- Page 1 SUBMERSIBLE DEWATERING PUMP MSD 1021 • MSD 1021/A • MSD 2051 MSD 2051/A OPERATING/PARTS MANUAL...
-
Page 2: Introduction
Keep a copy of this manual with the unit at all times. Additional copies are available from Magnum Products LLC, or can be found at www.m-p-llc.com. The information contained in this manual was based on machines in production at the time of publication. -
Page 3: Table Of Contents
COMPONENT LOCATIONS - MSD 1021 & MSD 1021/A ..............8 COMPONENT LOCATIONS - MSD 2051 & MSD 2051/A ..............9 UNIT ASSEMBLY AND PARTS - MSD 1021 & MSD 1021/A ............10 - 11 UNIT ASSEMBLY AND PARTS - MSD 2051 & MSD 2051/A ............12 - 13 WIRING DIAGRAM - MSD 1021 &... -
Page 4: Safety Notes
SAFETY NOTES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. This manual contains DANGERS, WARNINGS, CAUTIONS, NOTICES and NOTES which must be followed to prevent the possibility of improper service, damage to the equipment, personal injury or death. -
Page 5: Unit Serial Number Location
UNIT SERIAL NUMBER LOCATION Refer to the location illustrated below to find the unit ID tag. Important information, such as the unit serial number and model number are found on this tag. Record the information from this tag, so it is available if the tag is lost or damaged. -
Page 6: Specifications
SPECIFICATIONS Read this manual carefully before attempting to use this pump. The potential for property damage, personal injury or death exists if this equipment is misused or installed incorrectly. MAGNUM MODEL MSD 1021 MSD 1021/A MSD 2051 MSD 2051/A Motor Type ...... 1 Ø, 60 hz....1 Ø, 60 hz ....1 Ø, 60 hz ...... 1 Ø, 60 hz Amperage Range (Min. -
Page 7: Operating The Pump
OPERATING THE PUMP 1. Connect the discharge hose with the proper fittings. 2. Place the pump in the water. Lower by attaching a strong rope to the handle. The pump should be placed on a flat, hard surface in at least 2 inches of water. WARNING Never lower or move the pump with the electrical cord. -
Page 8: Component Locations - Msd 1021 & Msd 1021/A
COMPONENT LOCATIONS - MSD 1021 & MSD 1021/A CORD HANDLE HOUSING DISCHARGE IMPELLER (UNDER INLET) INLET... -
Page 9: Component Locations - Msd 2051 & Msd 2051/A
COMPONENT LOCATIONS - MSD 2051 & MSD 2051/A CORD HANDLE HOUSING DISCHARGE IMPELLER (UNDER INLET) INLET... -
Page 10: Unit Assembly And Parts - Msd 1021 & Msd 1021/A
UNIT ASSEMBLY AND PARTS - MSD 1021 & MSD 1021/A... - Page 11 ITEM NO. PART NO. DESCRIPTION NOTES 41668 Hose coupling 41609 Power cord 41633 Upper bearing 41623 Capacitor - run 41656 Motor lower cover 41647 Mechanical seal 41750 O-ring - 2” 41657 Seal plate 41688 Impeller 41683 Pump casing 41708 Strainer 41663 Oil seal Not shown...
-
Page 12: Unit Assembly And Parts - Msd 2051 & Msd 2051/A
UNIT ASSEMBLY AND PARTS - MSD 2051 & MSD 2051/A... - Page 13 ITEM NO. PART NO. DESCRIPTION NOTES 41617 Handle 41610 Power cord 41634 Upper bearing 41641 Lower bearing 41624 Capacitor - run 41648 Mechanical seal 41750 O-ring - 2” 41658 Seal plate 41689 Impeller 41669 Hose coupling 41684 Pump casing 41699 Suction cover 41709 Strainer...
-
Page 14: Wiring Diagram - Msd 1021 & Msd 1021/A
WIRING DIAGRAM - MSD 1021 & MSD 1021/A... -
Page 15: Wiring Diagram - Msd 2051 & Msd 2051/A
WIRING DIAGRAM - MSD 2051 & MSD 2051/A... - Page 16 REV: B PART NO: 41864 01.28.09...
