iMarc
™
SLV
Models 9820-2M and 9820-8M
Installation Instructions
Document Number 9820-A2-GN10-70
May 2003
Contents
...................................................................................................
................................................................................................... 24
.....................................................................
....................................................................
........................................................................................
..................................................................................
.........................................................................
..........................................................................
............................................................................................
.................................................................... 11
..................................................................... 13
.............................................................................. 13
.................................................................... 13
.................................................................... 14
............................................................................... 15
........................................................................... 16
...................................................................... 18
........................................................................ 21
......................................................................................... 24
...........................................................
....................................... 12
.............................................. 17
.................................................... 19
...................................... 24
1
NOTE: The FrameSaver
product line has been
renamed to iMarc.
................................
....................... 17
®
2
2
3
3
4
5
5
6
7
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iMarc SLV 9820-2M and is the answer not in the manual?

Questions and answers

Related Manuals for Paradyne iMarc SLV 9820-2M

Summary of Contents for Paradyne iMarc SLV 9820-2M

  • Page 1: Table Of Contents

    iMarc ™ ® NOTE: The FrameSaver product line has been Models 9820-2M and 9820-8M renamed to iMarc. Installation Instructions Document Number 9820-A2-GN10-70 May 2003 Contents Product Documentation Online ..............iMarc SLV 9820 In-Line Models ..............Package Checklist ..................Preparation ....................Cables You Can Order ..................

  • Page 2: Product Documentation Online

    Technical Description (9000-A2-GB30) iMarc Configuration Reference (9000-A2-GB31) iMarc SNMP Reference (9000-A2-GB32) iMarc Operations Guide (9000-A2-GB33) To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 1-727-530-2000. iMarc SLV 9820 In-Line Models ™...

  • Page 3: Package Checklist

    ❑ Ferrite choke (9820-2M only) Be sure to register your warranty at www.paradyne.com/warranty. Preparation If you ordered a wall mounting kit (Feature No. 9001-F1-891) for your iMarc unit, install the wall mounting before you start installing the unit. Follow the same guidelines below when installing the wall mounting.

  • Page 4: Cables You Can Order

    Cables You Can Order Feature Part If connecting to . . . Order a . . . Number Number PC with a D-Sub9 Standard EIA-232 3100-F2-550 035-0313-1431 interface/connector straight-through cable, D-Sub9-to-DB25 (14 feet / 4.3 meters) LAN adapter Adapter DB25 3100-F1-920 002-0069-0031 plug-to-8-position modular receptacle...

  • Page 5: Imarc Slv 9820 Front Panel

    Contact your sales representative to order cables. iMarc SLV 9820 Front Panel (2 Mbps Model Shown) iMarc SLV 9820 Rear Panel 98-16189 Safety Instructions Please refer to the Important Safety Instructions on page 21.

  • Page 6: Installing The Power Supply And Cord

    Installing the Power Supply and Cord Procedure 1. Insert the power supply’s 4-prong plug into the POWER jack. When inserting the plug at the rear of the iMarc unit, align the plug with the notch above the POWER jack. Make sure the locking tab snaps securely into the jack. Locking Grounded Power...

  • Page 7: Connecting The Com Port To An Async Terminal Or Pc

    Connecting the COM Port to an Async Terminal or PC The iMarc unit must first be directly connected to a PC or asynchronous terminal (providing VT100 terminal emulation) to set up access and management of the unit. Procedure 1. Configure the VT100-compatible terminal or PC to be compatible with the access unit: —...

  • Page 8: Menu Hierarchy

    Menu Hierarchy The Menu Hierarchy shows the organization of the iMarc unit’s screens. Status System and Test Self-Test Results Status Last System Reset Health and Status Test Status LMI Reported DLCI DLCIs Status CIR (bps) IP Path Device Name Connection Status IP Address Status Discovery Source...
  • Page 9 Test Network PVC PVC Loopback Tests Send Pattern Monitor Pattern Connectivity Data Port PVC PVC Loopback Tests Send Pattern Monitor Pattern Data Port Physical DTE Loopback Tests IP Ping Lamp Test Abort All Tests Configuration System Frame Relay and LMI Class of Service Definitions Service Level Verification General...
  • Page 10 Control Modem Call Directory Number Directories Directory Phone Number System Device Name Information System Name, Location, Contact Date Time Administer Logins Login ID Password Access Level Change Operating Back-to-Back Mode Mode Standard Mode Select Software Current Release Release Alternate Release Switch &...

  • Page 11: A Quick Guide To Configuration

    A Quick Guide to Configuration The iMarc unit should operate using the default (factory-set) configuration options, with exception to the changes specified in these installation instructions. Refer to the following table for help in navigating through the menus. Press the . . . To .

  • Page 12: Installing And Setting Up The Imarc Slv 9820 Unit

    Network Operations Center (NOC) router (for management by the Network Service Provider). Multiple management PVCs then connect the central site unit to the remote site units using Paradyne’s proprietary PVC multiplexing method (embedded DLCIs).

  • Page 13: Verifying That Self-Test Passed

    Verifying that Self-Test Passed Procedure 1. Follow this menu selection sequence from the Main Menu and press Enter after each selection: Main Menu → Status → System and Test Status 2. Check the Self-Test Results column (in the center of the System and Test Status screen).

  • Page 14: Configuring Physical Interfaces

    Configuring Physical Interfaces The network and data port interfaces support three different port types: EIA-530-A, V.35 and X.21. If your application does not use V.35 interfaces, then the port type needs to be changed. If the Hardware Bypass feature will be used, both the network and user port interfaces should use the same type of interface.

  • Page 15: Automatic Configuration

    Automatic Configuration The iMarc unit provides several automatic configuration features. Frame Relay Discovery and configuration is one of these features. Main Menu → Auto-Configuration The default discovery mode is 1MPort. In this mode, for each DLCI discovered on the network, a multiplexed network DLCI and a standard data port DLCI will be configured and connected, and a Management PVC will be embedded in the network DLCI.

  • Page 16: Connecting To The Network

    Connecting to the Network Now that the iMarc unit is set up, the unit can be connected to the network. Procedure 1. Insert the DB25 connector of the network cable into the network data port. 2. Insert the other end of the cable into the NTU (EIA-530-A, V.35, or X.21). 98-16199 NOTE: After connecting the network cable, wait about a minute to allow...

  • Page 17: Setting Up Service Provider Connectivity At The Central Site

    Setting Up Service Provider Connectivity at the Central Site When management needs to be set up between a service provider’s customer and its network operations center (NOC), a non-multiplexed DLCI must be configured to carry management data between the customer’s central site and the NOC console. This requires that a frame relay discovered DLCI needs to be modified.

  • Page 18: Verifying The End-To-End Path

    3. Save the configuration. 4. Return to the Main Menu. If trap dial-out is desired, the PC or asynchronous terminal must be disconnected from the unit’s COM port when setup is complete, and an external modem connected instead. See Setting Up Call Directories for Trap Dial-Out and in the iMarc Configuration Reference for additional information.

  • Page 19: Connecting To The Dte (Router Or Frad)

    Connecting to the DTE (Router or FRAD) Procedure 1. Connect the appropriate cable to the Port connector. — If the DTE interface type is EIA-530-A, the DTE can be directly connected to the Port connector. — If the DTE interface type is V.35 or X.21, a V.35 or X.21 adapter cable is required.
  • Page 20 Checking That Data is Being Received Procedure 1. Return to the Main Menu. 2. Select Performance Statistics, and select an interface’s frame relay statistics. Main Menu → Status → Performance Statistics → Frame Relay → Net1-FR1 3. Verify that the Frames Received and Characters Received counts under the Frame Relay Link statistics are incrementing, and there are no errors under the Frame Relay LMI statistics.

  • Page 21: Important Safety Instructions

    Low Voltage (SELV) output less than 240 VA available, certified for use in the country of installation. Paradyne power supply part number 327-0107-0031 is recommended. This power supply includes a special mating connector for connection to this equipment. 5. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.
  • Page 22 The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne. CANADA – EMI NOTICE: This Class A digital apparatus meets all requirements of the Canadian interference-causing equipment regulations.
  • Page 23 CE Marking When the product is marked with the CE mark, this demonstrates full compliance with the following European Directives: „ Directive 73/23/EEC – Council Directive of 19 February 1973 on the harmonization of the laws of the member states relating to electrical equipment designed for use within certain voltage limits, as amended by Directive 93/68/EEC.

  • Page 24: Warranty, Sales, Service, And Training Information

    Trademarks iMarc is a trademark of Paradyne Corporation. FrameSaver is a registered trademark of Paradyne Corporation. All other products and services mentioned are the trademarks, service marks, registered trademarks, or registered service marks of their respective owners.
