Hardware Overview

Four Channel 3G-SDI Video Capture Card
•
Four independent 3G SDI capture channels
•
Four channels of 1920 x 1080p 60fps capture
•
Eight lane PCIe Gen.3 interface,
•
Frame buffer memory - 768 MB
•
Single PCIe endpoint, allowing for more cards & captures to be placed within a single system.
Datapath Vision Performance Driver
Multiple cards per system, 16 streams per card
Frame sync and time stamping
Automatic signal detection
Direct Show interface
Datapath RGBEasy API
Models
VisionSC-SDI4 - 3G-SDI Video Capture Card
Fig. 1
Fig. 2
