Cooper Lighting High Mast HMC40SC23E Specification Sheet

R O A D W AY
HMC HIGH MAST
L A R G E A R E A L U M I N A I R E
STREETWORKS ™
H O U S I N G O R D E R I N G I N F O R M AT I O N
Die-cast aluminum housing and
S A M P L E N U M B E R
cover. Standard bronze polyester
powder coat finish. Other finish
PRODUCT
colors available. Consult your
FAMILY
Streetworks Representative.
HMC
M O U N T I N G
Clamp type slipfitter for 2 3/8"
O.D. pipe.
O P T I C S
Anodized spun aluminum outer
reflector housing. Light pattern
can be oriented by rotating optical
O P T I O N S + A C C E S S O R I E S
assembly (360°). A degree indicator
is provided to identify the aiming
position. OPTIONS (add as suffix)
1=Single Fuse, Internally Mounted (120, 277V)
R E F L E C T O R
2=Double Fuse, Internally Mounted (208, 240 & 480V)
Inner hydroformed and anodized
3=Four-Stage Air Filter
reflector.
4=Photocontrol Receptacle
AP=Grey
D O O R
B=Plastic Two Position Terminal Block
Die-cast aluminum door with
F=Flat Glass
tempered convex glass lens and
M=MOV Lighting Surge Protector
silicone rubber gasket.
O P T I O N A L C O L O R S
AP
Grey
E P A :
Effective Projective Area: 1.46
S H I P P I N G D ATA
Approximate Net Weight:
NOTE: 1 Refer to technical section for lamp/ballast/voltage compatibility. 2 1000W HPS only. 3 Not available on 1000W units. 4 Four-Stage air filter prevents entrance of dust particles .00025mm and larger. 5 MOV option is not
68 lbs. (30 kgs.) available for any system requiring a three position terminal block (Example—120/240 incoming line). In order for MOV option to function center terminal of three position terminal block must be connected to "Earth" ground.
128 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
: H M C 4 0 S C 2 3 E
LAMP LAMP TYPE 1 BALLAST TYPE
WATTAGE S=HPS C=CWI
40=400W M=MH K=10KV CWA
91=1000W M=Mag. Reg.
W=CWA
[ M u s t b e l i s t e d i n t h e o r d e r s h o w n a n d s e p a r a t e d b y a d a s h ]
4
5
[ S t a n d a r d c o l o r i s b r o n z e , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
2 3/8"
[61mm]
O.D. Pipe
Horizontal Lamp Configuration
1 VOLTAGE 1
2=120V
2 0=208V
3 4=240V
7=277V
8=480V
9=347V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
ACCESSORIES (order separately)
OA/RA1016=105-285V Photocontrol
OA/RA1027=480V Photocontrol
OA1153=External Cutoff Shield (.90 EPA)
19 3/8"
[492mm]
4 3/8"
[111mm]
28" [711mm]
OPTICAL DISTRIBUTION
PACKAGE A=SCO
1=Type I D=MCO
2=Type II E=MSCO
3=Type III L=LMCO
4=Type IV
C o o p e r L i g h t i n g
400-1000W
MH/HPS
23 3/4"
[503mm]
OPTIONS +
ACCESSORIES
(See Below)
