Summary of Contents for Logik L90CHDB10
- Page 1 90cm Black Chimney Standard Hood Instruction / Installation Manual L90CHDB10...
-
Page 2: Table Of Contents
Contents Before Use .................................3 Unpacking........................................3 Product Overview ....................................4 Control Panel ......................................5 Modes of Operation ....................................5 Operation ..................................6 Operation ......................................... 6 Ū To select the fan motor speed ..............................6 Ū Hob lighting ..................................... 6 Cleaning and Maintenance ............................7 Cleaning and Maintenance .................................. -
Page 3: Before Use
Congratulations on the purchase of your new Logik Cooker Hood. We recommend that you spend some time to read this manual in order to fully understand how to install and operate it correctly. Read all the safety warnings carefully before use and keep this manual for future reference. -
Page 4: Product Overview
Product Overview Grill for air outlet Control Panel Internal Chimney Aluminium Filter External Chimney Illumination GB-4... -
Page 5: Control Panel
Control Panel Lamp button Motor speed buttons OFF button Modes of operation The cooker hood works with 1. Air Extraction: The air is drawn in and cleaned by the grease filters and directed outside. The non-return flap supplied with the appliance must be fitted on the exhaust socket of the motor unit. -
Page 6: Operation
Operation To select the fan motor speed The unit has 3 motor speeds “I” , “II” and “III”. For short periods of cooking food with intensive vapours and a strong aroma, e.g. when searing meat, you may wish to select the highest setting “III”. To turn the motor fan off, press the OFF button. -
Page 7: Cleaning And Maintenance
Cleaning and Maintenance Before any cleaning or maintenance work is carried out, disconnect the cooker hood from the mains power supply. Ensure that: – it is switched off at the isolator, or – it is switched off at the wall socket and the plug is withdrawn, or –... -
Page 8: Ū Cleaning The Grease Filters By Hand
Cleaning the grease filters by hand • Clean the filters with a soft nylon brush in a mild solution of hot water and a little washing-up liquid. Do not use “neat” washing up liquid. Do not use: • cleaning agents containing descaling agents, •... -
Page 9: Carbon Filter Usage
Carbon Filter Usage Your product is compatible with one type of carbon filter. • Before installing or replacing the carbon filters, you should switch off and disconnect the electricity supply. • The carbon filters should never be washed. • The grease filter should be installed on the product even when carbon filters are not being used. Do not use your product without the grease filter. -
Page 10: Hints And Tips
Hints and Tips Problem Solution • Check Electric connection. (The supply voltage should be 220-240 V. The cooker hood must be connected to an earthed socket.) Cooker hood does not operate • Check motor speed selector. (Motor speed selector should be in position I, II or III.) •... -
Page 11: Specifications
Technical Specification Model no. L90CHDB10 Extraction Rate (m Voltage (V) 220 – 240 ~ Frequency (Hz) Total Power (W) Lamp 2 × 25 W Because we continually strive to improve our products we may change specifications and designs without prior notice. -
Page 12: Installation
Installation Product Overview Chimney connection plate Internal chimney Plastic chimney External chimney Chimney adaptor GB-12... - Page 13 All dimensions shown are in mm. GB-13...
-
Page 14: Safety Distance Between Hob And Cooker Hood
Safety Distance between Hob and Cooker Hood When planning the installation height of your cooker hood, the minimum safe distance between the top of a cooker or hob and the bottom of the cooker hood are as follows, unless a greater distance is specified by the manufacturer of your cooking appliance: 650 mm —... -
Page 15: Connection For Air Extraction
Connection for Air Extraction To avoid the danger of toxic fumes, please observe the Safety Warnings. This is especially crucial when using the cooker hood at the same time as another heating appliance which relies on air from the same room. The cooker hood should be installed according to local and national building regulations. -
Page 16: Mounting The Cooker Hood
Mounting the Cooker Hood • We recommend professional tradespersons are consulted prior to the fitting of this appliance. • Each installation is different and these instructions should be used as a guide only. If in doubt consult professional tradespersons. • Air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels. - Page 17 Wall Plug Fixings Push the Ø 10mm wall plugs into the drilled holes (A, B, C, D). For the chimney connection plate, push the 2 pcs of Ø 6mm wall plugs into the holes drilled with Ø 6mm drill bit. Fixing the screws Screw the 5.5 ×...
-
Page 18: Safety Warnings
Safety Warnings Safety with children This appliance complies with all relevant local and national safety requirements. • This appliance is only intended for use by Inappropriate use can, however, lead to adults who have read these instructions. personal injury and damage to property. • This appliance is not a toy! To avoid the risk of To avoid the risk of accidents and injury, keep children well away and do not... - Page 19 • Do not use the cooker hood without the filters • Only open the housing as described in the in place. This way you will avoid the risk of instructions. Under no circumstances should grease and dirt getting into the appliance and any other parts of the housing be opened.
- Page 20 Using at the same time as other heating In order to ensure safe operation, and to prevent appliances that depend on the air from gases given off by the heating appliances from the same room. being drawn back into the room when the cooker hood and the heater are in operation simultaneously, an underpressure of 0.04 mbar Warning...
- Page 21 Correct installation • Refer to the cooker or hob manufacturer's instructions as to whether a cooker hood may be operated above the cooker/hob. • The minimum safe distances between the top of the cooker or hob and the bottom of the cooker hood given in the Installation section of this booklet must be maintained, unless the hob/cooker manufacturer states that a greater...
- Page 24 If you require a replacement for any of the items listed below, please quote their corresponding part numbers: Replacement Part Part Number 10 mm plastic wall plug YT 350.1000.02 6 mm plastic wall plug YT 350.1000.01 5.5 × 60 mm YSB screw YT 310.1000.20 M5 ×...
