Dometic CAM45 Installation And Operating Manual

Rear view video camera
Hide thumbs Also See for CAM45:
Table of Contents

Advertisement

Quick Links

Download this manual
DRIVING SUPPORT
CAM45
Rear View Video Camera
EN
Installation and Operating Manual . . . . . . 9
Rückfahrvideokamera
DE
Montage- und Bedienungsanleitung . . . 20
Caméra vidéo de recul
FR
Instructions de montage et de service . . 31
Cámara de vídeo de marcha atrás
ES
Instrucciones de montaje y de uso . . . . . 42
Câmara de marcha-atrás
PT
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . . . . . . . 53
Videocamera per la retromarcia
IT
Istruzioni di montaggio e d'uso . . . . . . . . 63
Achteruitrijvideocamera
NL
Montagehandleiding en
gebruiksaanwijzing. . . . . . . . . . . . . . . . . . 74
Bakvideokamera
DA
Monterings- og betjeningsvejledning. . . 85
Backningsvideokamera
SV
Monterings- och bruksanvisning . . . . . . . 95
Ryggevideokamera
NO
Monterings- og bruksanvisning . . . . . . . 105
PERFECTVIEW
Peruutusvideokamera
FI
Asennus- ja käyttöohje . . . . . . . . . . . . . . .115
Видеокамера заднего вида
RU
Инструкция по монтажу
и эксплуатации. . . . . . . . . . . . . . . . . . . . 126
Kamera cofania
PL
Instrukcja montażu i obsługi . . . . . . . . . 137
Cúvacia kamera
SK
Návod na montáž a uvedenie
do prevádzky . . . . . . . . . . . . . . . . . . . . . 148
Couvací kamera
CS
Návod k montáži a obsluze . . . . . . . . . . 158
Tolatókamera
HU
Szerelési és használati útmutató . . . . . . 168

Advertisement

Table of Contents
loading

Related Manuals for Dometic CAM45

Summary of Contents for Dometic CAM45

  • Page 1 Instrukcja montażu i obsługi ..137 Cúvacia kamera Návod na montáž a uvedenie CAM45 do prevádzky ..... 148 Couvací kamera Rear View Video Camera Návod k montáži a obsluze .
  • Page 2 CAM45...
  • Page 3 CAM45...
  • Page 4 CAM45...
  • Page 5 CAM45 90°...
  • Page 6 CAM45...
  • Page 7 CAM45...

  • Page 8: Table Of Contents

    CAM45 Please read this instruction manual carefully before installation and first use, and store it in a safe place. If you pass on the product to another person, hand over this instruc- tion manual along with it. Table of contents 1 Explanation of symbols.

  • Page 9: Explanation Of Symbols

    Explanation of symbols CAM45 Explanation of symbols WARNING! Safety instruction: Failure to observe this instruction can cause fatal or serious injury. CAUTION! Safety instruction: Failure to observe this instruction can lead to injury. NOTICE! Failure to observe this instruction can cause material damage and impair the function of the product.
  • Page 10 CAM45 Safety and installation instructions Use a crimping tool (fig. 1 10, page 3) to connect the cables. • • Screw the cable when connecting cable 31 (earth). – Screw on the cable using a cable terminal and serrated washer to one of the vehicle's earth bolts or –...

  • Page 11: Scope Of Delivery

    – Intended use The CAM45 camera (ref. no. 9600000523) is designed primarily for use in vehicles. It can be used in video systems to observe the space around the vehicle from the driver's seat when, for example manoeuvring or parking.

  • Page 12: Technical Description

    CAM45 Technical description Technical description The camera with integrated microphone, which is encased in an aluminium housing, transmits image and sound to a monitor via a cable. The infrared LEDs improve night vision. The camera transmits the image as if you were looking in the rear-view mirror.

  • Page 13: Fitting The Camera

    Fitting the camera CAM45 When laying the cables (fig. 3, page 4), make sure: • – they are not kinked or twisted – they do not rub on edges – they are not routed in sharp-edged ducts without protection. •...
  • Page 14 CAM45 Fitting the camera Fitting the camera CAUTION! Select a location for the camera and attach it firmly enough so that it cannot under any circumstances fall off and injure bystanders (e.g. by being knocked off by branches brushing over the roof of the vehicle).
  • Page 15 Fitting the camera CAM45 Creating a through-hole for the camera connection cable (fig. b, page 6) NOTE If possible, use available openings, such as ventilation grilles, to feed the connection cables through. If there are no existing ducts, you must drill a hole of Ø 16 mm.

  • Page 16: Cleaning And Caring For The Camera

    CAM45 Cleaning and caring for the camera Establishing the electrical connection for the camera NOTE • Lay the camera cable so that, should you need to remove the camera, you can access the plug connection between the camera and the extension cable easily. This greatly facilitates the disassembly.

  • Page 17: Warranty

    Warranty CAM45 Warranty The statutory warranty period applies. If the product is defective, please contact the manufacturer's branch in your country (see the back of the instruction manual for the addresses) or your retailer. For repair and guarantee processing, please send the following items: •...

  • Page 18: Technical Data

    CAM45 Technical data Technical data PerfectView CAM45 Ref. no.: 9600000523 Image sensor: 1/4" CCD Pixels: Approx. 250000 pixels Video standard: PAL, 1 Vpp Sensitivity: < 1 Lux / 0 Lux with infrared LEDs Viewing angle: Approx. 120° diagonal Approx. 80° horizontal Approx.
