- Page 1 CDPW-V4H2HP MX-UHD4H2H 4 by 2 HDMI 4K UHD Wall Plate Matrix with HDCP 2.2 Operation Manual Operation Manual...
- Page 2 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fi re, electrical shock and injury to persons.
-
Page 3: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........1 6. Operation Controls and Functions ..2 6.1 Top Panel ..........2 6.2 Left Panel ..........3 6.3 Right Panel ........3 6.4 Bottom Panel ........4 6.5 Remote Control ........4 6.6 IR Cable Pin Assignment....5... -
Page 4: Introduction
1. INTRODUCTION This 4 by 2 HDMI Wall Plate Matrix is an advanced HDMI solution designed for Ultra High-Defi nition signal distribution needs. It allows you switch between and distribute one of four 6G HDMI inputs to two simultaneous 6G HDMI outputs. It has support for the latest HDMI features such as support for 4K2K@60 resolution, 48-bit 'Deep Color', high defi... -
Page 5: Operation Controls And Functions
4096x2160@50/60 Hz (4:4:4) • Supports data rate up to 6Gbps (600MHz) and Deep Color up to 1080p 48-bit • Supports pass-through of HD audio formats of LPCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio •... -
Page 6: Left Panel
IR Window: This IR Receiver receives IR signal from the remote control included in the package only. Ensure that remote being used is within the direct line-of-sight of the IR window. OUTPUT A1~A4 & B1~B4: Press these buttons to change the routing of output with an input A/B. -
Page 7: Bottom Panel
6.4 Bottom Panel RS232 IR IN SERVICE DC 5V LAN: Connect to PC/Laptop with active internet service for Telnet/ WebGUI control with RJ-45 terminated cable. RS232: Connect to PC/Laptop with D-Sub 9- pin female cable for the transmission of RS-232 commands to control the device. IR IN: Connect the IR Receiver cable from the package for receive IR signal from the remote control. -
Page 8: Ir Cable Pin Assignment
6.6 IR Cable Pin Assignment IR Extender IR Signal Power Grounding 6.7 RS-232 Protocol MATRIX REMOTE CONTROLLER Assignment Assignment ► ◄ Baud Rate: 19200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1... -
Page 9: Rs-232 And Telnet Commands
6.8 RS-232 and Telnet Commands COMMAND DESCRIPTION PARAMETERS PRINT OUT ALL OF AVAILABLE COMMANDS HELP PRINT OUT ALL OF AVAILABLE COMMANDS POWER OFF NONE POWER ON NONE SET OUTPUT A SOURCE N= Input 1~ 4 SET OUTPUT B SOURCE N= Input 1~ 4 IPCONFIG DISPLAY THE CURRENT IP CONFIG NONE... -
Page 10: Telnet Control
COMMAND DESCRIPTION PARAMETERS SET ALL CONFIGURATIONS TO FACTORY FADEFAULT DEFAULT Note: Any commands will not be executed unless followed by a carriage return. Commands are case-insensitive. 6.9 Telnet Control Before attempting to use the Telnet control, please ensure that both the Matrix (via the 'LAN /CONTROL' port) and the PC/Laptop are connected to the same active networks. - Page 11 This will bring us into the unit which we wish to control. Type "help" to list the available commands. Note: Commands will not be executed unless followed by a carriage return. Commands are case-insensitive. If the IP is changed then the IP Address required for Telnet access will also change accordingly.
-
Page 12: Webgui Control
6.10 WebGUI Control On a PC/Laptop which is connected to an active network system, open a web browser and type device’s IP address (factory default static IP: 192.168.1.50) on the web address entry bar. The browser will display the device’s control page for users to control. -
Page 13: Connection Diagram
7. CONNECTION DIAGRAM Games Console Satellite Receiver Set-top Box Blu-ray Player HDMI Outputs HDMI Inputs HDCP2.2 RS232 IR IN SERVICE DC 5V Power Supply LAN Connection Extender RS-232 60° POWER Internet Connected Remote RS-232 Equipped Router PC or Notebook CR-155 UHDTV UHDTV... -
Page 14: Specifications
8. SPECIFICATIONS 8.1 Technical Specifi cations Video Bandwidth 600 MHz/6 Gbps Input Ports 4×HDMI, 1×IP Control (RJ-45), 1×IR, 1×RS- 232 (9-pin D-sub), 1×USB (Service only) Output Ports 2×HDMI Supported Resolutions 480i~1080p@24/50/60, 4K2K@24/25/30/50/60 & VGA~WUXGA HDMI Cable Length I:15M/1080p@12bits, 5M/4K2K O:15M/1080p@12bits, 5M/4K2K IR Frequency 38 kHz Baud Rate... -
Page 15: Supported Resolutions
8.2 Supported Resolutions Resolution Input Output 640×480@60/72/75/85 √ √ 720×480@60 √ √ 720×576p@50 √ √ 800×600@60/72/75/ √ √ 1024×768@60/70/75 √ √ 1280×720@50/60 √ √ 1280×720p@60 √ √ 1280×768@60 √ √ 1280×800@60 √ √ 1280×1024@60 √ √ 1360×768@60 √ √ 1600×1200@60 √... -
Page 16: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM Consumer Electronics Control Command Line Interface Digital Theater System Digital Visual Interface EDID Extended Display Identification Data Graphical User Interface HDCP High-bandwidth Digital Content Protection HDMI High-Defi nition Multimedia Interface HDTV High-Defi nition Television Internet Protocol Infrared Universal Serial Bus Video Graphics Array... - Page 17 Should you feel your product does not function adequately due to defects in materials or 1. Damage requiring service workmanship, PhD Solutions (hereby referred to as “the warrantor”) will, for the length of the period indicated below: All units should be serviced by a PhD Solutions qualified service person.: Repair the product with new or 2.
- Page 18 Product Service Provided 1. Damage requiring service 1. Damage requiring service All units should be serviced by a PhD Solutions qualified service person.: All units should be serviced by a PhD Solutions qualified service person.: 2. Servicing Personnel 2. Servicing Personnel Do not attempt to service the unit beyond that described in these operating instructions.
- Page 19 2. There are no express warranties except as listed under “limited warranty coverage.” The warrantor is not liable for incidental or consequential damage resulting from the use of this product or arising out of any breach of this warranty. 2. There are no express warranties except as listed under “limited warranty coverage.” The warrantor is not liable for incidental or consequential damage resulting from the use of this For example: damage for lost time, the cost of having a person/persons remove or re- ¥...
- Page 20 Premium High Definition Solutions Home page: http://www.phdsolutions.co...
