BLACKMER LIQUEFIED GAS PUMPS
INSTALLATION OPERATION AND MAINTENANCE INSTRUCTIONS
MODELS: CRLR1.25, CRL1.25, CRL1.5

TABLE OF CONTENTS

Technical Data ................................................... 2
Initial Pump Start Up Information ....................... 2
Pre-Installation Cleaning .................................... 3
Location and Piping ........................................... 3
Check Valves ..................................................... 4
Mounting ............................................................ 4
Coupling Alignment ............................................ 4
Pump Rotation ................................................... 4
To Change Pump Rotation ................................ 4
Pre-Start Up Check List ..................................... 5
Start Up Procedures .......................................... 5
Strainers ............................................................... 6
Lubrication ............................................................ 6
Vane Replacement ............................................... 7
Pump Disassembly ............................................... 7
Parts Replacement ............................................... 7
Pump Assembly .................................................... 8
TROUBLE SHOOTING ............................................. 10
NOTE: Numbers in parentheses following individual parts
indicate reference numbers on Blackmer Parts List No. 701-
A01.
Blackmer pump manuals and parts lists may be obtained
from
Blackmer's
website
contacting Blackmer Customer Service.
FOR CO
SERVICE
2
Page
(www.blackmer.com)
or
This is a SAFETY ALERT SYMBOL.
When you see this symbol on the product, or in the
manual, look for one of the following signal words and
be alert to the potential for personal injury, death or
major property damage
Warns of hazards that WILL cause serious personal
injury, death or major property damage.
Warns of hazards that CAN cause serious personal
injury, death or major property damage.
Warns of hazards that CAN cause personal injury
Indicates special instructions which are very
important and must be followed.
Blackmer CO
2
systems which have been designed by qualified
engineering personnel. The system MUST conform to
all applicable local and national regulations and safety
standards.
This manual is intended to assist in the installation and
operation of the Blackmer CO
kept with the pump.
Blackmer CO
2
qualified technicians ONLY. Service shall conform to
all applicable local and national regulations and safety
standards.
Thoroughly review this manual, all Instructions and
hazard warnings, BEFORE performing any work on the
Blackmer CO
pumps.
2
Maintain ALL system and Blackmer CO
operation and hazard warning decals.
by
962300
INSTRUCTIONS NO. 701-A00
Section
701
Jan 2019
Effective
Mar 2016
Replaces
SAFETY DATA
or property damage.
NOTICE:
NOTICE:
pumps MUST only be installed in
pumps, and MUST be
2
pump service shall be performed by
pump
2
