Neck pickup
EMG 85-7
Bridge pickup
EMG 81-7
3-way switch settings
1
2
Neck
Bridge
Neck Vol
Bridge Vol
Tone
3-Way
Tone
Switch
For technical or warranty questions please email: tech@schecterguitars.com
Diagram copyright Schecter Guitar Research 2011
EMG
EMG
3
9-Volt
9-Volt
battery
battery
Hellraiser Special C-7
Wiring Diagram
3
2
3-way
switch
Ring (battery ground)
2
Bare
White
1
Bare
White
Master
tone
25k
Output Jack
= ground. This symbol
is found where any ground connection
should be soldered.
Bridge
volume
25k
Neck
volume
25k
Tip (hot output)
Sleeve (ground)
