Raritan Crown Head CW912 Installation, Operation And Maintenance Instructions

CENTRIFUGAL DISCHARGE SERIES AUTOMATIC MARINE TOILET
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
THE FOLLOWING ARE CAUTIONARY STATEMENTS THAT MUST BE READ AND
WARNING:
Raritan Engineering Company, Inc. recommends that a qualified person or electrician install this product.
Equipment damage, injury to personnel or death could result from improper installation. Raritan En-
gineering Company, Inc. accepts no responsibility or liability for damage to equipment, injury or death
to personnel that may result from improper installation operation of this product.
WARNING: HAZARD OF SHOCK OR FIRE
Always use recommended fuse, circuit breaker and wire size.
Motors and relays used with this product are "Ignition Protected". They are not however, ex-
plosion-proof as defined in 46CFR 110.15-65(e), Subchapter J-Electrical Engineering.
WARNING: HAZARD OF FLOODING - Always shut off seacock(s) before leaving the boat unattended.
Whenever possible hose connections should be secured using two (2) all-stainless steel hose
clamps. Integrity of clamps, hoses and fittings should be checked periodically.
INTRODUCTION
The Crown Head is a powerful centrifugal macerating
toilet that thoroughly breaks down waste in preparation for
treatment or holding and requires little maintenance. It can
be ordered with a 90 degree or a straight discharge fitting.
Available in marine-size or household-style bowl.
OPERATION
CAUTION: The Crown Head motor is designed to
be used as a toilet and is not rated for continuous
duty.
The Crown Head doesn't require special toilet paper,
however, hard objects or stringy substances (paper
towels, feminine hygiene products, filter cigarettes,
etc.) must not be thrown into the toilet as they will
cause damage.
A. Momentary Operation Using Momentary Flush
Switch (Part#PRS) - not included: Depress button
and hold. Water should appear in the bowl within
one to four seconds. Flush as necessary.
Model and Serial #
crown head
FOLLOWED DURING BOTH INSTALLATION AND OPERATION.
DO NOT run this system dry (without water).
DO NOT run continuously for more than 30 seconds.
™
MAINTENANCE
1. Refill the reservoir when empty; occasionally check
that it has not run dry.
C.P., Cleans Potties, (1PCP32) helps minimize the
need for cleaning.
Use only Raritan Cleans Potties as an additive in the
Concentrate tank. Other products may cause damage
to the internal parts of the toilet.
2. Using C.P. a bio-enzymatic toilet bowl cleaner
(available from Raritan Engineering) will keep the
bowl clean and fresh smelling.
Do not use any chemical that contains ammonia, ethyl
acetate, phosphoric acid or concentrated chlorine
bleach as a cleaner. These may cause damage to the
toilet.
3. Make a periodic visual check for leaks at the base of the
toilet and at hose connections.
4. Check semiannually to ensure all wire terminals and
junctions are corrosion-free.
5. When boat is not in use, flushing the system with fresh water
will help minimize odors and reduce mineral buildup.
Link to online
Warranty
Registration
1
L91 1022jlc
