- Page 1 VARIABLE SPEED JIG SAW MILL DRILL STAND MILL DRILL STAND Part No. 6460200 MODEL No. MDS1 Part No. 6500330 ASSEMBLY INSTRUCTIONS 0308...
- Page 2 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice.
- Page 3 PARTS LIST Please note, Parts 6-15 are supplied as a complete set (HTMDS1006)
- Page 4 ASSEMBLY 1. Attach the side panel (2) to the rear panel (3) as shown and secure into place using, 4 nuts (11), bolts (9) and flat washers (10). 2. Place the shelf (4) into the position shown and using the screw (13) and washer (12) provided screw it into position.
- Page 5 ASSEMBLY 3. Connect the second side panel (2) to the rear panel (3) as shown and secure into place using, 4 nuts (11), bolts (9) and flat washers (10). 4. Place the front panel (1) into position and screw the other end of the shelf (4) to the front panel (1), using a screw (13) and...
- Page 6 ASSEMBLY 6. Place the tray (4) on top of the stand and line up the holes. Fix into place using the remaining 4 screws (13) and washers (12). 7. Place the drain bolt (15) ( 15 ) into position and secure using the 24mm nut (14).
- Page 7 GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended.
