Range Hood
Power supply: 120V
Rated power: 323W
Frequency: 60Hz
USER MANUAL
Free 3 months
extension
original limited warranty
period!* Simply text a
picture of your proof of
purchase to:
1-844-224-1614
*The warranty extension is for the
three months immediately following
the completion of the product's
original warranty period.
MODEL NUMBER
en
of the
CVB27W7ASS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CVB27W7ASS and is the answer not in the manual?

Questions and answers

Related Manuals for Comfee CVB27W7ASS

Summary of Contents for Comfee CVB27W7ASS

  • Page 1 Free 3 months extension of the original limited warranty period!* Simply text a picture of your proof of purchase to: 1-844-224-1614 *The warranty extension is for the three months immediately following the completion of the product’s original warranty period. MODEL NUMBER CVB27W7ASS...
  • Page 2 INTENDED FOR RESIDENTIAL COOKING USE ONLY READ ALL INSTRUCTIONS BEFORE INSTALLATION AND USE CAUTION WARNING IMPORTANT WARNING alerts you to situations that may CAUTION indicates a potentially hazardous IMPORTANT indicates installation, operation, cause serious body harm, death or property situation which, if not avoided, may result in maintenance or valuable information that is not damage.
  • Page 3 Components Ref. Qty. Product Components Box assembly Fan assembly Filter Assembly The Activated Charcoal filter(optional) Screws...
  • Page 4 Measurement 10.20" 0.51" 26.65" Φ5.91" 10.08" 9.76" 11.18"...
  • Page 5 Measurement...

  • Page 6: Installation

    Installation There are two venting options, extraction-air venting and recirculation venting. Plan for one venting option before installation. Recirculation Venting Extraction-air (Outdoor) Option Venting Option...
  • Page 7 Installation  Unlatch the metal filter, remove the filter. Remove the stainless steel  frame by unfastening the 4 Philips head screws. Cut the zip ties , remove the  one screw securing the black terminal box lid. Cut the zip ties, remove the ...
  • Page 8 Installation Re-secure the stainless  steel frame back into place using the 4 screws removed as described above. Reconnect all wiring  harness connectors and re- secure the black terminal box lid. Replace the metal Filter.  Install the air outlet pipe(Extraction ...
  • Page 9 Speed adjustment. See Button Function Turns the lighting system on or off. Button on. Decrease the motor speed. When are on. Display fan gear "1、2、3". When the fan is running. Display "0". Delayed shutdown mode, or standby mode. Increase the motor speed. When are on.

  • Page 10: Maintenance

    Maintenance Cleaning of the filter  Make sure that the hood is shut off before cleaning. Press the lock catch of metal Filter, remove the Filter. (page 7)  Put into a dishwasher with detergent, set the temperature below  60 degrees.

  • Page 11: Replacing The Lamp

    Maintenance Replacing the lamp  metal  Push  Connect the wires of the   Push the new from outside and fix it to the hole Max Power Voltage Picture Lamp Cap ILCOS D code Round/ Diameter —— 1.5W DC 12 V DSR-1.5-S-70 : 2.76"...

  • Page 12: Troubleshooting

    Trouble Shooting Fault Cause Solution Disconnect power supply before The blades are blocked. checking blades for obstruction. The capacitor is damaged. Call Customer Support. Light on, but The motor is damaged. Call Customer Support. motor does not The internal wiring of motor is cut off/ work disconnected.

  • Page 13: Main Parameters

    Main Parameters 120V~ 60Hz 323W Rated Power Lighting Power 1.5 W x 2 320W Motor Power Diameter of air tube 150mm 450CFM 71 dB(A) The air flow parameter is tested under conditions of 120V~ 60Hz when the voltage is 110V-127V~ 60Hz and without carbon filters. Disposal Please dispose of it at your local community waste collection / recycling center and ensure it presents no danger to children...

  • Page 14: Year Limited Warranty

    1 YEAR LIMITED WARRANTY This is the only express warranty for this product and is in lieu of any other warranty or condition. This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option;...
  • Page 16 The manufacturer shall decline all responsibility if the foregoing recommendations and instruction regarding installation, maintenance and use are not observed and respected when using the cooker hood. P/N:16173000A21868...
