Paradyne MIM-2T1 Installation Instructions Manual

Micro interface module

Advertisement

Quick Links

MIM-2T1
Installation Instructions
Document Number MIM2-A2-GZ41-00
October 2004
Contents

Software and Firmware License Agreement

The terms and conditions of this License Agreement (the "Agreement") will apply
to the software and/or firmware (individually or collectively the "Software")
incorporated into the Paradyne product (the "Product") purchased by you and any
derivatives obtained from the Software, including any copy of either. If you have
executed a separate written agreement covering the Software supplied to you
under this purchase, such separate written agreement shall govern.
Paradyne Corporation ("Paradyne") grants to you, and you ("Licensee") agree to
accept a personal, non-transferable, non-exclusive, right (without the right to
MIM2-A2-GZ41-00
....................................................................................... 3
...................................................................................... 4
................................................................................................ 5
............................................................................................ 6
................................................................................................... 8
............................................................................................ 9
ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
October 2004
...................................................... 1
.......................................................................... 3
......................................................... 3
.............................................................................. 6
........................................... 10
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIM-2T1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Paradyne MIM-2T1

  • Page 1: Table Of Contents

    Installation Instructions Document Number MIM2-A2-GZ41-00 October 2004 Contents Software and Firmware License Agreement Product Documentation Online Unpacking and Inspecting the Equipment Installing the MIM-2T1 Connecting the T1 Line T1 RJ45 Pinouts T1 Default Settings T1 Parameter Configuration LED Indicators Regulatory Notices...
  • Page 2 sublicense) to use the Software, solely as it is intended and solely as incorporated in the Product purchased from Paradyne or its authorized distributor or reseller under the following terms and conditions: 1. Ownership: The Software is the sole property of Paradyne and/or its licensors. The Licensee acquires no title, right or interest in the Software other than the license granted under this Agreement.
  • Page 3: Product Documentation Online

    If you are not sure of the proper static control precautions, contact your nearest sales or service representative. If there is any visible damage, do not attempt to install the MIM-2T1; contact your sales representative. Installing the MIM-2T1 The MIM-2T1 Micro Interface Module provides additional uplink ports for the AµD8000 ADSL Micro DSLAM or BSX8000-5 Broadband Services Switch.
  • Page 4: Connecting The T1 Line

    Position the choke as close as possible to the RJ45 connectors. — Snap shut the ferrite choke. 2. Plug your T1 cables into the T1 RJ45 ports (Port 1 and Port 2) on the MIM-2T1 faceplate; the order of connection is not important.
  • Page 5: T1 Rj45 Pinouts

    Position the choke as close as possible to the RJ45 connector. — Snap shut the ferrite choke. 2. Plug your T1 cable into one of the two T1 RJ45 ports on the MIM-2T1. Either port may be used. 3. Verify the connection: the T1 link LED on the front of the MIM will flash green to indicate the connection is established and operational.
  • Page 6: T1 Default Settings

    T1 Default Settings No configuration is necessary for the MIM-2T1 to operate at default settings: „ Speed: Adaptive. The MIM-2T1 determines timeslot and bandwidth configurations via communication with the remote T1 equipment to which it is connected. Each T1 connection has the capability of receiving data across all 24 channels at 1,536 kbps.
  • Page 7 Paradyne products meet the North American minimum ones density requirement internally such that loss of synchronization is prevented between the MIM-2T1 and remote T1 equipment with AMI just as it is with B8ZS. Line Attenuation Shorter distances between the MIM-2T1 and remote modems can require an...
  • Page 8: Led Indicators

    T1 line. Red AlarmThe incoming If the outgoing connection from connection to the MIM-2T1 the MIM-2T1 has also been lost has been lost; no data is then the remote T1 equipment being received. to which the MIM is connected will be in Red Alarm as well.
  • Page 9: Regulatory Notices

    Cet appareil numérique de la classe A respecte toutes les exigences du règlement sur le matérial brouilleur du Canada. EUROPEAN REGULATORY COMPLIANCE The following regulatory compliance information applies to the MIM-2T1 as installed in the AµD8000 or BSX8000-5: This Class A product complies with European Norm EN55022.
  • Page 10: Warranty, Sales, Service, And Training Information

    Warranty, Sales, Service, and Training Information Contact your local sales representative, service representative, or distributor directly for any help needed. For additional information concerning warranty, sales, service, repair, installation, documentation, training, distributor locations, or Paradyne worldwide office locations, use one of the following methods: „...
