www.gracobaby.ca
TURBOBOOSTER
Do not install or use this child
restraint until you read, understand
and follow the instructions in this
manual and the warnings on
the car seat.
FAILURE TO PROPERLY USE THIS
CHILD RESTRAINT INCREASES THE
RISK OF SERIOUS INJURY OR DEATH
IN A SUDDEN STOP OR CRASH.
PD349130E 11/18

Advertisement

loading
Need help?

Need help?

Do you have a question about the TURBOBOOSTER PD349130E and is the answer not in the manual?

Questions and answers

Related Manuals for Graco TURBOBOOSTER PD349130E

Summary of Contents for Graco TURBOBOOSTER PD349130E

  • Page 1 www.gracobaby.ca TURBOBOOSTER Do not install or use this child restraint until you read, understand and follow the instructions in this manual and the warnings on the car seat. FAILURE TO PROPERLY USE THIS CHILD RESTRAINT INCREASES THE RISK OF SERIOUS INJURY OR DEATH IN A SUDDEN STOP OR CRASH.
  • Page 2 1 Important Pages 5-19 1-A Quick Guide to Your Manual 1-B Welcome to the Graco Family 1-C Before You Begin Register This Car Seat If You Need Help Certification Car Seat’s Useful Life Vehicle Seat Protection Warm Weather Use 1-D Safety Warnings...

  • Page 3: Securing Child

    3 Booster Pages 24-27 3-A Booster Use 3-B Install Booster 3-C Install Backless Booster 4 Securing Child Pages 28-37 4-A Securing Child Backed Booster 4-B Securing Child Backless Booster 5 Accessories Page 38...

  • Page 4: Vehicle Information

    6 Vehicle Information Pages 39-42 6-A Choosing Vehicle Seat Location 6-B Unsafe Vehicle Seat Location 6-C Vehicle Seat Belts 7 Care & Cleaning Pages 43 7-A Cleaning Seat Pad tigh...
  • Page 5 1-A Quick Guide to Your Manual This car seat is for children: Booster: 18-45 kg (40-100 lb) 110-145 cm (43-57 in) Car Seat Assembly (On Select Models) Adult Assembly Required 1. Armrests Insert armrest into base as shown until buttons snap into slots on side of base.
  • Page 6 2. Armrest Covers Slip armrest covers onto armrests as shown. (on certain models) 3. Back support pad (on select models) On certain models, your lower back support pad may not be attached to the back support. Place lower back support pad around edges of support as shown.
  • Page 7 4. Head support (on select models) Flip head support and lower back support over as shown. Squeeze red adjustment button and slide two pieces together until they snap into place. CHECK to make sure two pieces are securely snapped together by pulling on them. Attach elastic strap to metal hook on other side of seat pad as shown.
  • Page 8 5. Head support pad (on select models) Flip seat over and insert the fabric from the head support underneath the fabric on the lower back support as shown. To make insertion of fabric easier, slide the upper and lower back pieces apart by squeezing the red adjustment button.
  • Page 9 Once backrest is securely attached to the base, push backrest up as shown. Your Graco booster seat is now ready to use.
  • Page 10 Get to Know Your Car Seat Review section 2-A to see all of the features of this booster seat. What Seating Location Should I Use? The best seating location for this booster seat is one that: • Is recommended by your vehicle owner’s manual, and •...
  • Page 11 Using The Car Seat Correctly To make sure your child is secured properly, review section 3 and 4 to fit your child. When Installing As a Booster Vehicle Seat Belt There is one type of vehicle seat belt that can be used: Lap/Shoulder Seat Belt.
  • Page 12 Booster Installation Use Lap/Shoulder Belt Only Review section 3 Position Lap Belt Highback Backless Lap belt must go in front of armrest and lie low across your child’s hips and thighs. Review section 3 Position Shoulder Belt Shoulder belt lies across shoulder between neck and edge of shoulder.
  • Page 13 1-B Welcome to the Graco Family! Your child’s safety depends on you. No car seat can guarantee protection from injury in every situation, but proper use helps reduce the risk of serious injury or death. Even if this car seat seems easy to figure out on your own, you must follow the detailed...
  • Page 14 1-C Before You Begin Register This Child Restraint Please fill out the prepaid registration postcard attached to the harness and mail it in today or register online at www.gracobaby.ca Child restraints could be recalled for safety reasons. You must register this restraint to be reached in a recall.
  • Page 15 For future reference or if you change addresses, record the model name, model number, date of manufacture and purchase date of this car seat on the below. You can find this information either on the registration card if you still have it or on the date label located on the back of the car seat.
  • Page 16 Certification This child restraint meets or exceeds all applicable requirements of Canadian Motor Vehicle Safety Standards 213.2 for use in motor vehicles. This child restraint is NOT certified for use in aircraft because aircrafts do not have shoulder belts.
  • Page 17 STOP using this car seat and throw it away 10 years after the date of manufacture. Look for this sticker on back of the car seat. Graco Children’s Products Inc. advises against loaning or passing along a car seat unless you know the complete history of the product. We also advise against purchasing a car seat second hand.
  • Page 18 Failure to follow these instructions and child restraint’s labels can result in child striking the vehicle’s interior during a sudden stop or crash. Review your vehicle owner’s manual for more information about air bags and car seat use. If your vehicle does not have a back seat, review your vehicle owner’s manual.
  • Page 19 DO NOT use car seat if it is damaged or missing parts. DO NOT use accessories or parts other than those provided by Graco except for a thin towel or mat to protect your vehicle seat. Their use could alter the performance of the car seat.
  • Page 20 2-A Car Seat Features...
  • Page 21 A Head Support B Shoulder Belt Guide C Cup Holder...
  • Page 23 A Head Support Adjustment Lever B Belt Positioning Clip (Inset)
  • Page 24 3-A Booster Use • N • D Booster Use With Back: 18-45 kg (40-100 lb) 110-145 cm • D (43-57 in.) at least 4 years old • D Booster Use Without Back: 18-45 kg (40-100 lb) • V 110-145 cm (43-57 in.) at least 4 years old •...
  • Page 25 • Never use a vehicle lap-only belt across front of child. • DO NOT position vehicle shoulder belt under the child’s arm or back. • DO NOT allow child to slouch or slide down in the booster seat. • DO NOT position vehicle belt over top of armrests. Never Use a Vehicle •...
  • Page 26 3-B Install Booster 1. Place Car Seat Forward-Facing in Back Seat of the Vehicle Place forward-facing in vehicle seat. The bottom of the seat should sit as flat as possible on the vehicle seat. 2. Thread the Vehicle Seat Shoulder Belt Through Seat Belt Guide on the Headrest See section 4-A to secure your child.
  • Page 27 3-C Install Backless Booster 1. Remove the Back Support (on select models) Recline seat back then remove from base. 2. Place the Booster Seat Forward-Facing in the Back Seat of Vehicle Place forward-facing on a vehicle seat that has a lap/ shoulder seat belt.
  • Page 28 4-A Securing Child Backed Booster Use only the vehicle lap and shoulder belt system when restraining the child in the booster seat. 1. Place Child In Seat Have your child sit in the booster seat, with his/her back flat against the back of the booster seat.
  • Page 29 3. To Raise or Lower Headrest Support Lift adjustment lever and lift or lower headrest.
  • Page 30 4. Buckle the Vehicle Lap/Shoulder Seat Belt Be sure the lap portion of the vehicle seat belt goes in front of both armrests and the shoulder belt goes under the armrest on the buckle side. Be sure the lap portion of the vehicle seat belt lies low across your child’s hips.
  • Page 31 Is Everything Correct? Never Use Lap Belt Only Lap Belt in Front of Armrest and Lies Low Across Hips and Thighs Shoulder Belt Lies On the Shoulder, Between the Neck and Edge of Shoulders...
  • Page 32 4-B Securing Child Backless Booster Use only the vehicle lap and shoulder belt system when restraining the child in the booster seat. 1. Place Child In Seat Have your child sit in the booster seat, with his/her back flat against the back of the vehicle seat. 2.
  • Page 33 3. Buckle the Vehicle Lap/Shoulder Seat Belt Be sure the lap portion of the vehicle seat belt goes in front of both armrests and the shoulder belt goes under the armrest on the buckle side. Be sure the lap portion of the vehicle seat belt lies low across your child’s hips.
  • Page 34 Is Everything Correct? Never Use Lap Belt Only Lap Belt in Front of Armrest and Lies Low Across Hips and Thighs Shoulder Belt Lies On the Shoulder, Between the Neck and Edge of Shoulders...
  • Page 35 Using Belt Positioning Clip 1. Make Sure Vehicle’s Seat Shoulder Belt Lays in the Red Zone As Shown If the vehicle’s seat shoulder belt lays outside this zone, you MUST use the belt positioning clip. DO NOT use the belt positioning clip if the shoulder belt is in the red zone. 2.
  • Page 36 4. Free End of Strap Should Face Front of Seat 5. Place Child in Seat, Buckle Child In Seat and Attach Belt Positioning Clip if Needed With child’s back flat against the back of the vehicle seat, buckle child in. Then slide the clip onto the vehicle’s seat shoulder belt as shown.
  • Page 37 6. Adjust the Belt Positioning Clip to Fit Your Child Lengthen Shorten Lengthen or shorten the belt length as shown. Clip should fit right at the top of shoulder as shown. Be sure the lap portion of the vehicle seat belt lies low across your child’s hips.
  • Page 38 5 Accessories (on select models) Cup Holders In t chil follo...
  • Page 39 6-A Choosing Vehicle Seat Location Review your vehicle’s owner manual for Seating Locations The best seating location for this car seat is one that: • Is recommended by your vehicle owner’s manual, and • Results in a secure installation of this car seat In the event there is no available back seat and / or you have no other option than to place a child other than in a front passenger seating position, experts recommend that you take the following steps:...
  • Page 40 6-B Unsafe Vehicle Seat Location Never install this car seat in any of the following vehicle seating locations: rear-facing or side-facing booster mode with vehicle vehicle seats lap belt only seat belt...
  • Page 41 6-C Vehicle Seat Belts Review your vehicle’s owner manual for vehicle seat belt use Vehicle Seat Belt Terms Retractor A device that winds up the unused vehicle seat belt. It is often hidden inside the panels on the walls of the vehicle or in the vehicle seatback.
  • Page 42 Identify Your Seat Belt Type There is one type of vehicle The following types of vehicle seat belts seat belt that can be used CANNOT be used safely with this booster seat: with this car seat: Lap Belt Only 2 Lap Belt with Lap Belt or connection points...
  • Page 43 7-A Cleaning Seat Pad Refer to seat pad care tag for washing instructions. To Remove Seat Cover Remove elastic loops and hooks from seat as shown. Clean with a damp sponge using mild soap and cool water. If needed, head support cover may be removed for cleaning.

  • Page 44: Replacement Parts

    Replacement Parts To purchase parts or accessories in Canada, please contact us at the following: www.gracobaby.ca • gracoconsumercareca@newellco.com 1-800-345-4109 Store instruction manual in the slot with the instruction book icon as shown.
