HPE OfficeConnect 1820 Series Quick Setup Manual And Safety Information
Hide thumbs
Also See for OfficeConnect 1820 Series:
- Installation and getting started manual (46 pages)
Related Manuals for HPE OfficeConnect 1820 Series
Summary of Contents for HPE OfficeConnect 1820 Series
- Page 1 HPE OfficeConnect 1820 Switch Series Quick Setup Guide and Safety/Regulatory Information *5200-2851* Part Number: 5200-2851 Published: February 2017 Edition: 1, Printed in China...
- Page 2 HPE OfficeConnect 1820 8G Switch J9979A HPE OfficeConnect 1820 24G Switch J9980A HPE OfficeConnect 1820 48G Switch J9981A HPE OfficeConnect 1820 8G PPoE+ (65W) Switch J9982A HPE OfficeConnect 1820 24G PoE+ (185W) Switch J9983A HPE OfficeConnect 1820 48G PoE+ (370W) Switch J9984A ©...
-
Page 3: Table Of Contents
Contents HPE OfficeConnect 1820 Switch Series............ 4 Example: Initial Switch Configuration....................7 SFP Installation Notes......................... 8 Warranty and regulatory information............10 Safety Precautions..........................10 Installation Precautions......................10 Regulatory and Safety Information....................10 1820 Switch Series Information — Regulatory and Safety............. 11 1820 8G External Power Adapter and Power Cords:..........12 1820 8G PoE+ External Power Adapter and Power Cords:........ -
Page 4: Hpe Officeconnect 1820 Switch Series
Getting Started Guide for your switch at http://www.hpe.com/support/hpesc. NOTE: The HPE OfficeConnect 1820 Switch Series 8-port, 24-port, and 48-port non-PoE+ models have a fan- free design, making them quiet for office deployments. A warmer than normal enclosure is a standard state of operation for a fan-free switch. - Page 5 Phillips (cross-head) screwdriver. Then secure the brackets to the rack by using the four number 12-24 screws. Table or Desktop Mounting: Attach the four self- adhesive pads (included in the accessory kit) to the bottom corners of the switch. HPE OfficeConnect 1820 Switch Series...
- Page 6 Do not wall-mount the switch with the ventilation holes facing up or down. (See Installation Precautions.) 5. Power on the switch. Follow the same procedures as in step 3. 6. Configure the switch for operation on your network (minimal configuration). HPE OfficeConnect 1820 Switch Series...
-
Page 7: Example: Initial Switch Configuration
Example: Initial Switch Configuration. 7. Connect the network cables. NOTE: For transceiver connections, install and use only HPE SFP transceivers supported by the switch. See SFP Installation Notes. Example: Initial Switch Configuration Procedure 1. Reconfigure the PC’s IP address and Subnet Mask so that it can communicate with the switch. -
Page 8: Sfp Installation Notes
Use only an approved Laser Class 1 SFP transceiver. NOTE: To ensure proper operation of your switch, use only the HPE Aruba SFP transceivers supported by your switch. Use only supported HPE Aruba SFP transceivers. Non-HPE Aruba SFP transceivers are not supported. - Page 9 Because of these default speed/duplex considerations, make sure that devices connected to your SFP ports are properly configured. At a minimum, make sure the configurations match. HPE OfficeConnect 1820 Switch Series...
-
Page 10: Warranty And Regulatory Information
Ensure that the air flow around the switch is not restricted. Leave at least 7.6 cm (3 inches) for cooling. Regulatory and Safety Information For important safety, environmental, and regulatory information, see Safety and Compliance Information for Server, Storage, Power, Networking, and Rack Products, available at http://www.hpe.com/support/Safety- Compliance-EnterpriseProducts. Warranty and regulatory information... -
Page 11: 1820 Switch Series Information - Regulatory And Safety
1820 Switch Series Information — Regulatory and Safety 1820 8G 1820 24G 1820 48G 1820 8G PoE 1820 24G 1820 48G Switch Switch Switch + (65W) PoE+ (185W) PoE+ (370W) (J9979A) (J9980A) (J9981A) Switch Switch Switch (J9982A) (J9983A) (J9984A) Electrical: For power, For power, For power,... -
Page 12: 1820 8G External Power Adapter And Power Cords
NOTE: Use only supported HPE SFP transceivers with your switch. When selecting a fiber SFP device, make sure it can function at a temperature that is not less than the recommended maximum operational temperature of the product. Use only an approved Laser Class 1 SFP transceiver. -
Page 13: 1820 8G Poe+ External Power Adapter And Power Cords
1820 8G PoE+ External Power Adapter and Power Cords: AC power cord: 90W inline power adapter (5066-5569 ) specifications: 8121-0837 Australia/New Zealand • AC Input Voltage: 100–240 V 8121-0943 China • Maximum AC Input Current: 1.4 8121-0731 Continental Europe • AC Input Frequency Range: 50/60 Hz 8121-0733... -
Page 14: 1820 48G Poe+ Power Cords
AC power cord: 8121-1004 Israel 8121-1143 Japan 8121-0737 South Africa 8121-0731 South Korea 8121-0738 Switzerland 8121-0964 Taiwan 8121-0734 Thailand 8121-0739 United Kingdom/Hong Kong/Singapore/Malaysia 8121-1141 United States/Canada/Mexico 8121-1071 Brazil 8121-0729 Argentina 8121-0735 Chile 1820 48G PoE+ Power Cords AC power cord: 8121-1476 Australia/New Zealand 8121-1484... -
Page 15: Documentation Feedback
Documentation Feedback ( docsfeedback@hpe.com). When submitting your feedback, include the document title, part number, edition, and publication date located on the front cover of the document. For online help content, include the product name, product version, help edition, and publication date located on the legal notices page.
