSTRUCTIONS 4pcs 4pcs 32pcs...
- Page 11 ASSEMBLY INSTRUCTIONS 4pcs 4pcs 96pcs 4pcs 4pcs 24pcs X6 X6...
- Page 12 ASSEMBLY INSTRUCTIONS 4pcs 12pcs...
- Page 13 ASSEMBLY INSTRUCTIONS 4pcs 12pcs...
- Page 14 ASSEMBLY INSTRUCTIONS...
- Page 15 ASSEMBLY INSTRUCTIONS 4pcs 4pcs 8pcs...
- Page 16 ASSEMBLY INSTRUCTIONS 4pcs 4pcs...
- Page 17 ASSEMBLY INSTRUCTIONS 4pcs 4pcs 4pcs 4pcs 8pcs...
- Page 18 ASSEMBLY INSTRUCTIONS 8pcs 4pcs 4pcs...
- Page 19 ASSEMBLY INSTRUCTIONS 48pcs 4pcs 4pcs 4pcs 4pcs Attach Z by lightly tapping with a screwdriver.
- Page 20 ASSEMBLY INSTRUCTIONS...
- Page 21 ASSEMBLY INSTRUCTIONS...
- Page 22 ASSEMBLY INSTRUCTIONS 80pcs 8+56pcs 16pcs Notes: 1. When installing the ceiling, fix the screws on the central beam first to prevent the iron sheet from falling and causing injury. 2. Do not fully secure the screw until all screws are properly in position. 3.
- Page 23 ASSEMBLY INSTRUCTIONS 4pcs 4pcs 4pcs 4pcs 8pcs...
- Page 24 ASSEMBLY INSTRUCTIONS 4pcs The other part has 6 holes hanging on Part B1. One part of the curtain has 6 holes hanging on Part B1. The other part has 6 holes hanging on Part B. One part of the curtain has 6 holes hanging on Part B.
- Page 25 ASSEMBLY INSTRUCTIONS Pay attention to the sidewall curtain's installation position.
- Page 26 ASSEMBLY INSTRUCTIONS 4+1pcs The other part has 6 holes hanging on Part B1. One part of the netting has 6 holes hanging on Part B1. The other part has 6 holes hanging on Part B. One part of the netting has 6 holes hanging on Part B.
- Page 27 ASSEMBLY INSTRUCTIONS Note: Attach 1 to 2 to secure parts T1 and T (curtains) together. Attach 1 to 3 to secure the back curtain (T). Attach 1 to 3 to secure the front curtain (T1). Pay attention to the sidewall Hang the hook attached to netting's installation position.
- Page 28 ASSEMBLY INSTRUCTIONS 12pcs 12pcs To improve wind resistance, be sure to complete this installation step. If expansion screws or ground nails are not installed,strong winds Cement surfaces may topple the gazebo. Expansion screws are essential for stability on cement surfaces, and ground nails are for grassy surfaces.
- Page 29 ASSEMBLY INSTRUCTIONS Installation Completed...
